Heart Reactor (Anahat Chakra)

Jai Hind all of You !

This is basically a Heart Reactor placed on our Anahat Chakra. I was wondering from ECG sensor then i though i should make a creative thing with it, and it must be werable. Althoug it is inspired by Arc Reactor obviously but i have change a little bit convept !

It reacts according to your Heart Rate using AD8232 ECG sensor and i have created a small Heart in that light travels according to RA, LA, RV, LV... Yes according to your PQRSTUV waves.

So lets Starts !

Supplies

You will need below materials !

Supplies

1 AD8232 ECG Heart Rate Sensor

1 PCB for Hear Circuit Wires Ardiuno Lithium Battery 5 to 9 Volt Box for Ardiuno

1 Circular Box 2 One way Mirrors 1 Glass Cutter Black Tape

Red and Yellow Leds 10 to 15 apx 1 k resistance for Leds

1 Black Belt (3 Mtr)

Soldering Machine Glue Gun + Glue Sticks Forcep Fabric or Water Color

Printed Anhat Chakra (Image Given)

and Other tools you may use to improve or as required !

Step 1: Step 1: Creating Heart Circuit

Take a white paper and draw 3 x4 cm Heart shape roughly to cut PCB.

Then mark on PCB and cut it as per shape.

Take 4 Leds for RA, LA, RV and LV !

Arrange and connect all 3 Leds and 1 Yellow Leds as givne in the images

Step 2: Step 2 : Creating the Circular Circuit

To make more creative we have to make a circular circuit you may use your creativity !

To do this take a Hard paper strip around 1.5 cm and arrange and connect 3-4 red and yellow leds with resistance as required.

Step 3: Step 3 : Wiring, Connections and Coding

Then Connect all the wiring as given into the Code !

Step 4: Step 4 : Glass Cutting According to Circular Box

Take a circular box with apx 9 cm width and 4 cm height to arrange all the thing in it.

Take two one way mirrors and cut a circular shape according to the box.

Be catious when working with glass !!!

Step 5: Step 5 : Making It Wearable

Take a black belt around 3 meter and arrange and connect as given !

Step 6: Step 6 : Creating a Small Heart Model

Create a heart as given step by step using Glue stick ! Explore your creativity .

Step 7: Step 7 : Arranging All in the Circular Box and Testing !

Arrangne all the thing in the Box as given !

Step 8: Step 8 : Preparing the Cap of the Circular Box

Cut the cap and attach the mirror in the cap .

Step 9: Step 9 : Taping and Decoration

Hereuse your creativity i used black tape and a Anahat Chakra Image to decorate it !

and Test it !!

Step 10: Step 10 : ECG Sensor Connections (Wearing It Properly)

Connect ECG sensor

Red one for Right Chest

Yellow one for Left Chest

and

Green one below right stomach !

and and Power the Ardiuno and Voila !!!!

Play with Heart Reactor !!!
