Introduction: Arduino Based Auto Timer / Stop Watch Timer for Stroking Time Measurement
The Need:
Last week around at work I had another usual un-usual problem to face with. Having to make lots of mechanisms n components to work with-in seconds or fracs at times I kind-of knew this was always coming.
And invariably so my poor mind couldn't think of anything but Arduino for a handy solution that should be compact, flexible, highly customizable, rugged and most importantly easier to work around.
Last week around at work I had another usual un-usual problem to face with. Having to make lots of mechanisms n components to work with-in seconds or fracs at times I kind-of knew this was always coming.
And invariably so my poor mind couldn't think of anything but Arduino for a handy solution that should be compact, flexible, highly customizable, rugged and most importantly easier to work around.
Step 1: The Problem:
What we had is an arm moving around from an actuator which we would like to tap with some contact type micro switces (limit switches) to give a feed-back signal as the awkward figure suggests.
Step 2: Components:
I franatically searched for the components from the Junks I always treasured with the hobby kit coming-in handy..
LCD Display (16x2) - 1
Arduino - 1 (Duemelanove is what I had)
Micro Switches - 2
Hook-up wires for (bread board) - Plenty (see Fritizing schematic for actuals)
Bread Board - 1 (for Prototyping)
LED - 1 (fok blinking indication)
Resistors 330 & 2K - 1 each
potentiometer 4k - 1 ( I had used one 2k Resistor and a 4K POT in comb. instead of a 6k pot to control the display as it came so handy from the junk parts)
LCD Display (16x2) - 1
Arduino - 1 (Duemelanove is what I had)
Micro Switches - 2
Hook-up wires for (bread board) - Plenty (see Fritizing schematic for actuals)
Bread Board - 1 (for Prototyping)
LED - 1 (fok blinking indication)
Resistors 330 & 2K - 1 each
potentiometer 4k - 1 ( I had used one 2k Resistor and a 4K POT in comb. instead of a 6k pot to control the display as it came so handy from the junk parts)
Step 3: The Methodology
Now that all I/O's are wired in order as per the schematic, it pretty much works-out itself and it all boils down to the programming now..
I had used the StopWatch library to evoke the timer and initiated the millis() function to record time step value as soon as Arduino is started.
But what I need is just a differential timer with the simple math which gives us the time on air or otherwise.
All that I did is declared some run-time variables and do some math to display the difference value to show only the time between micro-switches getting energised. Otherwise to display the time correctly in the format is similar to Dan Thompson's method as it only records the time values in millis and we have to convert the values to sec, min, hr and microsecs.
The other problem i encounter is the sign reversal as arduino cannot handle large buffer. I finally managed to overcome this error by using the unsigned longint as integer data type.
I had used the StopWatch library to evoke the timer and initiated the millis() function to record time step value as soon as Arduino is started.
But what I need is just a differential timer with the simple math which gives us the time on air or otherwise.
All that I did is declared some run-time variables and do some math to display the difference value to show only the time between micro-switches getting energised. Otherwise to display the time correctly in the format is similar to Dan Thompson's method as it only records the time values in millis and we have to convert the values to sec, min, hr and microsecs.
The other problem i encounter is the sign reversal as arduino cannot handle large buffer. I finally managed to overcome this error by using the unsigned longint as integer data type.
Step 4: Display Shield
The display shield is constructed of pretty much the same components over a matrix board with pin rails for piggy-backing Arduino.
