While this circuit does invert the signal in your simulation, it is not actually a NOT gate. A correct NOT gate would be actively driven. For a 5V TTL circuit: if the input is at least 2V, the output is pulled high (5V); but if the input goes below 0.8V, the output is pulled low (0V).http://www.allaboutcircuits.com/textbook/digital/c...https://en.wikipedia.org/wiki/Inverter_(logic_gate...
