Arduino Prototyping Shield

Introduction: Arduino Prototyping Shield

About: I'm a 13 year old dude with a arduino obsession.

Hi guys girls, and robots I'm 13 years old and this is my Arduino Prototyping station. The basics are pretty simple. I soldered a prototyping sheild for my arduino

Step 1: Get Stuff

Some stuff you need

>assorted wood(I used plywood and some spare walnut)

>bread board

>arduino I used an uno

>male/female arduino headers

>perf board with copper

>a tone of jumpers!!!! (1 for each arduino pin

>4-40 bolts and tap

>4-40 stand off

The tools you will need

> soldering iron

> solder

> solder wick

> saw to cut ply wood

> screw driver for bolts

Step 2: Assemble

This part I won't be giving detailed directions the only really important part I you need to ruff up the back side of the bread board to get the bread board off unscrew or pry. solder in between the joints, you know like gnd on arduino will go to gnd on bread board. Good luck. :-)
