Introduction: 2 Liter Bottle Water Rocket and Launcher Pad
First, I know this is not the first 2 Liter Bottle Water Rocket launching system ever designed. This design actually took inspiration from several of the designs that NASA had posted.
Second, depending on where you buy your parts and what stuff you have on hand, this may not be the cheapest design either. You will need to decide if this design provides you the characteristics that warrant the potential additional costs over alternative designs. I had some very distinctive goals with this Water Rocket Launcher system that I personally felt the other designs did not fulfill. For example:
- The design needed to survive rapid repeated use in a very short amount of time. Scaling to 100+ repeated launches in a day with the ability to turn around and do it again the next day. Not only did this mean it needed to be rugged enough to last, but it had to have a system that allowed for quick resets.
- The design needed to allow children 6-17 and adults of all ages to pressurize and launch the system from a safe distance (~20 feet). Although staging / clamping and safety check would be done by an experience adult / young adult prior to pressurizing, it was important to me that each participant had the opportunity to be involved in the act of pressuring and releasing the Water Rocket.
Third, I know the design is not perfect. I am hoping, like I did with other designs I found, someone will see this design, identify refinement opportunities, and be inspired to improve on it.
In short... Do your own engineering work and analysis of the approach for your specific implementation to determine validity, safety, and assume accountability for the outcome of your engineering assessment; assess and mitigate the risks specific to your scenario and skill level. Use good sense on how, where, and if to use this approach; if you are unsure, do not use it... I would have said common sense, but common sense is definitely not common.
This Bottle Water Rocket Launcher Design has 3 major system components:
- 2 Liter Bottle Water Rocket & Pressurization Plug: This system stores the pressurized water and air and, on Launch Pad Clamp release, allows the 2 Liter Bottle to generate thrust projecting the 2 Liter Bottle housing into the air.
- Launch Pad: Holds the 2 Liter Bottle Water Rocket while the system is being pressurized and provides a mechanism to quickly release the pressurized water / air.
- Modified Bicycle Pump / Pressurization System: Although any bicycle pump can be used to pressurize the system, this modified version provided additional hose length and pressurized water back flow protection. Whether you use this modified bicycle pump or any off the shelf bicycle pump design, a bicycle pump or air compressor is required.
Summary of Procedure:
Launch System Component Assemble
- Getting your Materials (Parts & Tools)
- Assemble Pressurization Plug
- Assemble Launch Pad Clamp Bracket and Hinge
- Launch Pad Base preparation
- Launch Pad Base Pressurization Plug Housing rough-in
- Launch Pad Base Pressurization Plug Housing tuning
- Fastening Launch Pad Clamps to Launch Pad Base
- Place the Launch Pad Clamps under return spring tension
- Secure Stabilization Feet to Launch Pad Assemble Base
- Affix Velcro Launch Pad Clamp release strap
- Disassemble Bicycle Pump
- Assemble Bicycle Pump Hose Extension
- Reattach Bicycle Pump Hose & Head
- 2 Liter Bottle Water Rocket and Launcher Pad Operation
- Safety and Additional Notes
Step 1: Getting Your Materials (Parts & Tools)
2 Liter Bottle Water Rocket:
- Use: This is the rocket body housing which stores the pressured water.
- Price: Hopefully you dig this out of recycling or save it after finishing a refreshing beverage. If you need to buy one, they are ~$0.50 - ~$1.50 containing a beverage. (I have used Pepsi and Coke product 2 Liter Bottles without issue.)
- Use: Plugs 2 liter bottle pour spout while pressurizing system.
- Price: Home Science Tools online has them for ~$0.45 - http://www.hometrainingtools.com/rubber-stopper--3-1-hole/p/CE-STOP03A/
- Use: Inserted into widen #3 Rubber Stopper hole and provides Schrader Valve for bicycle pump to pressurize the system.
- Price: AutoZone has them for ~$2.75 - http://www.autozone.com/autozone/accessories/Slime-Tubeless-tire-valves/_/N-25cj?itemIdentifier=542362_0_0_
Launch Pad Assemble:
- Use: Launch Pad Assemble Base.
- Price: Hopefully you have some scrape lumber laying around; if not, price for a 8 foot 2x4 at Home Depot is ~$6.00 - http://www.homedepot.com/p/202061034
- Use: To provide stabilization feet for the Launch Pad Assemble Base.
