Binary LED Marble Clock




Introduction: Binary LED Marble Clock

Now I think just about everybody has a binary clock and here's my version. What I enjoyed was that this project combined some woodwork, programming, learning, electronics and perhaps just a little artistic creativity.

It shows time, month, date, day of week, temperature and humidity on the marble display in a binary form - an illuminated marble is "on" and represents a digit. All this info is also displayed on an oled display in a conventional way. There is provision to set the time from the computer, daylight saving is easily adjusted and there is an ability to "bump" the time to the top of the hour by using an external radio signal or other accurate source.

Many of the binary clocks you see use separate columns for minute, tens of minutes, hours and tens of hours, so you assemble the time by reading each individual column which represents a number and so a single digit of the time. Mine is different because you add together the binary values for minute in one string and hours in another string. The pictures will help, but the minutes string is six bits, from the rightmost end which is the least significant to leftmost end which is the most significant representing one, two, four, eight, sixteen and thirty two minutes. You arithmetically add the individual values. The Hours is likewise, one to eight hours.

Various colours indicate what function is currently being displayed. Magenta for month, yellow for date, green for day of week, red for temperature, blue for humidity and random colours for time. The display cycles through all functions and the delay pause can be set in the code.

The clock looks really cool at night in a darkened room although it's hard to take good photos that show the intensity.

Step 1: Clock Program Features

A few comments on some software features of the clock.

Time setting: Many of the Arduino examples which use an rtc are casual in how they set the time. Very often they use the compile time of the sketch to set the rtc if it is not already set. Since you don't know how long the compile and download will take this is clumsy, also if the clock has been previously set then the time is not updated.

I have put a flag (KBSetTime = true | false) within the code that will, if set upon download, cause a serial window to open and prompt for time entry. The time is precisely set to the rtc when enter is pressed.

Accuracy: The DST3231 module has a specified accuracy of +/- 2 ppm, which is about 1 min per year at normal temperatures. To allow for correction of this drift there is a "bump" button provided. The idea is that when you hear the time source signal pips that are broadcast over the radio the bump button is pressed and the time is adjusted to the "top of the hour". To prevent wandering fingers I have limited this feature to only be active in the range of five to or five past the hour.

Daylight Saving: is problematic! The clock isn't sync'd to any external source that is DST aware, so there's no way to automatically adjust , like say a phone would do due to it's connection to a networke tower. In older versions of Windows they just use a file which has dates in it that specify when the change should occur, for this you need to know, in advance and with certainty the change dates - how far do we go, what is the expected life of the clock, what if we move jurisdictions? etc etc Other approaches rely on a fixed specification eg 2nd Sunday in March, but this has problems too - not every locality adjusts at the same time, special events may move this "fixed" change point. For these reasons I decided on a different approach that lets the user easily make the adjustment - a slide switch is set to specify moving into or out of daylight saving, then a push button is pressed. This will either add or subtract exactly an hour to the current time. The accuracy of dates is maintained in case you do it at say 23:45hrs.

Expansions: As is the clock displays in 12h format, with four leds for hours the max is 8+4+2+1 = 15, so you could add an extra led if 24h hour format is desired. Alternatively you could add a way to indicate am or pm. The software libraries and interface to the clock module will all allow these easily should it be desired.

Step 2: Bits & Bobs - the Pieces

The Arduino world has an array of interesting bits, all remarkably cheap from ebay, ali barber and so on. There's lots of guidance and advice available too. Here's what I used;

  • Nano arduino, cheap, powerful, educational - this project ends up using about 80% of the code space
  • DS3231 - real time clock module that maintains time, 2 ppm accuracy that is about 1 min / year
  • SSD1306 oled display, 128 x 32 pixels
  • WS8212 leds - serially controlled leds, 3 wire, individual led colour set by 3 byte RGB string
  • DHT22 - temperature and humidity module. A capacitive humidity sensor and a thermistor
  • miscellaneous switches, push buttons - power supply with connector to fit Arduino

It might have been nicer to use capacitive touch switches in place of push buttons. An example would be TTP223

A note on the DS3231 rtc module: If you use this with a lithium button cell like a CR2032 (and most people will) you need to cut the battery charge trace on the module. An internet search will reveal info and reasons on this. The picture above illustrates the trace to be cut.

Step 3: Wiring

The diagram shows the wiring connections.

Step 4: Code

The code is presented here and you can just download and use it. You need the Arduino environment installed.

Hopefully it is commented sufficiently to allow it to be followed and modified by anyone with some Arduino skills.

The Arduino world has many libraries where smart folk make it easy for the rest of us to use devices. There's no point reinventing the wheel so I made use of the following libraries;

  • TimeLib.h - for use and management of time functions
  • DS3223RTC.h - for access to the rtc module
  • Adafruit_NeoPixel.h - for using the serial leds
  • DHT.h - for the humidity and temperature sensor
  • Streaming.h - for easy interaction with the serial window
  • U8glib.h - for the Oled display

the IC2 bus is used, this is inbuilt into the Arduino, the rtc and oled modules and associated libraries - it's all transparent to the use because of the libraries mentioned above

Interrupts. These are used for the bump to hour and daylight saving adjust routines. The former because it needs to happen in a time critical manner and the latter because it will be infrequently used.

