Introduction: 3D Printed Back to the Future TIme Circuit Clock

The time circuit clock will display the following via the LED displays.

Destination Time – (Top-Red)

The destination time is an area that shows a fixed date and time. Use this area to display an important date in your life such as wedding, Birthday or the date you first discovered this most excellent clock.

Present Time – (Middle-Green)

The present time is the current date and time. You set this initially when you download the Arduino and you can adjust the hour and minute via the RGB LCD display keypad.

Last Time Departed – (Bottom-Yellow)

The last time departed will alternate between three different important dates every 20 seconds. Use this for birthdays, the date you finished building the clock, the day you met your significant other, etc.

The time circuit clock will announce the time between the hours of 8:00 AM and 9:30 PM. The time is generated via the Music Maker MP3 shield. The audio files for the time announcement were recorded by my wife and are included. To enhance the clock further, I enlisted a voice impersonator that recorded the time announcements as "Doc Browns: voice. Contact information for the voice impersonator is included in this “Instructable”.

Power on message and time announce files are provided. You can change these by simply by recording new .mp3 files and putting them on the music maker board micro SD card.

The clock is 3D printed and utilizes (1) Arduino Uno, (1) Music Maker MP3 shield, (1) ChronoDot real time clock, (1) RGB LCD keypad, (9) 3 mm LEDs, (1) voltage isolator and a few other components. A complete parts list is provided at the end of this “Instructable”.

The .stl files for printing the clock parts, Arduino code, wiring diagram, decal template and the audio files are located here. The clock was printed on a Lulzbot mini which has a print bed size of 150 mm x 150 mm. Due to the smaller print bed, some parts require gluing.

The entire clock was printed with HIPS filament with the exception of the pushbutton extensions that were printed with black ABS filament.

Step 1: Components - Arduino Uno R3 Controller

Step 2: Components - Arduino Proto Screwshield

Step 3: Components - ChronoDot Real Time Clock

Step 4: Components - Music Maker MP3 Shield

Step 5: Components - Audio Speakers

Step 6: Components - LED Displays

Step 7: Components - LED Backpack

Step 8: Components - SN74HC138N 3 – 8 Line Decoder

Step 9: Components - RGB LCD Shield

Step 10: Components - AM / PM LEDs

Step 11: Components - Power Supply

Step 12: Components - Panel Mount 2.1 MM DC Barrel Jack

Step 13: Components - LM7805 Voltage Stabilizer

Step 14: Components - Perma-Proto Breadboard

Step 15: Components - Filament

Step 16: Components - Wire

Step 17: Components - Paint

Step 18: Components - Screws / Washers

Step 19: Clock Decals / Design

Step 20: 3D Printing - BTTF_Pushbuttons.stl

Step 21: 3D Printing - BTTF_Pushbuttons.stl

Step 22: 3D Printing - BTTF_Top_Left_LCD.stl & BTTF_Top_Right.stl

Step 23: 3D Printing - BTTF_Front_Side_Left.stl & BTTF_Front_Side_Right.stl

Step 24: 3D Printing - BTTF_Speaker_Covers.stl

Step 25: 3D Printing - BTTF_Front_LED_Left.stl & BTTF_Front_LED_Right.stl

Step 26: 3D Printing - BTTF_Bottom_Left.stl & BTTF_Bottom_Right.stl

Step 27: 3D Printing - BTTF_Back_Left.stl & BTTF_Back_Right.stl

Step 28: 3D Printing - Assembly View 1 & Assembly View 2

Step 29: 3D Printing - Assembly View 3 & Assembly View 4

Step 30: 3D Printing - Assembly View 5

Step 31: 3D Printing - Assembly View 6 & Assembly View 7

Step 32: Construction - Glue the Top, Front and Bottom Halves

Step 33: Construction - Glue the Front Halves

Step 34: Construction - Glue the Top Halves

Step 35: Construction - Glue the Back Halves

Step 36: Construction - Glue the Bottom Halves

Step 37: Construction - Drill Guide Holes for LED Displays / Drill / Expand LED Mounting Holes

