I love working with 2020 aluminum extrusion and designing CNC, 3D Printer, Plotter etc. And always I need light source to see on my work. I've prepare a PWM LED controller PCB with NE555 timer IC and IRF540 MosFET transistor to use with 12V LED Strip.

Step 1: Part List

NE555D SOIC SMD 1pcs

IRF540S 1pcs

LL4148 2pcs

10nF0805 1pcs

100nF0805 1pcs

1K0805 1pcs

47R 0805 1pcs

50K-100K Potentiometer 1pcs

2020 Tnut & Screw 2set

2pin Terminal Block 2pcs

Step 2: Gerber Files

Gerber Files