- Price: Hopefully you have some scrape lumber laying around; if not, price for a 6 foot 4x4 at Home Depot is ~$7.00 - http://www.homedepot.com/p/100043272
- Note: You will need ~3 inches of ground clearance to easily affix the Bicycle Pump Hose Head to the Rubber Stopper Schrader Valve. Doubling up with 2X4 should work fine.
- Use: Clamps and holds 2 Liter Bottle to Launch Pad Base while system is being pressurized.
- Price: Pretty common item at any home improvement store; Home Depot has it for ~$9.50 for a 4 foot length. - http://www.homedepot.com/p/202183466
- Use: Retracts clamps holding pressurized 2 Liter Bottle to Launch Pad Base.
- Price: Theses are ~$16 a piece from Home Depot. I have seen them a couple dollars cheaper online, but with shipping it is usually a wash. - http://www.homedepot.com/p/202033836
- Use: Fasten 1-1/4 inch X 8 inch Punched Angle to 4 Inch Adjustable Spring Hinge.
- Price: Home Depot has a 5 piece pack for ~$1.20 - http://www.homedepot.com/p/202706154
- Use: Fasten 4 Inch Adjustable Spring Hinge to Launch Pad Base.
- Price: Home Depot has a 3 piece pack for ~$1.20 - http://www.homedepot.com/p/202706158
- Use: Washers for Clamp assemble and Launch Pad assemble.
- Price: Home Depot has a 12 piece pack for ~$1.20 - http://www.homedepot.com/p/202704551
- Use: Tension washer for Clamp assemble and launch pad assemble.
- Price: Home Depot has a 6 piece pack for ~$1.20 - http://www.homedepot.com/p/202706385
- Use: Fasten Launch Pad Assemble Base to Stabilization Feet.
- Price: Home Depot has a 1 pound box for ~$10.00 - http://www.homedepot.com/p/203696244
- Use: To keep Launch Pad Clamp halves closed and tightly grasping onto 2 Liter Bottle nozzle rim.
- Price: Home Depot has a 3 pack for ~$4.20 - http://www.homedepot.com/p/202261933
- Use: To pull apart Velcro from itself from a distance allowing the Launch Pad Clamp havles to snap open releasing the 2 Liter Bottle from Launch Pad Base.
- Price: Home Depot has a 225 foot roll for ~$3.00 - http://www.homedepot.com/p/202079597
- Use: To damper the return spring force of the Launch Pad Clamps on release.
- Price: Home Depot has a 16 pack foot roll for ~$2.50 - http://www.homedepot.com/p/100047252
Modified Bicycle Pump / Rocket Pressurization System (Note: Optional modification)
Item: Bell Air Attack 300 Air Pump - Quantity 1
- Use: To pressurize system with air.
- Price: Walmart has them for ~$10.00 - http://www.walmart.com/ip/24311975
- Note: I choose the Bell Air Attack 300 Air Pump because it was inexpensive and easy to modify. Although I did not try other similar style bicycle pumps, it is my assumption that as long as the inner diameter of the pump hole is a 1/4 inch, another bicycle pump should work just fine.
- Use: To prevent water from draining into the pump and extended pump hose line.
- Price: U.S Plastics Corporate has them for $0.70 - http://www.usplastic.com/catalog/item.aspx?itemid=23369
- Note: Normally the existing check value in the pump is sufficient to prevent pressurized water and air from leaking from the system; however, since I extended the hose length, I wanted to ensure pressure remained more consistent at the 2 Liter Bottle.
- Use: To extend the hose length of the bicycle pump.
- Price: This is a pretty common item at any home improvement store. For a 20 foot length, it will be ~$5.00 - http://www.homedepot.com/p/202257573
- Use: To provide additional thickness at the end of the Clear Vinyl tube being inserted into the Bicycle Pump to ensure secure fitting when screwing down bicycle pump hose clamp.
- Price: This is a pretty common item at any home improvement store. ~$1.00 per roll. - http://www.homedepot.com/p/100130843
Get your Tools...
- Circular Saw, Electric Drill, Hack Saw, Pencil, Philip Screw Drive, Ratchet Set, Rubber Malt, Vice, Metal file, Needle Nose Pliers, Pliers
- Drill Bits: 1/4 inch, 3/8 inch, 3/32 inch, 1/2 inch Spade or Forstner bit, 1 inch Spade or Forstner bit, 1-5/8 inch Spade or Forstner bit
Step 2: Assemble Pressurization Plug
With Rubber Stopper snuggly secured in a vice, widen existing hole in #3 Rubber Stopper using 3/8 inch bit and an Electric Drill. It is important to not over widen the Rubber Stopper hole.
