Introduction: How to Connect Arduino and RFID

On this instructable I will try to show how to interface a RFID sensor with the Arduino. I am using the RFID sensor from seeedstudio the serial version of it. There are a few parts you will gonna need. I also bought some RFID keys.

UPDATE: Now it works with IDE 021

Step 1: What You Gonna Need?

- Arduino Board
- RFID Sensor from seeedstudios
- Wires
- Protoboard
- RFID tags (125kHz) from seeedstudios

Step 2: Plugging All Together

Connect the antenna on the appropriate pins like the first photo.

Plug the RFID sensor to the protoboard like the second photo above.

Only 3 wires are required to interface, 2 wires for supply and another for the serial line(communication)
The wires as connected as the third photo shows.
On RFID sensor: PIN 1 -> Tx
PIN 2 -> Rx (Not Used)
PIN 3 -> NC
PIN 4 -> GND
PIN 5 -> VCC (+5V)

Tx from RFID board goes to Digital PIN 2 on Arduino Board.

That is all you gonna need to wire.

Moving on to next step, the software.

Step 3: The Code

I'm not a software guy, so this code is just for demonstration.

I don't make any kind of checksum at the tags code, but it seems to work fine.

The code is really simple. I used a new library for the serial, using software emulation.

With the two white cards you can deny or allow the access of others keys.

Any doubt, please ask me.

Edit (05/11/12):
code update for new Arduino version

Step 4: Results!

There is no LED, sound or LCD for debug or visualization, just through the serial line.

The video demonstrate how to use the software. I didn't post any kind of explanation as text on the video. I hope that the images spokes more then words, xD

Any doubt or suggestion, feel free to ask, or correct me.

Please, if you like it, rate it,

thank you


1 Person Made This Project!

Recommendations

  • Battery Powered Contest

    Battery Powered Contest
  • Plywood Challenge

    Plywood Challenge
  • Plastic Contest

    Plastic Contest

184 Discussions

0
epidemicz
epidemicz

11 years ago on Introduction

Thanks for the instructable man, really appreciate it.  I've been wanting to do something with rfid and this is going to help me out big time.

0
otaviousp
otaviousp

Reply 11 years ago on Introduction

Nice, thank you for the positive feedback. xD

0
GiovanniC84
GiovanniC84

Question 1 year ago on Step 1

Do yo know where I could find something similar for 134.2 kHz ? I have a Raspberry Pi and I would like to be able to clone the RFID in the key of my car.

0
nugax1
nugax1

2 years ago on Step 3

Sorry, but the code doesn't work as expected.
Attached find my version which does what it should do.
/*########################################################################
## Modified code to work with Arduino 1.0.1 / ##
## Credits to Petushka, https://www.instructables.com/member/Petushka/ ##
## https://cdn.instructables.com/ORIG/FM4/KU9W/H91LGBA6/FM4KU9WH91LGBA6.txt
########################################################################*/
#include <SoftwareSerial.h>
#define ADD_TAG_CODE "bfbdbfa57de717a0" //change this ID with your own card TAG (2)
#define DEL_TAG_CODE "bfbdbfa5899d5420" //change this ID with your own card TAG (1)
SoftwareSerial rfid = SoftwareSerial(2, 3,true);
String msg;
String ID ; //string to store allowed cards
void setup()
{
Serial.begin(9600);
Serial.println("Serial Ready");
rfid.begin(9600);
Serial.println("RFID Ready");
}
char c;
int i;
void loop(){

while(rfid.available()>0){
i=rfid.read();

msg += String(i,HEX);
Serial.print(i,HEX);
Serial.print(" - ");
Serial.println(msg.length());
}
// msg=msg.substring(0,15);
if(msg.indexOf(ADD_TAG_CODE)>=0) add();
else if(msg.indexOf(DEL_TAG_CODE)>=0) del();
else if(msg.length()>10) verifica();
msg="";

}// Ende von Loop ----------------------------------------------------------------------------
void add(){
Serial.print("What TAG do you wanna grant access?: ");
msg="";
while(msg.length()<16){
while(rfid.available()>0){
i=rfid.read();
msg += String(i,HEX);
}
}
if(ID.indexOf(msg)>=0) {
Serial.println("\nAccess already granted for this card.");
msg="";
}
else{
Serial.print("Card: ");
Serial.println(msg);
ID += msg;
ID += ",";
//Serial.print("ID: ");
// Serial.println(ID);
msg="";
Serial.println("Access granted for this card.");
}
}//---------------------------------------------------------------------
void del(){
msg="";
Serial.print("What TAG do you wanna deny access?: ");
while(msg.length()<16){
while(rfid.available()>0){
i=rfid.read();
msg += String(i,HEX);
}
}
msg=msg.substring(0,15);
if(ID.indexOf(msg)>=0){
Serial.println(msg);
Serial.println("TAG found. Access for this card denied.");
//ID.replace(card,"");
int pos=ID.indexOf(msg);
msg="";
msg += ID.substring(0,pos);
msg += ID.substring(pos+15,ID.length());
ID="";
ID += msg;
//Serial.print("ID: ");
//Serial.println(ID);
} else Serial.println("\nTAG not found or already denied");
msg="";
}//--------------------------------------------------------------------
void verifica(){
Serial.println(msg);
msg=msg.substring(0,15);
if(ID.indexOf(msg)>=0) Serial.println("Access granted.");

else Serial.println("Access denied.");
}

0
