AC MOTOR SPEED CONTROLLER CIRCUIT

Nowadays uses of motor in appliances and devices is increasing. motors are used in CD tray in your computer, the rotating microwave dish, the power windows in your car. so to control the speed of these appliances a seed controller is required. such a speed controller is the one which i have made . even though it is a simple one. i think you will like my project. if you like vote for me.

Step 1: HOW DOES THIS USED

This triac-based 220 V AC motor speed controller circuit is designed for controlling the speed of small household motors like drill machines. The speed of the motor can be controlled by changing the setting of P1. The setting of P1 determines the phase of the trigger pulse that fires the triac . The circuit incorporates a self-stabilizing technique that maintains the speed of the motor even when it is loaded.

For example, when the motor of the drill machine is slowed down by the resistance of the drilled object, the counter-EMF of the motor also decreases. This results to a voltage increase in R2-P1 and C3 causing the triac to be triggered earlier and the speed increases accordingly.
