Introduction: Building a Low-Power Inverter Using ICL7662CBA

By
About: Eiyu | Electronic Components Specialist Providing expert insight in sourcing, modules, and supply chain strategy at Eiyu—a top distributor of components from 1,000+ global brands.

In the world of electronics, creating efficient and reliable power supplies is a critical task, especially for battery-powered devices. In applications such as portable electronics, automotive systems, or power management circuits, there is a growing demand for low-power inverters to generate negative voltages from positive voltage rails. One of the most efficient ways to achieve this is by using charge pump ICs like the ICL7662CBA.

The ICL7662CBA is a high-efficiency voltage inverter designed to generate a stable negative voltage from a positive input. It can be used in a wide range of applications, including power supplies for op-amps, negative voltage generation for analog circuits, and general-purpose low-voltage inverters.

In this project, we will design a low-power inverter circuit using the ICL7662CBA to convert a positive 5V supply to a stable -5V output.

Objective

The goal of this project is to create a negative voltage generator using the ICL7662CBA. The generated negative voltage can be used to power circuits that require negative voltage rails, such as operational amplifiers, analog signal processing, or other analog components that operate with dual-supply voltages.

Key Features of ICL7662CBA:

  1. Wide Input Voltage Range: It supports an input voltage from 1.5V to 12V, making it versatile for various applications.
  2. High Efficiency: The charge pump design ensures high efficiency, with minimal loss.
  3. Low Quiescent Current: Ideal for battery-operated systems.
  4. Compact Size: Available in a small 8-Pin SOIC package, suitable for space-constrained applications.
  5. Output Voltage Range: Capable of providing a stable negative voltage output, typically around -1.5V to -12V depending on the input voltage.

Supplies

  1. ICL7662CBA – Voltage inverter IC
  2. Capacitors:
  3. C1 = 1µF (Input Capacitor)
  4. C2 = 10µF (Output Capacitor)
  5. C3 = 1µF (Flying Capacitor)
  6. Resistors (optional for output adjustment)
  7. Diodes (internal to ICL7662, no external diodes required)
  8. Power Supply: 5V DC (can be provided by a battery, USB, or DC power adapter)
  9. Multimeter for measuring output voltage
  10. Breadboard or PCB for assembling the circuit
  11. Wire leads and connectors (for easy testing)

Step 1: Circuit Schematic

ICL7662CBA Overview

The ICL7662CBA operates as a charge pump inverter, which means it uses capacitors and a switching mechanism to invert the input voltage. It uses an internal oscillator to alternate the charge between capacitors, allowing it to generate a negative voltage on the output pin.

Here is a basic breakdown of the pins:

  1. Pin 1 (V+ or VIN): Input voltage (+5V)
  2. Pin 2 (GND): Ground
  3. Pin 3 (VOUT): Output negative voltage (-5V)
  4. Pin 4 (V-): Connection to the flying capacitor (internal)
  5. Pin 5 (NC): No connection
  6. Pin 6 (CAP): Flying capacitor (typically 1µF)
  7. Pin 7 (C1): Input capacitor (typically 1µF)
  8. Pin 8 (C2): Output capacitor (typically 10µF)

Here is the simplified schematic for the inverter:

  1. Power Input: Apply a +5V DC supply to Pin 1 (V+) and Ground to Pin 2 (GND).
  2. Capacitors:
  3. C1 (1µF): Connect between Pin 1 (V+) and Pin 2 (GND). This capacitor helps filter the input voltage.
  4. C2 (10µF): Connect between Pin 3 (VOUT) and Pin 2 (GND). This capacitor helps stabilize the output voltage.
  5. C3 (1µF): Connect between Pin 4 (V-) and Pin 2 (GND). This capacitor is part of the internal charge pump circuit that helps invert the voltage.
  6. Output Voltage: The negative voltage (-5V) will appear at Pin 3 (VOUT).

Step 2: Operation of the Charge Pump Inverter

  1. The ICL7662CBA works by switching the flying capacitor between the positive input and ground to generate a negative output.
  2. It uses an internal oscillator to create a square wave that alternates the charging and discharging of capacitors, allowing the circuit to "invert" the input voltage.
  3. The flying capacitor is the key to this operation. It alternates between connecting to the input voltage and the ground, inverting the potential and resulting in a negative voltage at the output.

Step 3: Output Voltage

The output voltage, VOUT, will be approximately equal to the negative value of the input voltage (e.g., for a 5V input, the output will be -5V). This output is suitable for powering components that require negative voltages, such as op-amps, analog circuits, or signal conditioning circuits.

Step 4: Efficiency Considerations

The ICL7662CBA is designed to operate with high efficiency, typically greater than 70%. However, efficiency can be affected by factors such as:

  1. The quality of the capacitors used (especially the flying and output capacitors).
  2. The load current: Higher current demands may result in a slight decrease in efficiency.
  3. The input voltage: The chip operates optimally with input voltages between 3V and 12V, with 5V being ideal for most applications.

Step 5: Testing and Verification

1. Powering the Circuit

After assembling the circuit on a breadboard or PCB, connect the +5V input to Pin 1 (V+) and ground to Pin 2 (GND).

2. Measuring Output

Use a multimeter to measure the output voltage at Pin 3 (VOUT). The expected output should be -5V (given a 5V input). If using different input voltages, the output will scale accordingly.

3. Load Testing

To test the performance under load, connect a small load resistor (e.g., 10kΩ) to the output and measure the voltage. The voltage should remain stable, with only a slight drop under load.

4. Troubleshooting

If the output voltage is not correct:

  1. Ensure that the capacitors are properly placed and have the correct values.
  2. Check the connections, especially to the flying capacitor and output capacitor.
  3. Verify the power supply is providing the correct voltage.

Applications of the ICL7662CBA Inverter

The ICL7662CBA voltage inverter is suitable for various applications:

  1. Negative Voltage Generation for powering analog circuits (e.g., op-amps).
  2. Battery-Powered Devices where efficiency and low power consumption are important.
  3. Voltage Regulation in multivoltage systems, such as signal conditioning or bi-polar power supplies.
  4. Low-Power Sensors that require dual supply voltage rails (positive and negative).

Conclusion

The ICL7662CBA is a versatile and efficient IC for generating negative voltages from a positive supply. In this project, we have demonstrated how to use it to create a low-power negative voltage inverter circuit. With a simple setup and high efficiency, the ICL7662CBA offers a great solution for applications needing negative voltage rails, such as op-amps, analog sensors, and various other analog circuits.

By carefully selecting components and testing the circuit, you can build a robust and reliable voltage inverter for your electronic systems.
