A small parts holding clamp replaces your fingers for holding small items when cutting them on a band saw, sanding them on a belt sander, drilling or carving them.


There are many variations of small parts holding clamps. Mine are inspired by wood Jorgensen clamps, but use only one tightening screw.

These can be made in any size you desire. Too, there are various ways you can approach some aspects of the construction. I will attempt to point out alternatives as they become relevant.

Those experienced in woodwork probably just need to look at the clamp to see how to go about building it. That said, to build this clamp, you need the parts listed below. All the parts can be had from any decent hardware supply.

1) some scrap plywood or a good hardwood sufficient to make your clamp;

2.1) a toilet T-bolt [for the pivot];

2.2) a 1/4"x20 TPI nut [for the pivot];

2.3) two quarter inch flat washers;

or

2.1) a 1/4" x 20 TPI screw [for the pivot];

2.2) a 1/4"x20 TPI nut [for the pivot];

2.3) two quarter inch flat washers;

or

2.1) a 1/4" x 20 TPI Allen screw [for the pivot];

2.2) a 1/4"x20 TPI nut [for the pivot];

2.3) two quarter inch flat washers;

or

2.1) a 1/4" x 20 TPI

specialty furniture screw [for the pivot];

2.2) a 1/4"x20 TPI nut [for the pivot];

2.3) two quarter inch flat washers;

or

2.1) a 3/8" dowel;

2.2) two number six pan head screws;

2.3) two number six flat washers;

3) a 1/4" x 20 allthread rod;

4.1) two 1/4" x 20 nuts (to double nut (lock) the end from coming loose);

4.2) a 1/4"x20 female knob;

4.3 a 1/4"x20 flat washer;

or

4.1) a 1/4" x 20 T-nut;

4.2) a 1/4" x 20 nut;

4.3) a 1/4" x 20 flat washer;

5) 1/4" x 20 TPI female knob;

6) 1/4" x 20 TPI allthread rod

These are quite easy to make and take only a little while. Most the time is spend waiting for the glue to dry. Too, everything you need for them can be found at a hardware supply.

Step 1: INITIAL LAYOUT

Layout of the clamp is simple. You can freehand it, use commercial templates, jar tops, etc.), or do a little of both. I chose the latter.


I started layout my clamp using a circle template jig to establish the pivot area. For example, my first clamp was built off a 2-3/8" circle size, which I thought appropriate for the size clamp I was making. For the arm, I used an arc template. I chose an arc that gave me the length of arm I was shooting for.

When tracing the circle, I used the index lines to mark points ninety degrees apart on the circle. I joined the lines to mark center of the circle to establish the center of the pivot point for later drilling.

Clamps arms can be varied in length. A shorter clamp may be more comfortable in some applications. On the other hand, making the clamp longer will increase its capacity.

For the clamping ends of the clamp, I found it beneficial to extend the ends at least an inch or more. For my first clamp, I roughed in the ends freehand

I also put a little slant on the parts that hold a piece. The slant tilts back toward the arc of the half of the clamp they are on. When the clamps are opened wider, the angle keeps the jaws more parallel. This seems to help them hold better as they open wider.

If the clamp ends are kept straight, you can glue hard wood replacements to them at any time to try different shapes.

Step 2: INITIAL CUT

Once the first side laid out, cut it out on a band saw or use a jig saw and a fine blade. If necessary, a hole can be drilled in the previously marked center of the circle to allow the material to be secured during cutting. Another alternative would be to use a coping saw.

Step 3: FINAL LAYOUT

Once the first piece is cut, use it to draw a second, identical piece for the opposing jaw.


Also use the first piece to draw two duplicates of the first few inches of the clamping area. These can extend most the way down the arm, but should stop about an inch from the pivot area, so they do not interfere with the operation of the clamp.

Step 4: FINAL CUT

Cut the remaining three pieces just drawn out

Step 5: GLUING

If you desire sand the surfaces, it is much easier to smooth the backs of the short pieces before gluing is started.

Glue the smaller pieces to the full pieces, as shown in the photo. Both sides should be assembled identically. For example, when you lay them one beneath the other, both pivots would be on the left and both arms would extend to the right. The short pieces, the spacers will be lined up with and glued to the top of right ends of the arms.

You can just clap the pieces and wait for them to dry. You can also nail or screw the pieces. as they dry. I prefer clamping, so I can modify the ends without concern about a saw blade encountering nails or screws.

Allow the glue to harden.

Step 6: INSTALLING THE PIVOT (Joining the Clamp Halves)

You have several options for joining the two halves of the clamp and creating a pivot. You can:
1) use a nut, bolt and washers;

2) use a toilet mounting bolt, nut and washer;

3) use an allen head screw, two washers and a nut;

4) use a specialty furniture screw (with an Allen head (my favorite));

5) use a standard screw, two washers and a nut; or,

7) use a dowel, two screws and two washers.

Often, the use of the clamp requires it rest flat on a band saw table or other flat surface. Also, it may need to slide across that surface. For those reasons and to make the clamps more versatile, the bolts, screws and washers used to join the two halves must be counter sunk in the clamp material.

If you haven’t already drilled a hole in the center of the circles, mark the centers with an awl or other pointed object.

