9v Battery Status Indicator Circuit

This is a 9v battery status indicator circuit.One of my friend asked me to build this as he wants a 9v transistor radio battery status indicator. Thats why i build this circuit it works great and another thing about this circuit by changing the 'ZENER diode" you can rebuild this circuit for other low power battery. I used Green and Red led as green Led light's up when the voltage is upper than 6.9v and Red led lights up when the voltage drops to 6.9v . Its simple and reliable all the parts are commonly available and low cost also.

parts List :

Led (RED & Green )
ZENER 6.2v (for using with 9v battery)
330r
47k
BC547
10k

Comments

[Jaacckk]

Hi @victordas, I haven't built the circuit but viewing the comments below and analysing the circuit myself by pen and paper I don't see how the red light will ever be switched off. Can you please explain it to me?
What I understand so far is that when the battery voltage exceeds the zener voltage + base emitter voltage of the BJT (6.2 + 0.7 = 6.9V) the zener will reverse breakdown and there will exist small current that is able to enter the base of the first transsitor, which allows current to flow from the collector to the emitter. This current must first pass through the green light, which turns it on.
I also understand that when the battery voltage is less than 6.9V the first transistor will not allow current to flow through to its emitter, and due to the 47k resistor there will be only a very small current through the green LED into the base of emitter 2 - not enough for it to visibly be turned on - which in turn allows current to flow through from collector to emitter of transistor 2 and causes red LED to glow.

However, can there not also be small current that has passed through the green light which enters the base of emitter 2 (as the base voltage is 0.7V and there still exists a voltage differential across the 47k resistor) which will also allow current to flow from collector to emitter of transistor 2 and cause the red LED to glow.

I hope I explained myself well and I hope you respond soon
Jack

[riyaz dange]

[riyaz dange]

sir can i ask for a ckt for 6V battery status indicator? thank you!

[riyaz dange]

please reply me as quick as you can.

[afz2004]

First time, I build this circuit, I also faced a problem, where two LEDs lit up when voltage is above than set value which determined by zener diode. So, I make some modifications on its base resistor at transistors, and it worked out. Hope it will help you guys! Done with Proteus 8

[victordas]

Conzrzzzzzzz ......

[Grapheno]

Multisim

[Grapheno]

This circuit sound great to make a flip flop circuit however I have tried in Multisim and the red and green light both are lighting till 6,9 volts.

Actually, I would like to make this circuit in 7,4 lithium battery and I have tried to calculate the reistance and I find it quite difficult.

Do you know any page to calculate it, or could you show your results in your project.

Thanks,

[neneythXD]

sir can i ask for a ckt for 6V battery status indicator? thank you! :)

[apeiris]

please give me a NP4.5 6v 5Ah battery charging indicating circuit diagram

[victordas]

Ok i will try bt it will take little time

[muralim.murali.50]

sir how to set low led indication for 4v and high led for 8v.. can u help me???

[victordas]

First of all change the Zener diode as you need. Than set the circuit

[zlin1]

Hi do you have a picture of the built circuit? ive been trying to replicate it on a breadboard and couldnt get it to work. thanks

[victordas]

Sorry my frnd i don have any picture of the above circuit

[Fozzibehr]

So could you do this with a 12 volt battery and 4 leds? and could you clarify what the zener 6.2v is?

[iliceras]

they are rechargeable batteries (1.2v each), shall I use a 3.6v diode?

[victordas]

hoo yes u can try that .............

[iliceras]

Thank you very much for your design, it's really useful to me.

I got some questions, hope you can help me:

- I would like to place 3 different LEDs on my circuit to indicate the charge level for a 4 AA rechargeable battery pack. They all together and completely charge would give me 4.8 volts, which Zener diode do you suggest to me?

- Could I use 1 zener diode and different resistors values to light up the different leds?

[victordas]

1sly.....1.5v x 4aa would give u 6v not 4.8v.......as far i think u could use a 4.8v zener.....try 2 build the circuit in bread board 1st...........
