Servo Positioning

Introduction: Servo Positioning

  • Arduino UNO
  • Servo Motor
  • 4X4 Membrance Switch Module
  • Jumper Wires

Step 1: Add Servo Motor

  1. Connect Servo Motor positive wire to 5v pin on Arduino.
  2. Connect Servo Motor ground wire to GND pin on Arduino.
  3. Connect Servo Motor signal wire to Digital Pin 10 on Arduino.

Step 2: Add 4X4 Membrance Switch Module

  1. Connect 4X4 Membrance Switch Module Pin 1 to Digital Pin 5 on Arduino.
  2. Connect 4X4 Membrance Switch Module Pin 2 to Digital Pin 4 on Arduino.
  3. Connect 4X4 Membrance Switch Module Pin 3 to Digital Pin 3 on Arduino.
  4. Connect 4X4 Membrance Switch Module Pin 4 to Digital Pin 2 on Arduino.
  5. Connect 4X4 Membrance Switch Module Pin 5 to Digital Pin 9 on Arduino.
  6. Connect 4X4 Membrance Switch Module Pin 6 to Digital Pin 8 on Arduino.
  7. Connect 4X4 Membrance Switch Module Pin 7 to Digital Pin 7 on Arduino.
  8. Connect 4X4 Membrance Switch Module Pin 8 to Digital Pin 6 on Arduino.

Step 3: Code
