Introduction: DIY Mini Drill
Hi guys, this is my first instructable, my english is bad, I take terrible photos, so... :)
In this tutorial I will show you how to make a cheap drill.
Materials
-Compasses
-DC motor
-Terminal block
-Wire
Note: I found that the diameter of the compasses' leg's are 3mm in most cases. So try to find a motor with a 3mm axle, and the holes on the terminal should be 3mm too. With a 3mm terminal you can use any dremel tool, if you replace the "chuck".
Tools
-Screwdriver
Not necessary:
-Electrical tape
-Plier
-Saw
-File
Step 1:
Take apart the compasses, we need the component marked on the picture.
Actually, it is a mini chuck. :)
Step 2:
Now take apart the terminals with a knife. Remove the plastic, we only need the inner metal part.
Step 3:
Mount it on the motor.
Step 4:
Insert the compasses leg into the hole.
I replaced the screws with newer ones.
Step 5:
Now we are ready. :) If you want you can solder wires and a switch to it. I didn't solder them, because I use it with crocodile clips.
You can easily use 2-2.5 mm drills, for the smaller ones you need to put on some electrical tape or thin wire to the drill to fit in the chuck.
Step 6:
Now try it on an old PCB, or something else.
I give 12 volts to it from an old ATX psu.
Step 7:
Here is my first DIY drill, I made it before the instructable. Actually it is the same, but I mounted a push button to it, and I put on some electrical tape so it is more ergonomic. :) I made this for only PCB drilling so this is why the the drill bit is so short.
Step 8: One More Thing - New Screws for the Terminal
So I decided to add more steps, to make our drill better.
Finishing touches...
I didn't like the old one with the two long screws, so I made two mini screws.
First of all, find a screw which fits in your terminal. Put it into a vise or grip it with a plier.(I don't like the original screws, they are "weak")
Then take a saw and cut them or you can use your DIY drill :) - fortunately, all of the dremel tools fit in the terminal.
Step 9: One More Thing
Then cut a small line on the top of the screws.
Step 10: Last Thing
Last step, I promise. :)
Not necessary, but you should do this. Take your mini chuck (the compasses' leg), and place it in a vise or grip it with a plier. Then we need a small metal or diamond file, and you have to make a small flat area on the chucks axle. (The reason why I did this - the screws in the terminal will provide a better grip on a flat area than on a circular axle)
Step 11: The Finished Drill
Now we are ready, I guess. I think it looks better.
Step 12: The Finished-finished Drill
I found a small plastic tube and my motor perfectly fits in it. :) Then I put on some heat shrink pipe, so now it is indeed finished.