Had used some old components from an electronic choke for compacting
Had used some old components from an electronic choke for compacting
Step 5: Arduino Sketch - Programming
Final sketch\code for Arduino below:
/*
Sketch \ Code by Chuppandi aka Subu
Chuppandi@gmail.com
www.chuppandee.blgospot.com
*/
#include <StopWatch.h>
#include <LiquidCrystal.h>
LiquidCrystal lcd(7, 8, 9, 10, 11, 12); // LCD pins decleration
int switchPin1 = 3;// switch1 is connected to pin 3
int switchPin2 = 2;// switch2 is connected to pin 2
int ledPin = 13; // LED is connected to pin 13 in arduino
int val1;
int val2;
int frameRate = 500; // the frame rate (frames per second) at which the stopwatch runs - Change to suit
long interval = (1000/frameRate); // blink interval
char buf[15f00]; // string buffer for itoa function
unsigned long starttime = 0;
unsigned long endtime = 0;
unsigned long lasttime = 0;
unsigned long currenttime = 0;
StopWatch sw_millis; // MILLIS (default)
StopWatch sw_micros(StopWatch::MICROS);
StopWatch sw_secs(StopWatch::SECONDS);
void setup() {
lcd.begin(16,2);
pinMode(switchPin1, INPUT);
pinMode(switchPin2, INPUT);
pinMode(ledPin, OUTPUT);
Serial.begin(9600);
sw_millis.start();
sw_micros.start();
sw_secs.start();
}
void loop() {
val1 = digitalRead(switchPin1); // read input value and store it in val
val2 = digitalRead(switchPin2); // read input value and store it in val
if (val1 == LOW && val2 == LOW)
{
digitalWrite(ledPin, HIGH); // turn LED on
currenttime = (sw_millis.elapsed() - lasttime) ;
Serial.print("sw_millis=");
Serial.println(sw_millis.elapsed());
Serial.print("sw_micros=");
Serial.println(sw_micros.elapsed());
Serial.print("sw_secs=");
Serial.println(sw_secs.elapsed());
lcd.clear();
lcd.print("SECS:");
float sec = sw_millis.elapsed()/10;
lcd.print(sec);
int elapsedMinutes = (currenttime / 60000L);
int elapsedSeconds = (currenttime / 1000L);
int elapsedFrames = (currenttime / interval);
int fractionalSecs = (int)(elapsedSeconds % 60L);
int fractional = (int)(elapsedFrames % frameRate); // use modulo operator to get fractional part of 100 Seconds
fractionalSecs = (int)(elapsedSeconds % 60L); // use modulo operator to get fractional part of 60 Seconds
int fractionalMins = (int)(elapsedMinutes % 60L); // use modulo operator to get fractional part of 60 Minutes
lcd.clear(); // clear the LCD
lcd.print("TIME:");
if (fractionalMins < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalMins, buf, 10)); // convert the int to a string and print a fractional part of 60 Minutes to the LCD
lcd.print(":"); //print a colan.
if (fractionalSecs < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalSecs, buf, 10)); // convert the int to a string and print a fractional part of 60 Seconds to the LCD
lcd.print(":"); //print a colan.
if (fractional < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractional, buf, 10)); // convert the int to a string and print a fractional part of 25 Frames to the LCD
lcd.setCursor(0, 1);
lcd.print("ACTUATOR TIMER");
endtime = currenttime;
/* lcd.print(" ms=");
lcd.print(sw_millis.elapsed());
lcd.setCursor(0, 1);
lcd.print("us=");
lcd.print(sw_micros.elapsed());
*/
delay(10);
}
// if (val1 == LOW){
// digitalWrite(ledPin, LOW);}
else{
lasttime = sw_millis.elapsed();
// endtime = (sw_millis.elapsed() - starttime);
// endtime = (currenttime - starttime);
digitalWrite(ledPin, LOW);
int elapsedMinutes = (endtime / 60000L);
int elapsedSeconds = (endtime / 1000L);
int elapsedFrames = (endtime / interval);
int fractionalSecs = (int)(elapsedSeconds % 60L);
int fractional = (int)(elapsedFrames % frameRate); // use modulo operator to get fractional part of 100 Seconds
fractionalSecs = (int)(elapsedSeconds % 60L); // use modulo operator to get fractional part of 60 Seconds
int fractionalMins = (int)(elapsedMinutes % 60L); // use modulo operator to get fractional part of 60 Minutes
lcd.clear(); // clear the LCD
lcd.print("TIME:");
if (fractionalMins < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalMins, buf, 10)); // convert the int to a string and print a fractional part of 60 Minutes to the LCD
lcd.print(":"); //print a colan.
if (fractionalSecs < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalSecs, buf, 10)); // convert the int to a string and print a fractional part of 60 Seconds to the LCD
lcd.print(":"); //print a colan.
