Touch ON - Touch OFF Circuit + Touch Toggle Circuit

Introduction: Touch ON - Touch OFF Circuit + Touch Toggle Circuit

This is a circuit which can be controlled by a Touch. Two input Touch pin pairs controls the circuit output – one pair turns the circuit ON, while the other turns it OFF.

The circuit can also be extended to toggle between two outputs, where the two touch pin pairs controls the two respective outputs.

Step 1: Components Required

These are the Components Required for making the Touch ON –Touch OFF circuit:

  • 555 Timer IC
  • Resistor: 330 Ω
  • LED
  • Touch Pins (4)

Other Requirements :

  • Battery: 9V and battery clip
  • Breadboard
  • Breadboard Connectors

Step 2: Circuit Diagram

These are the Circuit Diagrams for:

  • Touch ON – Touch OFF Circuit
  • Touch Toggle Circuit

Step 3: Step-by-Step Tutorial

This video shows step-by-step, how to build these two circuits.

Be the First to Share

    Recommendations

    • Battery Powered Contest

      Battery Powered Contest
    • Plywood Challenge

      Plywood Challenge
    • Plastic Contest

      Plastic Contest

    3 Discussions

    0
    entropy79
    entropy79

    Question 1 year ago

    Where could I find the touch pins?

    0
    Molted
    Molted

    Reply 1 year ago

    You can use any metallic pin or even aluminium foil.

    0
    entropy79
    entropy79

    Reply 1 year ago

    Thanks!
