Arduino Led Chaser + Sequential Led + 7 Cool Effect

Introduction: Arduino Led Chaser + Sequential Led + 7 Cool Effect

About: Mr.ElectroUino is an education platform where we believe “Knowledge increases by sharing but not by saving”. Engineering projects, Electronics, Robotics, DIY stuff, Arduino projects, Raspberry Pi, IOT project …

In this Instructables, I have to show you arduino led chaser with 7 cool effects. So you guys can create your own dancing LED for your home decoration. An LED chaser or sequential led or Knight rider is a popular arduino led projects and simple to create it.

Step 1: Watch This Video!

In this video, I will show you how to make an arduino led chaser with 7 cool effects.

Step 2: Gather the Component:

Components Required for arduino led chaser.

1 × Arduino board.

1 × Breadboard.

12 × 5mm Led.

12 × Resistor (220Ω).

12 × Jumper wires (M).

Step 3: Make the Connection:

Connect LEDs pins to arduino uno pins.

1. To build led chaser we need a breadboard to create a connection between the component.

2. Next, connect the 220 ohms resistor to all LEDs anode terminal.

The resistor is used for protecting the LEDs. Without a resistor, the LED draws too much current and burns out.

3. Connnect LED1(+) Pin to arduino Digital Pin 2.

4. Connnect LED2(+) Pin to arduino Digital Pin 3.

5. Connnect LED3(+) Pin to arduino Digital Pin 4.

6. Connnect LED4(+) Pin to arduino Digital Pin 5.

7. Connnect LED5(+) Pin to arduino Digital Pin 6.

8. Connnect LED6(+) Pin to arduino Digital Pin 7.

9. Connnect LED7(+) Pin to arduino Digital Pin 8.

10. Connnect LED8(+) Pin to arduino Digital Pin 9.

11. Connnect LED9(+) Pin to arduino Digital Pin 10.

12. Connnect LED10(+) Pin to arduino Digital Pin 11.

13. Connnect LED11(+) Pin to arduino Digital Pin 12.

14. Connnect LED12(+) Pin to arduino Digital Pin 13

15. Connnect all LED Negative Terminal ( - ) to arduino GND Pin

Tell me your idea i will try to make it real(: and if you guys having any problem comment it.

Step 4: The Code:

//arduino led chaser code
/* Code:
           * by Sayed Mohsin
           * mrelectrouino.blogspot.com
           */

#define t   30
#define t1  20
#define t2  100
#define t3  50

void setup() {
  // set up pins 2 to 13 as outputs
  for (int i = 2; i <= 13; i++) {
    pinMode(i, OUTPUT);
  }
}
/////////////////////////////////////////////////////////////////////////////////Effect 1
void loop()
{
 effect_1();
 effect_1();
 effect_2();
 effect_2();
 effect_3();
 effect_3();
 effect_4();
 effect_4();
 effect_5();
 effect_5();
 effect_6();
 effect_6();
 effect_7();
 effect_7();
  }
//left to right and right to left
void effect_1()
{
for(int i=2; i<14; i++){
digitalWrite(i, HIGH);
delay(t1);
digitalWrite(i+1, HIGH);
delay(t1);
digitalWrite(i+2, HIGH);
delay(t1);
digitalWrite(i, LOW);
delay(t1);
digitalWrite(i+1, LOW);
delay(t1);
}
for(int i=13; i>1; i--){
digitalWrite(i, HIGH);
delay(t1);
digitalWrite(i-1, HIGH);
delay(t1);
digitalWrite(i-2, HIGH);
delay(t1);
digitalWrite(i, LOW);
delay(t1);
digitalWrite(i-1, LOW);
delay(t1);
}
}
/////////////////////////////////////////////////////////////////////////////////Effect 2
void effect_2()
{
int count = 13; // keeps track of second LED movement

  // move first LED from left to right and second from right to left
  for (int i = 2; i < 13; i++) {
    clear();
    digitalWrite(i, HIGH);      // chaser 1
    digitalWrite(count, HIGH); // chaser 2
    count--;
    // stop LEDs from appearing to stand still in the middle
    if (count != 7) {
      delay(t2);
    }
  }

  // move first LED from right to left and second LED from left to right
  for (int i = 13; i > 2; i--) {
    clear();
    digitalWrite(i, HIGH);      // chaser 1
    digitalWrite(count, HIGH); // chaser 2
    count++;
    // stop LEDs from appearing to stand still in the middle
    if (count != 8) {
      delay(t2);
    }
  }
}

