Forget Instagram, bring back that retro look to your pictures by using classic analog film in a fun new way. This camera hat was made using leftover single-use 35mm film cameras and several small servo motors, all powered by two AA batteries. With the camera array sitting on your head, you're able to capture a 360° panorama view of your surroundings. This project requires no special electronics knowledge and can be assembled in about an hour.
I designed this camera array off something I saw on the "Radar Detector" music video by Darwin Deez. But, after making the camera hat, everyone kept asking if it was a low-fi version of Google Street View. It's more the former than the latter, but people can draw their own interpretations. There's also Chindogu.
Of course you can always just buy (or win) a 360° panorama camera, but it's no where near as eye-catching as this one.
Enough talk, let's make a 360° panorama camera hat!
I designed this camera array off something I saw on the "Radar Detector" music video by Darwin Deez. But, after making the camera hat, everyone kept asking if it was a low-fi version of Google Street View. It's more the former than the latter, but people can draw their own interpretations. There's also Chindogu.
Of course you can always just buy (or win) a 360° panorama camera, but it's no where near as eye-catching as this one.
Enough talk, let's make a 360° panorama camera hat!
Step 1: Tools + Materials
tools:
| materials:
|
Step 2: Cut Can to Size
In order to hold the cameras and servos in place there needs to be a frame. I used an inexpensive plastic garbage bucket from the Dollar Store. Choose a bucket that can fit over your head (ignore the odd looks from other shoppers when you're trying out buckets on your head).
Next, I scored a cut line around the circumference of the bucket by elevating my hobby knife on a stable platform and rotating the bucket. Working slowly I carefully cut into the bucket until the lower bucket portion was separated from the rest.
Remove any burrs around edge, sand with a fine grit sandpaper if you like.
This bottom portion of the bucket will fit over your head and hold all the cameras, servos and battery assembly.
Next, I scored a cut line around the circumference of the bucket by elevating my hobby knife on a stable platform and rotating the bucket. Working slowly I carefully cut into the bucket until the lower bucket portion was separated from the rest.
Remove any burrs around edge, sand with a fine grit sandpaper if you like.
This bottom portion of the bucket will fit over your head and hold all the cameras, servos and battery assembly.
Step 3: Arrange Camera Array
Next, arrange your cameras around the rim of your bucket ring. The bucket I used had a small ledge which I used to mount my cameras level. Thick cable ties were used to hold each camera firmly in place.
Tighten each cable tie partway, then make any adjustments that are necessary to ensure each camera is equally spaced around the bucket ring, then tighten each cable tie to secure the cameras. Make sure you don't cover the lens with the cable tie.
Set aside the camera and frame assembly for now while the electronics are put together.
Tighten each cable tie partway, then make any adjustments that are necessary to ensure each camera is equally spaced around the bucket ring, then tighten each cable tie to secure the cameras. Make sure you don't cover the lens with the cable tie.
Set aside the camera and frame assembly for now while the electronics are put together.
Step 4: Prepare Servos
The electronics for this project are simple.
Most servos will have a 3-wire ribbon cable, this cable enables the servo to interface with a micro controller. However, we want our servos to operate without control circuitry. Luckily removing the controller from inside a servo is easy.
Start by prying open the back of the servo, the first thing you should see will be the controller. Most controllers will have a 3-wire ribbon cable attached to the controller, with wires from the controller to the motor and a potentiometer. Leave the 3-wire ribbon cable and desolder any wires connected to the controller (there should be 2 to the motor and 2 to the potentiometer). This should detach any connection between the controller and the servo, allowing the controller and 3-wire ribbon to be removed as one.
Next, solder new wires directly to the motor. Protect the wires from shorting out by sealing them in heat-shrink tubing. Tuck the soldered connection into the servo housing and snap the back of the servo back on.
Repeat with as many servos as you need for your camera array.
Most servos will have a 3-wire ribbon cable, this cable enables the servo to interface with a micro controller. However, we want our servos to operate without control circuitry. Luckily removing the controller from inside a servo is easy.
Start by prying open the back of the servo, the first thing you should see will be the controller. Most controllers will have a 3-wire ribbon cable attached to the controller, with wires from the controller to the motor and a potentiometer. Leave the 3-wire ribbon cable and desolder any wires connected to the controller (there should be 2 to the motor and 2 to the potentiometer). This should detach any connection between the controller and the servo, allowing the controller and 3-wire ribbon to be removed as one.
Next, solder new wires directly to the motor. Protect the wires from shorting out by sealing them in heat-shrink tubing. Tuck the soldered connection into the servo housing and snap the back of the servo back on.
Repeat with as many servos as you need for your camera array.
Step 5: Mount Servos
After each servo has been modified to direct drive they can be mounted on the camera assembly. Position the servo so that the rotating arm will fall onto the camera shutter trigger. Then using long, thin cable ties secure each servo in place, again making sure your cable ties don't block the camera lens.
Step 6: Wiring
I wired the servos in parallel. Using 2 long wires to form an electrical racetrack around the inside of the bucket ring, I cut the vinyl jacket on each wire where it met with the servos and then wired each into the racetrack. Connections were sealed with more heat-shrink tubing.
The battery holder was wired up last, along with long leads for the momentary switch (see next step).
The battery holder was wired up last, along with long leads for the momentary switch (see next step).
Step 7: Wire Servo Trigger
To trigger the servos I used a large N.O momentary switch. To hold the switch and provide a handle I used the housing on a regular ballpoint pen. Removing the end cap and ink cartridge inside the pen I fed the wires through and connected the switch, the other end was wired to the battery and racetrack. I decided to encase my trigger cord in some scrap paracord.
After all the wiring is complete tuck any slack wires behind the battery holder, then cable tie the battery holder in place. Then, test out your circuit by depressing the momentary switch, all the servo should activate at once.
Success!
After all the wiring is complete tuck any slack wires behind the battery holder, then cable tie the battery holder in place. Then, test out your circuit by depressing the momentary switch, all the servo should activate at once.
Success!
Step 8: Take Some Panorama Pictures
Time to wind up each camera and take your cameras out for a spin! I found that these single-use film camera work best outdoors, if you shoot indoors you'll need to have the flash on and take your pictures in an open area.
Depress trigger, wind each camera, move locations, repeat.
You're going to get a lot of stares.
Depress trigger, wind each camera, move locations, repeat.
You're going to get a lot of stares.
Step 9: Print Your Panoramas (optional)
After exposing all the cameras completely I printed out a few of the pictures to make a full panorama.
I lined up the pictures and used clear tape on the backside of each photo, then joined the two ends together forming a loop of pictures with the images on the inside. After, I put my head inside the ring of pictures to fully experience a 360° view of that location*.
*Looks of amazement when head is immersed in panorama may vary.
Step 10: Results and Final Thoughts
Here's a few of my shots compiled together digitally:
Of the 36 exposures for each camera in the array only about 10 "sets" came out with all six camera exposures in usable form. Of those 10 only the ones shown above were worth sharing, the remainder were either too dark, blown out, or incomprehensible to anyone who wasn't there when I took the shot.
Some notes to consider for others (and myself for next time):
- Ensure your camera array (head) is parallel to the ground before shooting
- Verify all cameras are operable/wound/aligned before shooting
- Do not rely on camera flash to compensate for terrible indoor lighting
I hope this inspires you to try and make your own, good luck!
I want to see your creations! Did you make your own version of this project? Share a picture of your own camera hat
below.
Happy making :)