Insert Tire Value into the #3 Rubber Stopper so that the Schrader Value will protrude on the wider end of the #3 Rubber Stopper. I found that rubbing a little liquid dish soap on the value and “persuading” it with a Rubber Malt helps with the insertion process.
Step 3: Assemble Launch Pad Clamp Bracket and Hinge
Using a Hack Saw, cut 1-1/4 inch Punched Angle to two 8 inch lengths. Ensure you remove all the rough and sharp edges with a metal file to reduce risks of being cut.
Using a 1/4 inch X 3/4 inch Machine Screw, 1/4 inch flat washer, 1/4 inch split washer, and 1/4 inch nut combination, affix the Punched Angle to the 4 inch hinge using the two outer hinge screw holes ensuring the Punched Angle is centered to the hinge. Do this for both hinges ensuring a mirror configuration of the Punched Angle to the hinge.
Step 4: Launch Pad Base Preparation
Cut one 2X4 Pressure Treated Lumber to 16 inches long; this will become the Launch Pad Base.
Cut two 4X4 Pressure Treated Lumber to 16 inches long; this will become the Launch Pad stabilization feet.
Identify center point of Launch Pad Base Pressure Treated Lumber and mark with pencil.
Step 5: Launch Pad Base Pressurization Plug Housing Rough-in
Drill a small pilot hole (~3/32 inch bit) into the center point of Launch Pad Base (2X4X16 Pressure Treated Lumber) ensuring pilot hole goes completely through.
Drill 1 inch hole centered on pilot hole ~1/8 inch deep using Spade or Forstner bit into the top of the Launch Pad Base; this is to start the Pressurization Plug Housing hole enough so that you can continue to remove move material during a future step.
Drill 1-5/8 inch hole centered on pilot hole ~1/8 inch deep using Spade or Forstner bit into the bottom of the Launch Pad Base; this is to start the Bicycle Pump Hose Head hole enough so that you can continue to remove move material later during a future step.
Drill out completely the initial Launch Pad Base center pilot hole with a 3/8 inch bit.
Step 6: Launch Pad Base Pressurization Plug Housing Tuning
Take the Pressurization Plug and insert it into the 2 Liter Bottle; do not over penetrate the plug into 2 Liter Bottle pour nozzle. In my trials, the Pressurization Plug Rubber should penetrate about 3/8 inch into the 2 Liter Bottle pour nozzle.
Place assembled Pressurization Plug and 2 Liter Bottle into the drilled out 1 inch Pressurization Plug Housing hole on top of the Launch Pad Base.
Unfold and align the Launch Pad Clamp assemble (hinge and angle metal) so that the lip of the Launch Pad Clamp is on top of the 2 Liter Bottle neck rim and flush to the 2 Liter Bottle neck.
The Launch Pad Clamp should be perpendicular to the 2 Liter Bottle when positioned over the 2 Liter Bottle neck rim; if not, carefully remove additional material from the Pressurization Plug Housing hole with the 1 inch Spade or Forstner bit until perpendicular alignment is obtained.
Note: I found that drilling out ~7/16 inch of material is usually the right amount; however, I would recommend taking the time to fine tune the depth of the Pressurization Plug Housing for your build. Also note that not all 2 Liter Soda Bottle are the same and there may be small variation between soda manufactures and brands.
With the Pressurization Plug still inserted into housing (it does not need to be attached to the 2 Liter Bottle), turn Launch Pad Base over, and note the amount of material that needs to be removed from the bottom of the Launch Pad Base to have the Pressurization Plug Schrader Value protruding completely so that the Bicycle Pump Hose Head can be secured properly. Using a 1-5/8 inch Spade or Forstner bit and electric drill, remove the necessary material. You should be able to clasp the Bicycle Pump Hose Head completely onto the Pressurization Plug Schrader Value.
Step 7: Fastening Launch Pad Clamps to Launch Pad Base
With the assembled Pressurization Plug and 2 Liter bottle assemble in the “tuned” Pressurization Plug Housing (ensuring a perpendicular position to the Launch Pad base), tightly butt up both Launch Pad Clamps halves to the 2 Liter Bottle.
While ensuring the Launch Pad Clamps halves are centered on the Launch Pad base, mark drill holes for the two inner holes of both hinges on the Launch Pad Base.
Drill a small pilot hole (~3/32 inch bit) into each of the marked Launch Pad Base hinge holes ensuring pilot hole goes completely through.
Drill 1/2 inch hole ~1/4 inch deep using Spade or Forstner bit into the bottom of the Launch Pad Base where the four hinge pilot holes punched through.
