Introduction: RGB LED Matrix Text Scroller

About: Crazy and Creative (boredom side effects)

RGB LED battery powered (rechargeable) Matrix Text Scroller

Step 1: Crazy Idea

okay fine, I've seen a lot of scrollers around, none is RGB. due to boredom, i went and got some stuff to build it.

Step 2: Material

Shift register 74HC595 (x2)
Decade counter CD4017 (x1)
RGB led 4 pins common positive (x100)
Arduino Nano (x1)
jumper wires
1 KOhm resistors (x6)
NPN transistors 2N3904 (x6)
DIP Switch 9 modules (x2)
Soldering iron
Copper wires
Hot glue gun
Rechargeable 7.4V 1500mah NiCd battery (any battery between 7V and 15V will do a good job)
Resin or Plastic or whatever you can get to hold LEDs (i cut mine using Laser and 3 mm plexi)

Powerful headphones
Metal Music
Huge coffee (x3) prefered black (no sugar, no milk, no nothing)

Step 3: Assemble the "Screen"

Using Super Glue, i glued LEDs into the plexi board I've got earlier.
Then, using cooper wires amd soldering iron, i connected positive poles in order to connect it later on to Shift register output.
Remember, Shift Register (positive) Decade Counter (Negative).

Now, Screen is ready.

Step 4: Circuit Preparation and Assembly

After soldering Positive poles vertically of the LED (longest), solder each color (other poles) horizontally, in order to connect it later on to the decade counter.

I used jumper wires to connect columns to the shift register and CAT 5 cables for rows connection to the decade counter.

Now, each output of the Decade counter is used 3 times. using the Fork theory ( 1 input, many output. in my case, 1 input, 3 outputs).

each output of the decade counter is connected to 3 ports of the DIP switch, and using jumper wires, i connected for example, pin 1 to pin 2 and pin 3 of the DIP switch. Switch will manually change color of each row.

Step 5: NPN Transistors and 1KOhm Trick

Since the breadboard I'm using has a limited pin number, i had to go for a soldering trick between NPN transistors and 1KOhm resistors, so i soldered the resistor to the Collector pin (Middle pin) of the NPN transistor, in order to save pins.
Clever, but time consuming.

Emittor pin to the DIP switch, Collector from the decade counter, Base to Negative.

Step 6: Last Assembly

using an old schematic and an old program that i already used to build a huge 150cm × 60cm scroller, i assembled it the same way.
The only tweak was in the DIP switch.

(I will post the code and schematic later)

Et Voilà, a RGB LED scroller is born.

(Happy dancing Happy dancing Happy dancing)

Wait !!! where is my COFFEE !!!

Step 7: A Color-Mix Preview Hehehe

And it is working !!! (ignore the cigarette holder up there hehehe)