Step 38: Construction - Drill Guide Holes for RGB LCD Display

Step 39: Construction - Drill / Expand RGB LCD Pushbutton / Contrast Holes

Step 40: Construction - Layout the Left and Right Sides

Step 41: Construction - Insert the Speaker Covers and Speakers

Step 42: Construction - Glue the Enclosure

Step 43: Construction - Assemble the Enclosure

Step 44: Construction - Assemble the Enclosure

Step 45: Construction - Prepare the Enclosure for Painting

Step 46: Construction - Prepare the Enclosure for Painting

Step 47: Construction - Paint Enclosure

Step 48: Construction - Paint Enclosure

Step 49: Construction - Assemble Music Maker

Step 50: Construction - Wire and Mount the 4 Digit LED Displays

Step 51: Construction - Wire and Mount AM/PM LEDs

Step 52: Construction - Mount the Voltage Stabilizer

Step 53: Construction - Mount the Arduino Uno

Step 54: Construction - Mount the RGB LCD Display

Step 55: Construction - Wiring Diagram

Step 56: Construction - Wire the Perma-Proto Board

Step 57: Construction - Wire the Screwshield & Install Arduino

Step 58: Construction - Install Music Maker on Screwshield

Step 59: Construction - Mount /Wire DC Barrel Connector

Step 60: Construction - Install Decals

Step 61: Construction - Install Decals

Step 62: Construction - Attach Base / Bumpers

Step 63: Construction - Make Power Connection

Step 64: RGB LCD Operation

Step 65: RGB LCD Operation - Hour Increment / Decrement

Step 66: RGB LCD Operation - Minute Increment / Decrement

Step 67: RGB LCD Operation - Backlight & Contrast

Step 68: Time Displays

Step 69: Time Announcement

Step 70: Power Up Sequence

Step 71: Parts Listing

ADAFRUIT

Arduino Uno R3 - Adafruit.com Product ID: 50

Adafruit "Music Maker" MP3 Shield for Arduino w/3W Stereo Amp - Adafruit.com Product ID: 1788

ChronoDot Real Time Clock - Adafruit.com Product ID: 255

Stereo Enclosed Speaker Set - 3W 4 Ohm - Adafruit.com Product ID: 1669

SD/MicroSD Memory Card (4 GB SDHC) - Adafruit.com Product ID: 102

Perma-Proto Half Sized Breadboard - Adafruit.com Product ID: 1609


AMAZON

Blinggasm Waterslide Decal Paper 10 Sheets Pack, Clear or White, Inkjet or Laser Printer Choose From Menu (WHITE FOR LASER PRINTER) - Amazon.com

http://www.amazon.com/gp/product/B00ZLVF670?psc=1&redirect=true&ref_=oh_aui_search_detailpage

OMNIHIL AC/DC 9V 2A High Quality Power Adapter - Amazon.com

http://www.amazon.com/gp/product/B00CAC399U?psc=1...

SMAKN® L7805 LM7805 3-Terminal Voltage Stabilizer 5V Voltage Stabilizer Power Module - Amazon.com

http://www.amazon.com/gp/product/B00RKY0NP6?psc=1...

Arduino Proto Screw Shield - Amazon.com

http://www.amazon.com/gp/product/B00HBVVKPA?psc=1...

Lowes

Paint - Rustoleum Forged Pewter

Screws - #2 x 3/8” and #4 x ½ “

Lulzbot.com

Gray Hips Filament - Lulzbot.com Gray HIPS 3mm, 1kg, filament (ESUN)

Black ABS Filament - Lulzbot.com Black ABS 3mm, 1kg, filament

Glue (SCIGRIP Weld-On 3 Cement)

Tapplastics.com

Glue (SCIGRIP Weld-On 3 Cement) - Tapplastics.com

http://www.tapplastics.com/product/repair_product...

Glue Applicators - Tapplastics.com

http://www.tapplastics.com/product/repair_product...

Autozone

Bondo Glazing Putty