Drill out completely the four initial hinge pilot holes with a 1/4 inch bit.
Using a 1/4 inch X 2 inch Machine Screw, 1/4 inch flat washer, 1/4 inch split washer, and 1/4 inch nut combination, thread machine screws through Launch Pad Clamp Hinge to Launch Pad Base.
Using a Philip Screw Driver and Socket Ratchet, tighten all four machine screws. Do not over tighten to the point the hinge does not swing relatively freely.
Step 8: Place the Launch Pad Clamps Under Return Spring Tension
Using Vinyl Bumpers, remove the adhesive backing and place 3 bumpers strategically around on the inner bottom hinge plate on both Launch Pad Clamp halves; this is used to damper the return spring force of the Launch Pad Clamps on release.
Using Allen Wrench provided with the hinge kit, place the Launch Pad Clamp hinge spring under slight tension and insert Pin into Spring Pin Housing. I found that tension on the first setting appears to have sufficient retraction force.
Repeat process on second Launch Pad Clamp hinge.
You should be able to pull the two Launch Pad Clamp halves together, release, and have them snap back down.
Note: Make sure you watch your hands and other body parts; these hinges with the metal brackets come down with force and can cut you badly if not careful.
Step 9: Secure Stabilization Feet to Launch Pad Assemble Base
Center Launch Pad Stabilization Feet (4X4X16 inch Pressured Treated Lumber) underneath the Launch Pad Base so that the Stabilization Foot is perpendicular, centered, and flush to the end of the Launch Pad Base. Fasten with two 2-1/2 inch Deck Screws.
Repeat for other Stabilization Foot on the opposite end of the Launch Pad Base.
Step 10: Affix Velcro Launch Pad Clamp Release Strap
Wrap Velcro 23 inch X 7/8 inch strap around one arm of the Launch Pad Clamp ensuring it is feed through the loop end of the Velcro Strap. It is recommended to use the Launch Pad Clamp arm on the opposite side of the Launch Pad Base Bicycle pump head cut out.
Tie #18 Twisted Mason Line to other end of the Velcro strap.
Step 11: Bicycle Pump Optional Step: Disassemble Bicycle Pump
Note: This step is not necessary if you are planning on using an unmodified off the shelf bicycle pump.
Remove Pump Hose from Pump by unscrewing the Hose Nut from the Hose Housing; it may be necessary to use a pair of pliers to loosen the Hose Nut.
Note: When the Pump Hose is removed, the Pump’s Check Value Disc will be free floating; make sure you do not lose it.
Using a pair of Needle Nose Pliers, remove the Check Value Vent from the Pump Hose by gently grasping vent and rocking while prying outward.
Slide off the Pump Hose Nut off Pump Hose.
Step 12: Bicycle Pump Optional Step: Assemble Bicycle Pump Hose Extension
Note: This step is not necessary if you are planning on using an unmodified off the shelf bicycle pump.
Slide the Pump Hose Nut onto one end of the 3/8 inch X 1/4 inch X 20 feet Clear Vinyl Tube; make sure you orientate the Pump Hose Nut in the right direction.
Insert the extracted Check Value Vent into the end of the 3/8 inch X 1/4 inch Clear Vinyl Tube.
Wrap the end of the 3/8 inch X 1/4 inch Clear Vinyl Tube containing Check Value Vent with about 4 layers of Electrical Tape. Electrical Tape is used to provide additional thickness to the Clear Vinyl Tube so that it seats better in the Hose Housing when the Pump Hose Nut is screwed down.
Insert the Clear Vinyl Tube end with Check Value Vent into the Check Value Hole; ensure that the Pump’s Check Value Disc was still present. Screw down the Pump Hose Nut back onto the Check Value Housing until tight. If you are able to pull up (gently) on the Clear Vinyl Tube and feel it unseat slightly from the Check Value Hole within the Hose Housing, apply an additional layer or two of Electrical Tape on the Clear Vinyl Tube.
Step 13: Bicycle Pump Optional Step: Reattach Bicycle Pump Hose & Head
Note: This step is not necessary if you are planning on using an unmodified off the shelf bicycle pump.
Insert the 1/4 inch PP Standard Check Valve into the original Bicycle Pump Hose & Head with the valve allowed directional flow towards the Pump Hose Head. If you are unsure which way the Check Value directional flow is, simply try to blowing air through it.
Insert the other end of the 1/4 inch PP Standard Check Value into the free end of the 3/8 inch X 1/4 inch Clear Vinyl Tube.
