Vibration Isolator

DIY vibration isolation platform

Supplies

Amazon Orders:

2x SK8 Aluminum Linear Motion Rail Clamping Rod Rail Guide Support for 8mm (Pack of 4)

https://www.amazon.com/dp/B07QS7Z8MK/

2x SCS8UU Linear Ball Bearing Slide Block Units, 8mm Bore Dia (Pack of 4)

https://www.amazon.com/dp/B07GQYTHMD/

1x 8mm x 150mm 304 Stainless Steel Solid Round Rod for DIY Craft - 10pcs

https://www.amazon.com/dp/B082ZNWR1G/

McMaster Orders (1x each):

47065T905 T-Slotted Framing, End-Feed Single Nut, 1/4"-20 Thread, packs of 25

90101A230 18-8 Stainless Steel Thin Nylon-Insert Locknut, 1/4"-20 Thread Size, packs of 50

9657K384 Compression Spring, 2" Long, 0.3" OD, 0.256" ID, packs of 6

9657K389 Compression Spring, 2" Long, 0.42" OD, 0.326" ID, packs of 6

9657K701 Compression Spring, 2.5" Long, 0.360" OD, 0.296" ID, packs of 12

8505K734 Clear Cast Acrylic Sheet, 12" x 12" x 1/4", Gray

47065T101 T-Slotted Framing, Single 4-Slot Rail, Silver, 1" High x 1" Wide, Solid, 8' Long

47065T101 T-Slotted Framing, Single 4-Slot Rail, Silver, 1" High x 1" Wide, Solid, 8' Long

47065T663 (8x) Silver Gusset Bracket, 1" Long for 1" High Rail T-Slotted Framing

Variety of #¼-20 and M4 bolts

Step 1: Vibration Isolator Diagrams and Photos

Vibration Isolator Diagrams And Photos

Step 2: CAD

Step 3: Source Files

Step 4: Chassis Assembly

1. Cut the following lengths of the 80/20 extrusions:

2x 18” long 1” x 1” extrusion

1x 16” long 1” x 1” extrusion

2x 8” long 1” x 2” extrusion

2. Using an F size drill bit, make the screw holes of the SK8 rod clamps larger (to the through

hole size of ¼”-20 screws)

3. Looking at the below image, assemble the 3D printed parts, cut extrusions, and rod clamps

together. Slide in the axles only for the two central rod clamps, and tighten them.

Step 5: Table Assembly

1. Put together the below assembly, putting together the axle, linear ball bearings, as well as

connectors for the table.

2. Laser cut ¼” acrylic using the file Tabletop.ai. Assemble the assembly from 1) to the laser cut

acrylic tabletop.

3. Assemble the vertical ball bearings as well as spring holders to the tabletop.

Step 6: Isolator Assembly

1. Place the tabletop on the assembled chassis, sliding the vertical ball bearings onto the

vertical axles.

2. Slide in the four axles for the negative stiffness structure.

3. Place the desired springs into the spring holders in both the vertical and horizontal portions,

depending on your desired calculations. Our suggestion for a wide range of vibration isolation is:

8x 9657K701 at the bottom

3x 9657K389 per side

2x 9657K384 per side
