Introduction: Arduino Ultra Sonic Distance Sensor
In this Arduino Tutorial we will learn how to use the HC-SR04 Ultrasonic Sensor to display the distance measured on LCD.
Step 1: Objective:
The objective of this project is to measure distance using the HC-SR04 Ultrasonic Sensor, and then display that value on the LCD display.
Step 2: Hardware Required :
-Arduino board (I used the Arduino UNO) https://amzn.to/2zvsEl3
- HC-SR04 Ultrasonic Sensor https://amzn.to/2TSitQb
-5kΩ pot (Other potentiometer can do the job) https://amzn.to/2TSPQ5C
-LCD display (2*16) https://amzn.to/2SghK9N
-Breadboard and wires https://amzn.to/2ScF4VY
Step 3: Connecting:
--For the LCD:
connect the Cathode to Arduino GND
anode to arduino 5v
D7 to Arduino pin 2
D6 to Arduino pin 3
D5 to Arduino pin 4
D4 to arduino pin 5
E to Arduino pin 9
R/W to Arduino GND
RS to Arduino pin 10
VO to the pot
Vcc to Arduino 5v
GND to Arduino GND
--Connecting the sensor:
Vcc to Arduino 5v
Trigger to Arduino pin 13
Echo to Arduino pin 11
Gnd to Arduino GND
--Then connect the pot to GND and Vcc as shown in the figure.
Step 4: Arduino Code:
#include <LiquidCrystal.h> //Load Liquid Crystal Library
LiquidCrystal LCD(10, 9, 5, 4, 3, 2); //Create Liquid Crystal Object called LCD
int trigPin=13; //Sensor Trip pin connected to Arduino pin 13
int echoPin=11; //Sensor Echo pin connected to Arduino pin 11
int myCounter=0; //declare your variable myCounter and set to 0
int servoControlPin=6; //Servo control line is connected to pin 6
float pingTime; //time for ping to travel from sensor to target and return
float targetDistance; //Distance to Target in inches
float speedOfSound=776.5; //Speed of sound in miles per hour
void setup() {
Serial.begin(9600);
pinMode(trigPin, OUTPUT);
pinMode(echoPin, INPUT);
LCD.begin(16,2); //Tell Arduino to start your 16 column 2 row LCD
LCD.setCursor(0,0); //Set LCD cursor to upper left corner, column 0, row 0
LCD.print("Target Distance:"); //Print Message on First Row
}
void loop() {
digitalWrite(trigPin, LOW); //Set trigger pin low
delayMicroseconds(2000); //Let signal settle
digitalWrite(trigPin, HIGH); //Set trigPin high
delayMicroseconds(15); //Delay in high state
digitalWrite(trigPin, LOW); //ping has now been sent
delayMicroseconds(10); //Delay in high state
pingTime = pulseIn(echoPin, HIGH); //pingTime is presented in microceconds
pingTime=pingTime/1000000; //convert pingTime to seconds by dividing by 1000000 (microseconds in a second)
pingTime=pingTime/3600; //convert pingtime to hourse by dividing by 3600 (seconds in an hour)
targetDistance= speedOfSound * pingTime; //This will be in miles, since speed of sound was miles per hour targetDistance=targetDistance/2; //Remember ping travels to target and back from target.
targetDistance= targetDistance*63360; //Convert miles to inches by multipling by 63360 (inches per mile)
LCD.setCursor(0,1); //Set cursor to first column of second row
LCD.print(" "); //Print blanks to clear the row
LCD.setCursor(0,1); //Set Cursor again to first column of second row
LCD.print(targetDistance); //Print measured distance
LCD.print(" inches"); //Print your units.
delay(250); //pause to let things settle
}