Note: I did not find it necessary to secure the Clear Vinyl Tube ends with an additional clamps; the barb on the 1/4 inch PP Standard Check Valve seemed to be sufficient.
Step 14: 2 Liter Bottle Water Rocket and Launcher Pad Operation
Unroll the modified Bicycle Pump Clear Vinyl Tube with the Pump Hose Head within reach of the Launcher Pad Base.
Unroll #18 Twisted Mason Line attached to Velcro strap about 20 feet from Launcher Pad Base.
Turn assembled Pressurization Plug and 2 Liter Bottle upside down and place it into Launch Pad Base Pressurization Plug Housing.
Attach and secure the Bicycle Pump Head to the Pressurization Plug Schrader Value.
Grasp, rotate upward, and hold the Launch Pad Clamp halves so that the lips of both Launch Pad Clamp halves are on top of the 2 Liter Bottle neck rim and flush to the 2 Liter Bottle neck. Make sure you hold Launch Pad Clamps tightly and securely.
Using the Velcro 23 inch X 7/8 inch strap, tightly wrap the Velcro strap over the top of the other Clamp overhang and back underneath onto Velcro’s starting point. Ensure there is enough Velcro overlaps to securely hold the Launch Pad Clamp tension.
Double check to make sure the 2 Liter Bottle and Launch Pad Clamp are secure and also make sure that everyone is clear.
Note: Too little pressure and the 2 Liter Bottle may not eject the Pressure Plug and not lift off. Too much pressure and the Launch Pad Clamp will slightly give causing Pressure Plug to give, and pressure will release premature or more seriously the 2 Liter Bottle may fail.
When ready to Launch, pull on the #18 Twisted Mason Line “unzipping” the Velcro strap. This will cause the Velcro to pull away allowing the Launch Pad Clamp to retract; once the Launch Pad Clamps retract, the 2 Liter Bottle should have sufficient pressure to eject the Pressure Plug. With the Pressure Plug extracted, the 2 Liter Bottle will thrust pressurized water downward causing the 2 Liter Bottle to lift off.
Step 15: Safety and Additional Notes
You are going to want to experiment with different 2 Liter Bottle water and air pressure levels. Roughly 1/3 (~675ml) to 1/4 (~500ml) full of water and 10 good pumps was about sweet spot for me. Too little pressure and the 2 Liter Bottle may not eject the Pressure Plug and not lift off. Too much pressure and the Launch Pad Clamp will slightly give causing pressure to release premature or more seriously the 2 Liter Bottle may fail. If you find yourself where you put too much pressure into the 2 Liter Bottle and it starts to leak from the Pressure Plug, just launch the device as safely and quickly as possible.
I cannot emphasize enough that you need to keep your body parts away from this thing when it is being pressurized, alarmed, or launched. If you are using an unmodified bicycle pump with a short hose, get as far back as you can and make sure your head is not above the 2 Liter Bottle.
If you find yourself in a situation where you inserted too little pressure and the Launch Pad Clamps have been released, just give the Bicycle Pump a couple more pumps; the added pressure should knock the Pressure Plug lose. Do not go over to the Launch Pad and tap the 2 Liter Bottle or Launch Pad Base; you risk knocking it lose and getting pegged with it.
If you feel like pressure is escaping from between Pressure Plug and the 2 Liter Bottle when only moderate pressure exists, either the Launch Pad Clamp is not tight enough and/or the Pressure Plug is not insert far enough. Modified as needed to resolve.
If you believe that you over drilled the Pressure Plug Housing in the Launch Pad Base and that is causing the Pressure Plug to not sit securely against the Launch Pad Base when Launch Pad Clamps are engaged, you can drop a washer or two into the Pressure Plug Housing underneath the Pressure Plug. Just make sure the washer is small enough to fit into the Pressure Plug Housing and the washer has a center hole large enough to allow the Schrader Value to slip through.
If the Velcro strap holding the Launch Pad Clamp together does not release smoothly, double check that you have wrapped the Velcro strap over the top and underneath the Launch Pad Clamp arms allowing the pull of the Twisted Mason Line to back track the Velcro wrap smoothly.
If the Launch Pad Clamp do not release quickly and smoothly, increase the hinge return spring tension. If you accidently lose the Hinge Tension Spring Pin, you can usually use a finishing nail as a suitable replacement.
After initial repeated use, you may find that the through-hole in the Pressure Plug Housing for the Schrader Value may become too tight due to lumber swell from exposure to water. Using a 3/8 inch drill bit, just re-drill it out.
Be Safe and have Fun!!!
