Introduction: LED COP LIGHTS USING ARDUINO!
Here's a video showing cop lights in action.
Attachments
Step 1: Components Required
- Micro controller(I used arduino Uno)
- Breadboard
- Red LED's(Or any colour you like)
- Blue LED's
- Connecting wires
Thats all
Now lets start working :)
Step 2: Making the Connections
Here is a circuit diagram,its not necessary to explain this its self explanatory
The pin 11 of arduino is connected to the positive terminal of the Blue LED
pin 9 is connected to the positive terminal of Red LED
the grounds are kept common and are connected to the GND pin
Step 3: Uploading the Code
Here's the code you need to upload on the arduino
int ledDelay = 50; // delay by 50ms
int redPin = 9;
int bluePin = 11;
void setup()
{
pinMode(redPin, OUTPUT);
pinMode(bluePin, OUTPUT);
}
void loop()
{
digitalWrite(redPin, HIGH); // turn the red light on
delay(ledDelay); // wait 50 ms
digitalWrite(redPin, LOW); // turn the red light off
delay(ledDelay); // wait 50 ms
digitalWrite(redPin, HIGH); // turn the red light on
delay(ledDelay); // wait 50 ms
digitalWrite(redPin, LOW); // turn the red light off
delay(ledDelay); // wait 50 ms
digitalWrite(redPin, HIGH); // turn the red light on
delay(ledDelay); // wait 50 ms
digitalWrite(redPin,LOW); // turn the red light off
delay(ledDelay); // wait 50 ms
delay(100); // delay midpoint by 100ms
digitalWrite(bluePin, HIGH); // turn the blue light on
delay(ledDelay); // wait 50 ms
digitalWrite(bluePin, LOW); // turn the blue light off
delay(ledDelay); // wait 50 ms
digitalWrite(bluePin, HIGH); // turn the blue light on
delay(ledDelay); // wait 50 ms
digitalWrite(bluePin, LOW); // turn the blue light off
delay(ledDelay); // wait 50 ms
digitalWrite(bluePin, HIGH); // turn the blue light on
delay(ledDelay); // wait 50 ms
digitalWrite(bluePin, LOW); // turn the blue light off
delay(ledDelay); // wait 50 ms
}
Attachments
Step 4: You Are Done!
Yes you are done enjoy!
