Simple Wide Belt Sander for Wooden Strips

Introduction: Simple Wide Belt Sander for Wooden Strips

Material:

1 multilayer wood 230x300x15

1 multilayer wood 300x60x15

2 multilayer wood 70x25x15

1 hinge 50x40

1 screw M8x70

1 abrasive buffer

1 drill support

Step 1:

Mount the hinge on the two pieces of multilayer (70x25 & 300x60) like in the pictures.

Step 2:

Screw in the two previous pieces on the basis of 230x300 like in the pictures

Step 3:

On the opposite side to the hinge execute a threaded hole M8

Step 4:

Mount the abrasive buffer on the drill and place it. With two screws fix the support.

Step 5:

Fix at the base the second piece (70x25) in front of the Support. Fix the support with two screws.

Step 6:

Insert the screw in the hole at the base. This screw allows adjustment of the thickness.

Step 7:

Lock the drill in the support and check the parallelism between the abrasive buffer and the adjustable base.

Step 8:

The wide belt sander machine is ready. Perform small thickness reductions.
