Introduction: Cardboard Cable Car Model How to Make With Recycled Materials, Working Model 250rpm Electric Motor & Basic Slide Switch ON-OFF-ON Science Project
You can show this cardboard model as an enjoyable school project. At the same time learn the working principle of a cable car by building it.
Supplies
• 1pcs 25*35cm 5mm Cardboard for project Ground
• 8pcs popsicle stick (15cm)
• 2pcs Plastic Pulley Wheel (Recycled from old CD/DVD burner)
• 1pcs DC BO Motor (6V)
• 7x4x3cm cardboard Block (Stacked 6pcs 4*7cm cardboard)
• Plastic Bottle Cap
• 4pcs Match
• 1pcs Battery Holder
• 1pcs DPDT On-Off-On Slide Switch
• Passengers (Optional)
• Nylon yarn
• 1pcs thin nail
Step 1: Mounting Pulley Wheel on Motor Shaft
You can check all steps on video briefly or follow below steps.
• Mount plastic pulley wheel onto DC motor shaft and glue on it.
Step 2: Glue Popsicle Stick for Pulley Holder
Glue the popsicle sticks on top of each other.
1 set of 4 sticks will be glued on top of each other.
2 sets of 2 sticks will be glued on top of each other.
Step 3: Plastic Pulley Wheel Holder Assembly
Glue the popsicle sticks together in the form of a slingshot, keeping the group of 4 in the middle.
Step 4: Drill a Hole on Slingshot
Drill a hole on slingshot shaped holder for plastic pulley.
Step 5: Mount Plastic Pulley on Slingshot
Mount plastic pulley wheel with a nail between slingshot arms.
Step 6: Motor Base
Glue cardboard block onto base left side.
Step 7: Motor Assembly
Glue 250rpm 3-6V DC motor onto cardboard block.
Step 8: Pulley Holder Mount
Glue pulley holder slingshot onto plastic bottle cap to increase height.
Glue pulley holder slingshot onto right side of base.
Step 9: Thread Tension Control
Knot the rubber band and cut it.
Step 10: Attach Tension Control Onto Yarn
Tie the rubber band together with nylon thread.
Step 11: Attach the Cable
Tie the yarn between the pulleys by adjusting the tension with the rubber band.
Step 12: Soldering System
Solder the wires onto the 6 pin slide switch for forward and reverse movement.
Step 13: Motor Soldering
Solder the cables coming from the middle pins of the slide switch to the motor pins.
Step 14: Battery Attachment
Solder the cables from the other ends to the pins on the battery holder.
Step 15: Cable Car Cabin Assembly
Cut away 4pcs Match heads.
Prepare 2pcs 4x3cm 3mm cardboard and glue Matches on the corners.
Don't forget the Passengers 🤪
Step 16: Cut Cabin Hanger 30º Angled
Cut ~30º Angle Holder for Cable Car Container
Step 17: Glue Hanger
Glue the angled cabin hanger onto the cabin
Step 18: Hanger Attach
Attach the cabinet to the rope
Step 19: Play and Fun
Start the cable car by moving the switch back and forth, have fun 👏👏👏👏
