Introduction: Temperature and Humidity Sensor and Lcd

By

This instructable combines dht11 sensor with lcd 16*2.

Step 1: Gathering

The things you need are:

  • Arduino
  • DHT11 (humidity and temperature sensor)
  • LCD 16*2
  • USB cable
  • Breadboard
  • Jumper wires
  • Resistors

Step 2: Wiring

The required pining is
  • LCD RS pin to digital pin 12
  • LCD Enable pin to digital pin 11
  • LCD D4 pin to digital pin 5
  • LCD D5 pin to digital pin 4
  • LCD D6 pin to digital pin 3
  • LCD D7 pin to digital pin 2
  • LCD R/W pin to ground
  • LCD VSS pin to ground
  • LCD VCC pin to 5V
  • 10K resistor:
  • ends to +5V and ground
  • wiper to LCD VO pin (pin 3)
  • DHT pin to 10 (2nd from left on the sensor)
  • DHT pin 1 to Vout
  • DHT pin 4 to Gnd

Step 3: Programming

First you have to have arduino ide.

after that include the libraries given below:

  • lcd
  • DHT

After that upload the program given below to your arduino.

Attachments

Step 4: All Done!

WHen done it should look like this
