Introduction: Animatronic Bird
This Animatonic was originally a TSA (Technology Student Association) Project. We had to make an animatronic and explain how it works showing the control electronics.
Step 1: The Concept
First I had to design a wing mechanism. Which was easier said then done. I took hours of analyzing how a bird flaps its wings. Then I figured it out. I needed a wing with 3 sections the base, The arm, Fore arm. And then I could connect the base and the fore arm throw the rod and as the arm spun in the base the rod would guide the fore arm with it. Then a hole would be drilled in the arm so I could add a torsion connected to the pegs of the base spring to snap the arm open.
Step 2: Finishing It
Finally I could add the second wing to the body. I also made 2 holes for micro servos. Servo 1 would flap the wings up and down with the help of an arduino nano. Servo 2 would pull the wings down then when the servo releases the torsion springs would snap the wings open again.
Step 3: DISCLAIMER
This bird was only a quick prototype for demonstration nothing in the model is a polished product
(I did 3d print and make the bird and everything went well. sadly I could not get pictures of it :( )