////////////////////////////////////////////////////////////////////////////////Effect 3

void effect_3()
{
for(int i=2; i<14; i++){
  digitalWrite(i, HIGH);
  delay(t3);
}
for(int i=2; i<14; i++){
  digitalWrite(i, LOW);
  delay(t3);
}


for(int i = 14; i>=2; i--){
  digitalWrite(i, HIGH);
  delay(t3);
}
for(int i = 14; i>=2; i--){
  digitalWrite(i, LOW);
  delay(t3);
}
}
  ///////////////////////////////////////////////////////////////////////////Effect 4
void effect_4()
{
for(int j = 2; j <= 13; j++){
  digitalWrite(j, HIGH);
  delay(t2);
  j=j+1;
  }
for(int j = 2; j <= 13; j++){
  digitalWrite(j, LOW);
  delay(t2);
  }

  for(int k = 15; k > 2; k--){
  digitalWrite(k, HIGH);
  delay(t2);
  k=k-1;
  }
for(int k = 15; k > 2; k--){
  digitalWrite(k, LOW);
  delay(t2);
  }
}
//////////////////////////////////////////////////////////////////////////////Effect 5
  void effect_5()
{
 for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin, HIGH);
  delay(t1);
  digitalWrite(pin+1, LOW);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+1, HIGH);
  delay(t1);
  digitalWrite(pin+2, LOW);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+2, HIGH);
  delay(t1);
  digitalWrite(pin+3, LOW);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+3, HIGH);
  delay(t1);
  digitalWrite(pin+4, LOW);
  delay(t1);
  }
    for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+4, HIGH);
  delay(t1);
  digitalWrite(pin+5, LOW);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+5, HIGH);
  delay(t1);
  digitalWrite(pin+6, LOW);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+6, HIGH);
  delay(t1);
  digitalWrite(pin+7, LOW);
  delay(t1);
  }
   for(int pin = 13; pin >= 2; pin--)
  {
  digitalWrite(pin+7, HIGH);
  delay(t1);
  digitalWrite(pin+8, LOW);
  delay(t1);
  }
  for(int pin = 9; pin >= 2; pin--)
  {
  digitalWrite(pin+8, HIGH);
  delay(t1);
  digitalWrite(pin+9, LOW);
  delay(t1);
  }
    for(int pin = 9; pin >= 2; pin--)
  {
  digitalWrite(pin+9, HIGH);
  delay(t1);
  digitalWrite(pin+10, LOW);
  delay(t1);
  }
  for(int pin = 9; pin >= 2; pin--)
  {
  digitalWrite(pin+10, HIGH);
  delay(t1);
  digitalWrite(pin+11, LOW);
  delay(t1);
  }
  for(int pin = 14; pin >= 2; pin--)
  {
  digitalWrite(pin+11, HIGH);
  delay(t1);
  }
  for(int pin = 13; pin >= 2; pin--)
  {
    digitalWrite(pin, LOW);
  delay(t1);
    }
  }
  /////////////////////////////////////////////////////////////////////////////Effect 6
void effect_6()
{
for(int j=2; j<14; j++){
  digitalWrite(j, LOW);
  delay(t);
  digitalWrite(j, HIGH);
  delay(t);
  digitalWrite(j-2, LOW);
  delay(t);
  digitalWrite(j, HIGH);
}
for(int k = 15; k>2; k--){
  digitalWrite(k, LOW);
  delay(t);
  digitalWrite(k, HIGH);
  delay(t);
  digitalWrite(k+2, LOW);
  delay(t);
  digitalWrite(k, HIGH);
}
for(int k = 2; k<14; k++){
  digitalWrite(k, LOW);
  delay(t);
  digitalWrite(k, HIGH);
  delay(t);
  digitalWrite(k-2, LOW);
  delay(t);
  digitalWrite(k, HIGH);
}
for(int k = 15; k>2; k--){
  digitalWrite(k, LOW);
  delay(t);
  digitalWrite(k, HIGH);
  delay(t);
  digitalWrite(k+4, LOW);
  delay(t);
  digitalWrite(k, HIGH);
}
for(int k = 2; k<14; k++){
  digitalWrite(k, LOW);
  delay(t);
  digitalWrite(k, HIGH);
  delay(t);
  digitalWrite(k-4, LOW);
  delay(t);
  digitalWrite(k, HIGH);
}
}
///////////////////////////////////////////////////////////////////////////////////Effect 7
void effect_7()
{
for(int j=2; j<14; j++){
  digitalWrite(j, HIGH);
  delay(t);
  digitalWrite(j+2, LOW);
  delay(t);
}
for(int k = 15; k>2; k--){
  digitalWrite(k, HIGH);
  delay(t);
  digitalWrite(k+2, LOW);
  delay(t);
}
}

// function to switch all LEDs off
void clear(void)
{
  for (int i = 2; i <= 13; i++) {
    digitalWrite(i, LOW);
  }
}

Step 5: Enjoy:)

After completing the circuit, connect the Arduino Uno to the computer, upload the code, and you've finished. Enjoy the arduino led chaser with some cool effects. Let me know if you guys having any problem.

Thank you for sticking to the end. I hope you all love this project and learned something new today. Let me know if you make one for yourself. Subscribe to my YouTube channel for more upcoming projects. Thank you once again!
