Arduino Pulse Sensor

This is my first project published here, An arduino pro mini board with Pulse Sensor.

Here I will show you how I did my arduino wiring and coding, including the source code and schematics. Also I coded a windows tool to show the wave form from arduino and pulse sensor via UART.

Of cause It can run independently without connecting to PC. You can make it wearable, like a ring, or attach on head....etc. To show how fast your heart-beat is, how nervouse you are, with RGB Led indicating should be intestering.

Step 1: Step1 : Parts List

USB_To_TTL x1 Used to upload the code to Arduino ProMini / Receive pulse data from Arduino to PC

Arduino ProMini x1 Control Blink Blue Led and Heart Beat indication RGB LED with data from pulse sensor

Pulse Sensor x1 Attached to Arduino Pro mini to get the heart beat pulse data。

Common Cathod RGB LED x1 Indicating the speed of heart beat ratio. Red(Fast) -> Green -> Blue(Slow)

Blue LED x1 Blinking while heart-beating。

Step 2: Step 2 : Schematic

The upper image shows how to connect USB-TTL to Arduino Promini. the lower show how to connect pulse sensor, blue led, RGB led to Arduino Promini.

Step 3: Step 3 : Upload Code.

Open Arduino IDE, load arduino code and upload them to Arduino ProMini.

There is also a document here in Chinese.

All souce code, schematics, paper download here

https://www.dropbox.com/sh/iy5nacruhfk7c28/AADUfQW...

More projects and freewares here

http://www.rasvector.url.tw/hot_91270.html

Other Arduino Projects

Comments

[DionT2]

hi, i have been using pro mini with the heartbeat sensor, but the problem that i encounter is that the pro mini detects random heartbeat even there is none. do u know why ? this problem never happen when I use arduino uno

[Daniel Lu]

Yes, there always be noise. Check my arduino code and you will see how I filter it out. Then, revise the code to match your sensor.

[nur safira]

hye, i want to know how to get the raw data pulse sensor?

[Daniel Lu]

Don't really understand what you mean. All the details in arduino code and you can see how I get the data.

[Daniel Lu]

What kind of raw data you need? All the schematics, aruduino source code are all included in the dolowlad package.

[DIY Hacks and How Tos]

Great looking pulse sensor project. I have been wanting to make one of these as part of a DIY health monitoring system.

[Daniel Lu]

Glad you like it.
