Build Basic Frame for Mini Pilot Plant or CNC




Introduction: Build Basic Frame for Mini Pilot Plant or CNC

About: Projects, Articles & tech reviews for Home & Industry


* Este proyecto tambien esta disponible en Español haciendo clic aqui

The vast majority of pilot plants are experimental, this means they could be moved, some of their parts could be changed or modified, or being part of an educative kit and must be disassembled, stored or transported easily as a part of the learning process.

For more info visit:




As mentioned earlier the structures are based on slotted profiles and connecting accessories. The best way is to seek for this stuff in local markets: specialized stores, hardware stores, DIY stores, etc. If there are no similar things in local markets, the next step is Internet to get the products. Being metallic objects of relative high weight, shipping costs from overseas are usually high. However, browsing a bit, sometimes there are pre-cut kits (usually to make DIY 3D printers) with a good price and free shipping worldwide !


The chosen accessories must be compatible with the corresponding slotted profile (T-slot, MicroRax, etc.) and the size of the profile, because are available in multiple sizes (10 series, 20 series, etc.). At this point there is a lot of flexibility because a lot of parts from local stores could be used.

Here is a list with the lowest cost possible with shipment worldwide:



To build a robust frame, but at the same time easy to disassemble, there is an available solution known as "modular aluminum structural system". This modular system is basically extruded slotted aluminum profiles with compatible accessories for fixation. There are a lot of manufacturers like 80/20, MakerSlide, MiniTec, etc. Some of them are compatible with other systems, some of them no. Metric and inches profiles and accessories are available. These systems became very popular in the last years due to the DIY CNC and 3D printers boom.

Step 3: ​L Shaped Plates, Allen Screws and T Sliding Nuts

L shaped plates, Allen screws and T sliding nuts

These plates are very common in hardware or home related stores, Allen screws are used and some sort of squared or T sliding nut compatible with the screw, and able to slide into the profile's slot. It's the least elegant solution aesthetically speaking, but the easiest to get.

Step 4: ​Corner Bracket Gussets , Allen Screws and T Sliding Nut

Corner bracket gussets , Allen screws and T sliding nut

This alternative could be explored if 90 degree metallic or hard plastic gussets are available, again Allen screws and T sliding nuts. Due to the dimensions of the gussets, screws with big heads can't be used.

Step 5: ​Internal L Shaped Joint Connector and Headless Allen Screws

Internal L shaped joint connector and headless Allen screws

This last option uses pieces exclusively designed for this type of profiles, aren't common in local hardware stores, but could be bought on the Internet for a very good price. This is the best visual option, because union joints are practically invisible.



-Cut the profiles to the desired length as precise and clean as possible.

-Work on a hard surface

-Get the Allen key for the respective used screws

-Verify with a Set square the angles (should be 90), and verify there is no gap between the profiles

-Don't screw the bolts too tight initially, probably they have to loose slightly later to make adjustments

For more info visit:

Be the First to Share


    • Bikes Challenge

      Bikes Challenge
    • Remix Contest

      Remix Contest
    • Make it Move Contest 2020

      Make it Move Contest 2020

    2 Discussions


    4 years ago

    This extruded aluminum is most frequently call T-slot instead of "modular aluminum structural system". The link below is a basic catalog of the different struts and mounting hardware that is available.


    Reply 4 years ago

    Is there any alternative way of making a clean similar frame? The price of extruded aluminium products are quite high for me.
