ASTROLABE - Made Using Paper (medieval Astronomical Instrument)

Introduction: ASTROLABE - Made Using Paper (medieval Astronomical Instrument)

An astrolabe is an elaborate inclinometer, and can be considered an analog calculator capable of working out several different kinds of problems in astronomy

Supplies

Templates

glue

scissors

nut and bolt

Step 1: PRINT THE TEMPLATES.

To make the astrolabe, you have to print some templates on A4 sheets.

The PDF link to the templates is:

https://in-the-sky.org/astrolabe/pdfs/astrolabe_15N_en_full.pdf

Step 2: STICK THE TEMPLATES ONTO THIN CARD AND CUT THEM

Stick the template onto thin card and cut out the front and back sides of the mother, and glue them back to back. You may wish to sandwich a piece of cardboard between them to make your astrolabe more rigid.

Repeat the same for the rule,rete and the alidade(stick them into thin card and cut it out).

Step 3: Assemble All the Parts Together.

Now all of the parts of the astrolabe need to be fixed together with a nut and boltor even a split fastener.

All of the components have small circular holes marked, which you should cut out.

Once all the holes are made, slide a bolt or a split-pin fastener through the rule, rete, mother and alidade of the astrolabe in turn, and fold the split pins back to fasten the astrolabe together. Ensure that the central hole is big enough that the alidade, rete and rule can turn freely.

Your astrolabe is now ready for use.

Step 4: TEST.

The astrolabe has a ton of uses but the most common one is to find the altitude of stars .

Pick up the astrolabe and aim the alidade towards the sun. The alidade is the part that moves on the outside of the astrolabe. Keep adjusting the alidade until the sun is blocked by the flaps on the alidade.

Keep the device pointing at the sun and then read the altitude where it’s written in degrees on the side of the device. The point to read is where the rule crosses across the astrolabe. The rule is the moving part on the inside surface of the astrolabe. It may be easier to have someone else read the measurement so you can keep the device steady.

Here at my house ,when i tested the astrolabe, the altitude of the sun was 70 degrees.

Thank you for viewing my instructable.

Space Challenge

Participated in the
Space Challenge

Be the First to Share

    Recommendations

    • Space Contest

      Space Contest
    • Micro:bit Contest

      Micro:bit Contest
    • Make it Move Challenge

      Make it Move Challenge

    7 Comments

    0
    DanyKarll
    DanyKarll

    1 year ago on Step 4

    If you look at the instructions, the piece called rete must be printed on acetate or on a transparent material, in such a way that it allows you to see the piece called mother, which is where the local horizon is shown.
    The rete piece is the one that has the circle of the ecliptic, with the zodiacal houses and that also draws some stars. The height of the sun, according to a date (position in the ecliptic or zodiacal constellation) or that of a star, can be read on the lines of coordinates that are located in the mother, so the piece rete (spider) should be transparent. Make that adjustment and you can enjoy your astrolabe. Congratulations.

    0
    creative sam
    creative sam

    Reply 1 year ago

    Yes ,but I did not have acetate sheets and i could not order them as they would take really long due to covid 19, so I had to use normal paper.
    Btw, thank you and vote my project if liked it.
    Samarth P

    0
    TheOwlman
    TheOwlman

    1 year ago

    Be aware that the link you gave is to PDFs for a specific latitude and others may be disppointed that their instrument doesn't perform correctly if they are far from 15N. https://in-the-sky.org/astrolabe will allow anyone to set their lattitude and download appropriate PDFs.

    0
    creative sam
    creative sam

    Reply 1 year ago

    TheOwlman thanks for letting me know.
    il shortly make the necessary changes.

    0
    creative sam
    creative sam

    Reply 1 year ago

    Thank you for giving me the link to the guide.
    I can learn much more about the astrolabe and it's used with the help of it.
    This is an entry in the space contest so do vote for me if you liked my project

    0
    TheOwlman
    TheOwlman

    Reply 1 year ago

    I did like your project and you have my vote :D
