Hi all,
I have just been given an Uninteruptable Power Supply. Great! One drawback, no cables!
It needed:
1 x USB to RJ50 cable
RJ50 cables look like normal ethernet RJ45 cables but have 10 pins not 8.
At least 1 kettle lead with a male connection one end and a female connection the other.
I looked at making a cable, but i would need an RJ50 plug. That wouldn't do! I will replace the socket instead.
Step 1: Popping It Open
I popped it open to see if adding/replacing the data port was a viable option.
Step 2: Removing the Rear Facia
Step 3: Cable Layout
Step 4: No Idea What This Port Is For, But Thr RJ50 Socket at the Bottom in Black
Step 5: The Board Completely Removed
Step 6: Underside of Board Where the Socket Is Soldered In
Pinout
SOCKET END
2 4 6 8 10
1 3 5 7 9
BOARD END
SOCKET END
2 4 6 8 10
1 3 5 7 9
BOARD END
| APC Pin | USB Pin | Description |
|---|---|---|
| 1 | 1 | USB +5V (red wire) |
| 4 | shield | chassis ground |
| 7 | 4 | USB GND (black wire) |
| 9 | 2 | USB Data- (white wire) |
| 10 | 3 | USB Data+ (green wire) |
Step 7: Adding the Printer USB Socket
http://image.pinout.net/pinout_USB_files/connector_pinout.php?image=usb_typeB_receptacle.gif&pinout=%20printer%20cable
2 1
3 4
1= +5v (Red)
2= D- (White)
3= D+ (Green)
4= GND (Black)
Step 8: Soldered Wiring
| APC Pin | USB Pin | Description |
|---|---|---|
| 1 | 1 | USB +5V (red wire) |
| 4 | shield | chassis ground |
| 7 | 4 | USB GND (black wire) |
| 9 | 2 | USB Data- (white wire) |
| 10 | 3 | USB Data+ (green wire) |
Step 9: Trimmed Case for Socket Access
