    Here are some photos of the Mavic Clone Frame I am working on from this instructable. I have printed all of the parts and assembled most of the frame. I am waiting on the springs to come in the mail, I am also waiting for the motors, ESC's, batteries, radio and propellers. There are a couple of parts I am going to reprint only because I made some mistakes or want to change the color. All in all it has been a very easy project so far even with some of the prints running as high as 18 hours. I am pleased with the overall design and will be flying this for quite a while because it is so compact when folded up.

    View Instructable »
  • Printable Foldable Quadcopter, DJI Mavic Clone Frame

    Sorry for bringing up two problems I am experiencing here however I think this needs to be discussed. I have printed the body_bottom three times, the last time was printed right side up just to make sure I did not have any issues induced by printing it upside down. The attached image shows the 2mm gap between the front of the body and the head_bottom piece. This gap is the result of the opening for the front arms not being tall enough for the 14mm arms. The other issue I have, which was solved with a file, is the 10mm diameter pin that mates with the body_bottom front arm mounting area is too long at 3.18mm for the 2.378mm deep recess it is supposed to fit into. The top pins fit into the head_top just fine as the recess there is deeper than the ones on the body_bottom. I have printe...see more »Sorry for bringing up two problems I am experiencing here however I think this needs to be discussed. I have printed the body_bottom three times, the last time was printed right side up just to make sure I did not have any issues induced by printing it upside down. The attached image shows the 2mm gap between the front of the body and the head_bottom piece. This gap is the result of the opening for the front arms not being tall enough for the 14mm arms. The other issue I have, which was solved with a file, is the 10mm diameter pin that mates with the body_bottom front arm mounting area is too long at 3.18mm for the 2.378mm deep recess it is supposed to fit into. The top pins fit into the head_top just fine as the recess there is deeper than the ones on the body_bottom. I have printed the 20mm test cube which came out to exactly 20mm when measured is all directions.

    View Instructable »
  • Printable Foldable Quadcopter, DJI Mavic Clone Frame

    I printed the rear legs last night, all turned out well. Since I am here in the United States it is not easy to locate metric wood screws. I found a source on ebay however the shipping is way more than the cost of the screws. I did some research and determined I can use #6 x 2 (50.8mm) so I went to the local home center an bought a pack. They work well and fit just fine. I did however learn to make very sure the hole for the screws is clear and ALL support material has been removed. I didn't get one of them cleared out completely and broke the pivot pin. Lesson learned, I had to print another right read leg.I am now on my third attempt today at printing the body top. For some reason they keep failing about an hour into the print with portions of the support structure coming off of...see more »I printed the rear legs last night, all turned out well. Since I am here in the United States it is not easy to locate metric wood screws. I found a source on ebay however the shipping is way more than the cost of the screws. I did some research and determined I can use #6 x 2 (50.8mm) so I went to the local home center an bought a pack. They work well and fit just fine. I did however learn to make very sure the hole for the screws is clear and ALL support material has been removed. I didn't get one of them cleared out completely and broke the pivot pin. Lesson learned, I had to print another right read leg.I am now on my third attempt today at printing the body top. For some reason they keep failing about an hour into the print with portions of the support structure coming off of the table. It is a lot of support material since I am printing it right side up, maybe I should turn it upside down. Any thoughts on this?Thanks