The pause delay for the display times for each display feature can be adjusted by the show_xxxx_delay constants. eg the red temperature leds being displayed is set to 4000 ms or 4 seconds by the line

const unsigned long show_temp_delay = 4000;

Variations of colour can be made by editing the lines - it's just three hex values each 00..ff for RGB

#define Yellow   leds.Color(0xff, 0xff, 0x00)     // colour for day display

Step 5: Woodwork

I started with a piece of pine that was in the garage, cut to length as needed. The marbles sit in recessed pockets, so from the front face you drill a larger hole the diameter of the marble to the depth you want and then drill a smaller hole to allow the light to see the back of the marble. With the holes drilled I used a plunge router to carve out a pocket from the rear to house the electronics.

I cut a small recess on the top surface so the Oed display would sit flush.

The back piece is cut to size and provision made for the buttons and DHT sensor.

I stained the pine with a homemade stain mix and applied a coat of wax to give a satin finish

Step 6: Electronics Assembly

I mounted the leds on a strip of wood - this was mainly to make them easier to handle as I was playing around and prototyping. They need a connections for 5V, 0V and data. The data pin connection from the arduino must go to the one minute led first as the leds are addressed by position in the string. The eight hour led is the last in the string and there is no terminator required.

Drill a few holes to mount the switches and sensor on the rear panel. Hot glue can be used to hold things in place. It might have been nicer to use touch switches for these.

The Arduino and rtc module were mounted on patch board. This just makes it easier to solder everything together. Links are made with single strand copper wire.

Ribbon cable provides neat connections to the rear panel mounted switches and sensor and allows the case to be opened up.

A piece of plastic from a milk bottle was used between the led strip and patch board to prevent anything shorting out.

Screw the back on and you're done. The clock can be powered by a USB port from a computer or a plug pack into the wall. Without USB power applied there is no display, but the battery on the rtc module maintains the time.

Enjoy it in a dimly lit room and quiz your visitors as it attracts some attention in the form of "what is that!?"

Clocks Contest

Participated in the
Clocks Contest

Be the First to Share


    • Photography Challenge

      Photography Challenge
    • Anything Goes Contest 2021

      Anything Goes Contest 2021
    • New Year, New Skill Student Design Challenge

      New Year, New Skill Student Design Challenge



    3 years ago

    Hi to everyone,
    has anyone tried to built this, yet?
    I tried, but I get a bunch of errors during compilation.
    Also I'm not sure if have installed the right libraries.
    There are so many similar names and each one has a lot of older versions.
    It would be really useful to add the name oft the author and the version of the library which
    was used in the project.
    Are the following errors related to the libraries or are the declarations missing in the code itself?

    Arduino: 1.8.5 (Windows 10), Board: "Arduino/Genuino Uno"
    C:\Users\Win Dows\Desktop\Arduino Projekte\BinClock_V09\BinClock_V09.ino: In function 'void loop()':
    BinClock_V09:121: error: 'ZeroSec' was not declared in this scope
    if (IntFlag) ZeroSec(); //check for an interupt
    BinClock_V09:124: error: 'DS_bump' was not declared in this scope
    if (DstBumpIntFlag) DS_bump (); //check for an interupt
    BinClock_V09:137: error: 'draw' was not declared in this scope
    BinClock_V09:143: error: 'show_time' was not declared in this scope
    show_time ();
    BinClock_V09:149: error: 'show_day_of_week' was not declared in this scope
    show_day_of_week ();
    BinClock_V09:154: error: 'show_month_date' was not declared in this scope
    show_month_date ();
    BinClock_V09:159: error: 'show_temp' was not declared in this scope
    show_temp ();
    BinClock_V09:164: error: 'show_humidity' was not declared in this scope
    show_humidity ();
    exit status 1
    'ZeroSec' was not declared in this scope


    Reply 3 years ago

    All of the errors above are calls to routines that are in tabs within the IDE. These are not related to the libraries. I put the routines in separate tabs just to aid readability and follow ability. Looks like you haven't loaded all the tabs into your IDE?

    The DHT lib was the one from adafruit. The rest are pretty common and mostly newer versions will be backwards compatible - but this isn't your problem.


    Reply 3 years ago

    Hi shawvale,

    Thank you very much for your answer.
    The download link above is only for the .ino.
    There are no tabs with routines.
    Aren't these normally packed together with the .ino in one (zipped) folder?

    I'm really looking forward to built this clock. There are many binary clocks out there
    but this one imho is the best. The binary theme combined with the oled display is great.
    Also the the temperature and humidity add on makes this clock stand out from the rest.
    The marbles as diffusors for the light are beautiful, although I'm looking for something
    bigger, as I want to built something to hang onto the wall. Some crystals maybe or the biggest marbles I can get .
    As my desk normally looks more like a workbench, a small desktop clock would be
    buried under my various projects most of the time.
    Thank you very much for sharing this great project and your hard work to create it.



    Reply 3 years ago

    Sorry Technikker, looks like what I originally uploaded only had the first tab in it :redface I thought everything went along with the first tab - maybe it did in other versions of the IDE.

    I have now uploaded a zip with everything in it, so you should be right now. Looks like your the only one who tried to build this. Thanks for the feedback.


    Reply 3 years ago

    Thank you for your support, shawvale, I've just made a quick breadboard built without the buttons and the switch and tried it. It works perfect now, without problems.
    I don't have the equipment for woodwork and as mentioned before I want a wall version. So from here on I'll have to part with your design. I'll post the result in the "Made it" section, but it can take a while to finish it.


    3 years ago

    I second that, the marbles are a nice touch. Thanks for making the effort to share. People sharing is what inspires others.

    Alex in NZ
    Alex in NZ

    3 years ago

    Beautiful. I love the use of the glass marbles as diffusers for the LEDs. Thank you for sharing this :-)