if (fractional < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractional, buf, 10)); // convert the int to a string and print a fractional part of 25 Frames to the LCD
lcd.setCursor(0, 1);
lcd.print("ACTUATOR TIMER");
}
}
// End of the program
/*
Sketch \ Code by Chuppandi aka Subu
Chuppandi@gmail.com
www.chuppandee.blgospot.com
*/
#include <StopWatch.h>
#include <LiquidCrystal.h>
LiquidCrystal lcd(7, 8, 9, 10, 11, 12); // LCD pins decleration
int switchPin1 = 3;// switch1 is connected to pin 3
int switchPin2 = 2;// switch2 is connected to pin 2
int ledPin = 13; // LED is connected to pin 13 in arduino
int val1;
int val2;
int frameRate = 500; // the frame rate (frames per second) at which the stopwatch runs - Change to suit
long interval = (1000/frameRate); // blink interval
char buf[15f00]; // string buffer for itoa function
unsigned long starttime = 0;
unsigned long endtime = 0;
unsigned long lasttime = 0;
unsigned long currenttime = 0;
StopWatch sw_millis; // MILLIS (default)
StopWatch sw_micros(StopWatch::MICROS);
StopWatch sw_secs(StopWatch::SECONDS);
void setup() {
lcd.begin(16,2);
pinMode(switchPin1, INPUT);
pinMode(switchPin2, INPUT);
pinMode(ledPin, OUTPUT);
Serial.begin(9600);
sw_millis.start();
sw_micros.start();
sw_secs.start();
}
void loop() {
val1 = digitalRead(switchPin1); // read input value and store it in val
val2 = digitalRead(switchPin2); // read input value and store it in val
if (val1 == LOW && val2 == LOW)
{
digitalWrite(ledPin, HIGH); // turn LED on
currenttime = (sw_millis.elapsed() - lasttime) ;
Serial.print("sw_millis=");
Serial.println(sw_millis.elapsed());
Serial.print("sw_micros=");
Serial.println(sw_micros.elapsed());
Serial.print("sw_secs=");
Serial.println(sw_secs.elapsed());
lcd.clear();
lcd.print("SECS:");
float sec = sw_millis.elapsed()/10;
lcd.print(sec);
int elapsedMinutes = (currenttime / 60000L);
int elapsedSeconds = (currenttime / 1000L);
int elapsedFrames = (currenttime / interval);
int fractionalSecs = (int)(elapsedSeconds % 60L);
int fractional = (int)(elapsedFrames % frameRate); // use modulo operator to get fractional part of 100 Seconds
fractionalSecs = (int)(elapsedSeconds % 60L); // use modulo operator to get fractional part of 60 Seconds
int fractionalMins = (int)(elapsedMinutes % 60L); // use modulo operator to get fractional part of 60 Minutes
lcd.clear(); // clear the LCD
lcd.print("TIME:");
if (fractionalMins < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalMins, buf, 10)); // convert the int to a string and print a fractional part of 60 Minutes to the LCD
lcd.print(":"); //print a colan.
if (fractionalSecs < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalSecs, buf, 10)); // convert the int to a string and print a fractional part of 60 Seconds to the LCD
lcd.print(":"); //print a colan.
if (fractional < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractional, buf, 10)); // convert the int to a string and print a fractional part of 25 Frames to the LCD
lcd.setCursor(0, 1);
lcd.print("ACTUATOR TIMER");
endtime = currenttime;
/* lcd.print(" ms=");
lcd.print(sw_millis.elapsed());
lcd.setCursor(0, 1);
lcd.print("us=");
lcd.print(sw_micros.elapsed());
*/
delay(10);
}
// if (val1 == LOW){
// digitalWrite(ledPin, LOW);}
else{
lasttime = sw_millis.elapsed();
// endtime = (sw_millis.elapsed() - starttime);
// endtime = (currenttime - starttime);
digitalWrite(ledPin, LOW);
int elapsedMinutes = (endtime / 60000L);
int elapsedSeconds = (endtime / 1000L);
int elapsedFrames = (endtime / interval);
int fractionalSecs = (int)(elapsedSeconds % 60L);
int fractional = (int)(elapsedFrames % frameRate); // use modulo operator to get fractional part of 100 Seconds
fractionalSecs = (int)(elapsedSeconds % 60L); // use modulo operator to get fractional part of 60 Seconds
int fractionalMins = (int)(elapsedMinutes % 60L); // use modulo operator to get fractional part of 60 Minutes
lcd.clear(); // clear the LCD
lcd.print("TIME:");
if (fractionalMins < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalMins, buf, 10)); // convert the int to a string and print a fractional part of 60 Minutes to the LCD
lcd.print(":"); //print a colan.
if (fractionalSecs < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractionalSecs, buf, 10)); // convert the int to a string and print a fractional part of 60 Seconds to the LCD
lcd.print(":"); //print a colan.
if (fractional < 10){ // pad in leading zeros
lcd.print("0"); // add a zero
}
lcd.print(itoa(fractional, buf, 10)); // convert the int to a string and print a fractional part of 25 Frames to the LCD
lcd.setCursor(0, 1);
lcd.print("ACTUATOR TIMER");
}
}
// End of the program
Step 6: Packaging
Packaging is always fun.. Just pick-up whatever you could come up with from the mighty treasure junks... you can make wonders...
Do visit my space for more updates on my Arduino erector kit.
Do visit my space for more updates on my Arduino erector kit.
