Introduction: Using SMD Components on Breadboards
More by the author:
About: I am an electrical engineer. I graduated from U of Waterloo. I used to work for Adafruit Industries as an EE. Now I work for Sony PlayStation as a EE.
To use SMD components on breadboards, simply use 0.1" spaced male headers, cut a piece of two pins, and solder the SMD component in between the two pins on the shorter end of the header.
This works well with 0603 and 0805 sized components, as shown in the pictures.
SMD components are much cheaper, and they also fit on perfboards. I never buy through hole components any more.
Participated in the
Electronics Tips and Tricks
7 Comments
6 years ago
good idea
7 years ago
This is GENIUS! I can't believe I never thought of it before.
One caveat: You no longer have the leads that can be bent to variable lengths.
8 years ago on Introduction
Just a note to let you know I have added this ( a year ago ) to the instructable:
Comprehensive Guide to Electronic Breadboards: A Meta Instructable
>> https://www.instructables.com/id/Comprehensive-Gui...
Take a look at a bunch of project involving breadboards.
9 years ago on Introduction
It would be useful to mention that a calculation of a resistor's power rating would be wise, as some 0603 resistors are rated at only 0.1 W or less.
9 years ago on Introduction
This could save someone so much precious breadboard space.
10 years ago on Introduction
That is so smart! I will surely be using this from now on :) Thank you! :)
10 years ago on Introduction
What an awesome idea! I plan on using this technique now.
