Introduction: Arduino UNO R4 Simple Game

By

I tried to make a simple game with the Arduino R4 board, I only added the GY-521 accelerometer sensor


Supplies

Step 1:

I simply searched the web for a tutorial on how to connect a GY-521 to Arduino


Step 2:

Then I asked chatGPT to create a code for me to create the game you see in the video, I made various attempts and corrections, among these I asked that the GY-521 sensor be initialized as a horizontal position at the first start of the game (turning on the Arduino) and I also asked to store the record (if created) in the Arduino internal memory (Eprom). In this way the record will be stored even when the Arduino is turned off.


Step 3:

And here is the code I created with the help of chatGPT

//sensore GY-521 accellerometro giroscopio SDA A4 SCL A5 VCC 3,3V

#include <Arduino_LED_Matrix.h>
#include <EEPROM.h>
#include <Wire.h>



ArduinoLEDMatrix matrix;

const uint32_t animation[][4] = {
{
0x7008810,
0x40200201,
0xac18c000,
66
},
{
0x1040f800,
0x200201,
0xac18c000,
66
}
};

// Frame della matrice LED
uint8_t frame[8][12] = {0};

#define ROWS 8
#define COLUMNS 12

// Variabili di posizione del LED
int pointX = COLUMNS / 2;
int pointY = ROWS / 2;
int R = 0;

// Indirizzo del GY-521
const int MPU_ADDR = 0x68;

// Variabili per il gioco
int fixedX, fixedY;
int score = 0;
unsigned long startTime;
unsigned long elapsedTime;
bool gameActive = true;

// Variabili per il record
const int RECORD_ADDR = 0; // Indirizzo EEPROM per il record
unsigned long bestTime = 999999; //RECORD CHE VIENE SALVATO

// Variabili per i dati del sensore
int16_t accX, accY;
int16_t baseAccX = 0, baseAccY = 0;

void setup() {
Serial.begin(115200);
delay(1500); //EEPROM.put(RECORD_ADDR, 99999); ///per resettare il record in memoria

matrix.begin();

// Inizializza il sensore GY-521
Wire.begin();
Wire.beginTransmission(MPU_ADDR);
Wire.write(0x6B); // Registro di alimentazione
Wire.write(0); // Sveglia il sensore
Wire.endTransmission(true);

// Calibrazione
calibrateSensor();

// Carica il record dalla EEPROM
EEPROM.get(RECORD_ADDR, bestTime);

// Genera il primo obiettivo
generateTarget();
startTime = millis();
}

void loop() { /////////////LOOP
if (gameActive) {
updatePosition();
checkCollision();
renderGame();
} else {
displayResults();
}
} /////////////LOOP

void calibrateSensor() {
Serial.println("Calibrating... Please hold the board still.");
delay(2000);
Wire.beginTransmission(MPU_ADDR);
Wire.write(0x3B);
Wire.endTransmission(false);
Wire.requestFrom(MPU_ADDR, 4, true);
baseAccX = (Wire.read() << 8 | Wire.read());
baseAccY = (Wire.read() << 8 | Wire.read());
}

void updatePosition() {
// Leggi il sensore
Wire.beginTransmission(MPU_ADDR);
Wire.write(0x3B);
Wire.endTransmission(false);
Wire.requestFrom(MPU_ADDR, 4, true);
accX = (Wire.read() << 8 | Wire.read());
accY = (Wire.read() << 8 | Wire.read());

int deltaY = map((int32_t)(accX - baseAccX), -17000, 17000, -1, 1);
int deltaX = map((int32_t)(accY - baseAccY), -17000, 0, -1, 1);

if (!(pointX == 0 && deltaX < 0) && !(pointX == COLUMNS - 1 && deltaX > 0)) {
pointX += deltaX;
}
if (!(pointY == 0 && deltaY < 0) && !(pointY == ROWS - 1 && deltaY > 0)) {
pointY += deltaY;
}
}

void generateTarget() {
fixedX = random(0, COLUMNS);
fixedY = random(0, ROWS);
}

void checkCollision() {
if (pointX == fixedX && pointY == fixedY) {
// Effetto luce piena
memset(frame, 1, sizeof(frame));
matrix.renderBitmap(frame, ROWS, COLUMNS);
delay(300);

score++;
if (score >= 7) { /////NUMERO DEI TARGET
gameActive = false;
elapsedTime = millis() - startTime;
if (elapsedTime < bestTime) { /////EPROM RECORD
R = 1;
bestTime = elapsedTime;
EEPROM.put(RECORD_ADDR, bestTime);
}
} else { R = 0;
generateTarget();
}
}
}

void renderGame() {
memset(frame, 0, sizeof(frame));

// Gestione del lampeggio dell'obiettivo
static unsigned long lastBlinkTime = 0;
static bool targetVisible = true;
if (millis() - lastBlinkTime >= 100) {
lastBlinkTime = millis();
targetVisible = !targetVisible;
}
if (targetVisible) {
frame[7 - fixedY][fixedX] = 1; // Obiettivo lampeggiante
}

frame[7 - pointY][pointX] = 1; // Giocatore
matrix.renderBitmap(frame, ROWS, COLUMNS);
delay(100);
}

void displayResults() {

Serial.println (R);
Serial.println (elapsedTime);
Serial.println (bestTime);


if (R == 1) {
matrix.loadFrame(animation[0]);
}
else {
matrix.loadFrame(animation[1]);
while (true); // Blocca il programma finché non viene premuto il reset
}
}


That's all. Have fun!
