Introduction: Aerodynamic FPV Case
Hello and welcome to this instructable about my Aerodynamic FPV case for RC planes, drones and more!
I will be explaining to you how I had the idea of this type of case, how I designed it and how I 3D printed it with my UP! Mini!
Enjoy!
Step 1: The Idea and the Design.
I wanted an aerodynamic case for my Fatshark FPV set and searched for one but I couldn't find one that suited me so I decided to make my own!
As a mechanical engineering student, I was able to use Catia V5 and V6 at my school to design this little project.
I started by measuring all the sizes of the camera and the video sending module, I wanted the finished object to have these all in one so it could be easely removed from the aicraft or drone.
As the title says, I wanted it to be as aerodynamical as possible so I shaped the 3D model that way.
Step 2: Printing!
This image shows how I organised the plate of my UP! Mini so all the objects could fit at once!
The parts were printed at a 0.2mm resolution, at the printer's max speed, and with support material for everything over 45 degrees, so it took 2 hours and 56 minutes to print.
Step 3: Test Fitting of the Parts.
Here you can see all the parts fitted perfectly, the only post processing used was support removal and a bit of sanding of the assembled product to make it more aerodynamic!
The next step was to see if the components of the FPV set fitted.
Step 4: Finished Product!
Et voilà, as the french would say, everything fits nicely together!
The only thing to do next is to make it fly!
Thanks for reading this instructable, I hope it inspired you!
You can find all the parts and even a 2nd version of this project here:

Participated in the
3D Printing Contest
5 Comments
7 years ago on Introduction
I love it! The only question I have is with regards to the "vents" on the side: Is there a vent at the back where the air can exit, because if not, you have just created a drag pocket behind your camera, pretty much defeating the purpose of the aerodynamic shell.
Reply 7 years ago on Introduction
Yes Whisper219, there is a grill at the back that permits airflow, so no problem!
And by the way, check out version 2 on wich I tried to make even better airflow but I never printed that one. http://www.thingiverse.com/thing:629181
Reply 7 years ago on Introduction
Yeah, I saw the grill in the 3D model after I posted the comment. Ooh, the V2 looks REALLY good! I love them both!
7 years ago on Introduction
This turned out looking pretty slick!
Nicely done. Welcome to instructables too!
Reply 7 years ago on Introduction
Thank you seamster! I am amazed to see I have already so many views, I hope it will be useful for many people! :)