If you used a jar lid or other than a template with endexes, you need a means of finding center. In a pinch, this could be done by measuring across the widest part of the two circles and marking the half way points. Repeat this three or more times, moving around the circle. Where the lines intersect should give a reasonable indicator of center.

Using a spade, Forstner or spur bit sized big enough to create a hole the washers will fit in, drill holes in the outer parts of both halves of the clamp, using the holes you just made in the circle centers. Drill only deep enough to get the washer and nut or screw heads flush or just below the surface.

Next, drill a hole big enough for the screw, bolt or dowel, depending on which you chose to use.

Once the hole is drilled, install the screw, bolt or dowel through the two halves of the clamp.

The furniture screw seen in the picture needs a washer only under the nut, but regular screws or a bolt should have a washer under both the head and under the nut.

Install the washer and nut and snug them. You can use a punch at three places around the nut, where it contacts the screw, to lock it in place. If you used a dowel, install two 3/8" panhead wood screws with washers slightly larger than the dowel under them.

The clamp should be snug, but still open and close with reasonable ease. All the screw heads and nuts should be flush or just below the surface.

If part of the bolt or screw extends above the clamp surface, cut or grind it off, though you could use the clamp by just working off the side that is flush.

Step 7: ADDING THE LOCKING ROD AND KNOB

For this, a 1/4"x20 TPI T-nut, with barbs on the back, and allthread work well. The barbs on the T-nut stop the allthread from spinning, once allthread is locked to the T-nut with a jam nut [against the back of the T-nut].
Install the T-nut on the allthread with the barbs pointing in the direction you will be turning it, like in the picture.

Run the T-nut down just far enough to get a nut all the way on the allthread, keeping the surface of the nut flush with the end of the allthread, move the T-nut back against the nut and tighten the two against each other. Essentially, you are just double nutting the end of the rod, so it won’t turn when you tighten the locking knob, .

If appearance is important, you can switch from a standard nut to an acorn cap nut.

At about center of the open area of the two arms and at the center of the thickness of the arm, make a mark where you will drill a hole through the two arms, and for larger, but shallow, hole to flush mount the T-nut and jam nut.

Using a Forstner, spade bit or spur bit, drill a hole just deep to sink the T-nut and jamb nut flush into the clamp.

Next, drill a hole through the clamp arm. The hole should go through the first arm and enter the second such that the hole appears in the same position as the first arm, but on the second arm. See the initial pictures for an example.

In the opposite arm from the one the T-nut will install in, run the drill bit at an extreme angle toward the clamp tip, while keeping it in the center of the wood. Move the bit back and forth to elongate the hole. The longer the hole, the larger the clamp can be opened.

I used my jig saw and a fine blade to clean up the elongated hole, but any means that gets the hole to a point you are happy with how wide the clamp opens is fair game.

Once the hole is satisfactory, install the allthread through the hole so the T-nut and jamb nut are in the larger hole. Merely tightening the clamp MAY be sufficient to pull the T-nut barbs into the wood, but I found I had to use a drift punch to press the T-nut barbs into the wood on a couple of the clamps I made.

Once the allthread is installed, install a washer and the tightening knob.

Open the clamp as far as it can be opened and, with the knob all the way down, cut off the excess all thread [and save it for your next clamp].

Step 8: JAW REPAIRS AND MODIFICATIONS

You can experiment with different jaw configurations. For example:
1) Jaw tip modifications can be permanent or temporary.

2) Tip choices could include short and long parallel tips, slight or extreme angled tips, grooved gripping tips (like pliers), rounded tips for pipes and so on.

3) When the clamp is complete and if you are willing to work off only one side , you can modify it by cutting down or sanding down the clamping face (reducing the thickness) near the tip.

4) You can approach making the tips interchangeable in various ways:

a) You could use barrel nuts in the clamp body and screws through and counter sunk into the tips. To do this:

i) To do this, drill a hole in the jaw body, at the center of the clamp [thickness] about 1/2" back from the edge of the stationary jaw tip, just slightly larger than the barrel nut (so it can be turned and removed, if necessary). The hole would be just deep enough for the threaded hole of the barrel nut to line up with the center of the jaw tip.

ii) Then you'd drill a hole through the end of each clamp arm and into the center of the holed you just drilled for the barrel nut, to allow you to run a screw from the clamp tip into the barrel nut.

iii) Any tips you want to install would need a countersunk hole at their centers, so a screw could be installed through them into the barrel nut, to hold them on.

or

a) You could use a dowel to hold interchangeable tips in place (you may need to cut the jaw tips back a little to maintain capacity). To do this:

i) Drill holes sized for your dowels at the center of each jaw tip.

ii) Drill holes sized for your dowels in each interchangeable tip.

iii) You can permanently install a dowel in either the clamp end or i) You can permanently install a dowel in each interchangeable tip.

NOTES: The dowel holes should be snug enough to hold the dowel, but not so tight you have to fight to get the interchangeable tip back off.

By not glueing the dowel into the clamp or the tip, they are more easily removed.

5) When the clamp is completed and if you are not satisfied with the reach, angle or grip of the jaws, or if they become damaged from use, you can square the ends using a sander or saw, then glue on new ends.

Once you have new jaw tips, merely closing the clamp will, of course, hold the new tips while the glue dries.

If the jaws don't close parallel for gluing and clamping, use a couple wedges to create temporary parallel edges.
