TV REMOTE CONTROLLED APPLIANCES

THIS INTRUCTABLE IS ABOUT A INFRARED CONTROLLED HOME APPLIANCES USNG 4017 IC. THIS INSTRUCTABLES CAN BE EASILY MADE WITH BELOW GIVEN DECRIPTIONS. SO LET'S GET STARTED.....

Step 1: THING NEEDED

FOR MAKING THIS PROJECT YOU WILL NEED THE FOLLOWING PARTS-

-CD 4017 IC -1 NOS

- PCB - 1 NOS.

- BC557 - 1 NOS.

- BC547 - 1NOS

-100K RESISTOR - 1NOS

- 100 OHM RESISTOR - 1 NOS.

- RED AND GREEN LED - 1NOS.

- 5V RELAY - 1NOS.

-10UF/25V ELECTROLYTIC CAPACITOR - 3NOS.

-7805 - 1NOS.

-IR REMOTE.

- PENCIL CELL - 2 NOS. FOR REMOTE.

YOU CAN GET THESE ITEMS EASILY AT YOUR LOCAL ELECTRONIC STORE.

Step 2: THE MAIN CIRCUIT

FOLLOW THE ABOVE CIRCUIT DIAGRAM TO MAKE THIS PROJECT. AFTER MAKING THE CIRCUIT AS PER ABOVE DIAGRAM. ITS TIME TO TEST IT.

Step 3: Making 5v Power Supply

ABOVE IS THE CIRCUIT FOR MAKING POWER SUPPLY FOR POWERING THE CIRCUIT.FOLLOW THE CIRCUIT DIAGRAM AND MAKE IT.AFTER MAKING THE POWER SUPPLY CONNECT IT TO THE CIRCUIT AND TEST IT.

Step 4: Testing Time

NOW TIME TO TEST IT. it works..............THANKS.
