How to Construct a (paper Prototype) Multilayered Viewing Device for IPhone.(I3DG)

This is my first instructable on how to create a iphone hologram device. This model is made out of paper but instructions on how to build the device out of acrylic (plastic) is in another instructable. This paper model is a prototype for this. I decide to create this model as no other websites have instructions on how to build or buy it. This model was designed on the I3DG. I hope you have as much fun making this and amazing your friends as i did creating this model. This model uses peppers effect of using three, 45 degree, semi-transparent mirrors to lay the segmented image on your iphone/ipod touch one in front of each other.

Step 1: Cutting Out

cut out all peices as shown

Step 2: Creating the Box

fold sided 2 times so they meet. glue together here

Step 3: Finishing Box

fold all 3 tabs on back of box then cover in glue. Afterwards fold back down so the numbers match up.

Step 4: Adding Side Supports

fold tabs to 90 degrees and glue. Attach tabs to matching numbers.

Step 5: Sticking on Cover to One Side

attach tabs to matching numbers and glue in place.

Step 6: Completing the Other Support

do exactly the same and stick the tabs to the matching number. your model should look like this:

Step 7: Mirror Attachment

attaching the paper where the mirrors will be is not easy. match the numbers up and glue in. If your model is out of line trim a bit off the front.

Step 8: Completed Model

Well done. Because this is my first instructable so if you have any questions just ask me in a comment!

Step 9: Testing for the Acrylic Model

In order to get the best results i have experimented with diffrent parts of the model and here are some pictures, discriptions and videos to show you the testing i have done.

Step 10: Images for the Acrylic Version
