High-Tech Spy Stethoscope!

75,299

190

52

Introduction: High-Tech Spy Stethoscope!

About: Tinkerer, hackster and prankster. Hit me up on Facebook: https://www.facebook.com/kipkayvideos/ Thanks for checking out my Instructables!
Hear through walls AND record what you hear with this High-Tech Electronic Spy Stethoscope for under $25! See the Test Results in the Video!



Step 1: What You Need...

1) Stethoscope. I picked mine up at a local drug store (Walgreens) for $10
2) A pair of Stereo Multimedia Microphones. Chosen because of the low cost and decent specs. $12 on Ebay.
3) 3.5mm (mini) Stereo Y-Adapter. ($0. I had one laying around but they are probably a couple of bucks)

Step 2: Disassembly...

I disassembled the multimedia microhones using an X-Acto knife and assorted tools. I cut it down the middle to get to the cabling and also popped the top off the header to get the mics out. I ended up with 2 mics and 3.5mm connectors.

Step 3: Stethoscope Disassembly...

Remove the earpieces from the Steth. Then I drilled out the earpieces to the diameter of the mic housings. I used a Dremel with a grinding attachment to fine tune it.

Step 4: Reassembly...

I used a small dot of hot glue and inserted the microphones into the earpieces and then reassembled the earpieces on the Stethoscope.

Step 5: Final Results!

After plugging the two 3.5mm connectors into the Y-Adapter and then plugging the single stereo connector into my MP3 player, I was ready to test it out! Check out the video! Hope you like it and give it a try!
