Completely 3D Printed Model Rocket Using Tinkercad.

Introduction: Completely 3D Printed Model Rocket Using Tinkercad.

About: I love to make lots of things from 3D printing to Knitting. I enjoy designing with Tinkercad, and printing on my FlashForge Creator pro.

Have you ever wanted to fly a rocket, but you don't want to pay the price for cheaply made industrial model rockets, or wanted to feel the thrill of making one yourself, or simply just bored with a 3D printer, well this rocket is for you then! This rocket is a completely self designed, 3D printed, fully functional, Reusable, and Fun Model rocket. This rocket was designed with Tinkercad, and 3D Printed Using a FlashForge Creator Pro 3D printer.

Supplies

  • Access to Tinkercad (or other 3D C.A.D. platform)
  • 3D printer filament (I used PLA)
  • 3D printer
  • Super glue
  • Model rocket engine(s)

Step 1: Picking the Right Model Rocket Engine

Before we can design a rocket we need to know what size engine we will use. I would recommend using a smaller model rocket engine like an Estes B6-4 this is a great Model rocket engine that isn't too big or too pricey but still powerful enough too launch a model rocket high into the sky! I based my design off this engine. You can use other rocket engines just your results may very.

Step 2: Taking Measurements

To know what size we need to build our rocket we need to know the size of the engine, that our rocket is built around. My Estes B6-4 measured to be about 18mm In diameter and about 70mm in length. Other rocket engines will be different in size so be sure to know what engine you have.

Step 3: Designing the Nose Cone

To make our rocket aerodynamic so it can fly through the air with the least resistance we will need to give it a nose cone . Making a nose cone can help our rocket fly higher and faster and fly for a longer amount of time. we need a nose cone that can fit over the top of the engine so we can glue it on. I used the tinkercad generated shape called the Ogive and a hollowed out cylinder with an inner diameter of 2mm more than the outer diameter of the rocket engine (In my cases for the B6-4, it was exactly 20mm ). And the outer diameter of the cylinder was exactly 6mm bigger than the outer diameter of the rocket engine. make this hollowed cylinder at least 12mm tall so that it will ensure a tight fit. Set the diameter of the ogive to the same diameter of the outer diameter of the cylinder. Now you will need to align the ogive and the cylinder on both the x and the z axes using the align tool. and make sure that the bottom of both shapes is at the y value of 0 (touching the work plane) now move the ogive up by the height of the cylinder. Now the lsat step to designing the nose cone is to group the cylinder and the ogive using the group tool.

Step 4: Designing the Fins

Our rocket needs to fly in a straight line to do this we will need to give it fins. I used a tapered cylinder with the same dimensions from Step 3 then used 1/2 Ogive slices to make the fins you can do this by taking an ogive and placing it in between 2 equal-sized holes that are spaced apart by your desired fin width. Then I created 3 more fins for a total of 4 fins then I used the align tool to make sure that the fins were placed equally Apart.

Step 5: Print and Assembly

Next, we need to print our rocket, I used PLA which is slightly stronger and more rigid than ABS. I used regular print settings to print. when the rocket is done printing you will need to remove all of the supports if your printer uses them. now we need to assemble our rocket first we can take our nose cone and place super glue around the circumference of the top of the model rocket engine and place insert the glued engine top al the way into the nose cone. After this, you will need glue the fins on which can be done by placing superglue around the circumference of the bottom of the rocket motor and sliding the fins up so that the fin base will completely cover the bottom of the rocket. Now, wait for your glue to set and dry.

Step 6: Decorating Your Rocket!

This step is optional, but I would highly recommend it for two reasons, one it makes your rocket look awesome and two it can help you find your rocket after launching. I decorated my rocket with bright markers and reflective tape.

Step 7: Using Your Rocket

You will need a way to ignite your rocket engine from a safe distance, there are multiple ways that you can do this but I would just use the long fuse that comes with most rocket engines. Just be sure that however you light off you rocket you do it from a safe distance.

Step 8: Recovering Your Rocket!

If you want to be able to reuse your rocket multiple times you will of coarse have to find it after a launch. If you decorated your rocket with reflective materials it will be a lot easier to find.

Step 9: Printing Files

If you are using An Estes B6-4 or any similarly sized rocket engine the files below are what I designed as my rocket.

https://www.tinkercad.com/things/eyz9u8kw4wW-b6-4-model-rocket

Space Challenge

Participated in the
Space Challenge

Be the First to Share

    Recommendations

    • Summer Fun: Student Design Challenge

      Summer Fun: Student Design Challenge
    • Fandom Contest

      Fandom Contest
    • DIY Summer Camp Contest

      DIY Summer Camp Contest

    3 Comments

    0
    gizmologist
    gizmologist

    1 year ago

    Have you actually flown this rocket? Those fins look a little small.
    Also, I don't know where you're getting your model rocket motors, but in the U.S. motors do not come with a fuse. The model rocket safety code requires an electrical launcher so launches can be aborted at any time.

    0
    cmatthewking
    cmatthewking

    Reply 1 year ago

    The fins were not originally that small, if you look at the image in step 5 when they printed they were significantly larger. Yes I have flown the rocket and it worked until it slowed down when approaching Apogee it became very unstable due to the small fin area but if I decided to fly to t with the larger fins and the fins that I linked below I’m sure that it would have flown a bit better. Regarding the fuse I assumed that my fuses came with a model rocket because I just found them in bin of model rocket stuff.

    0
    seamster
    seamster

    1 year ago

    Nice work, model rockets are great fun and a fantastic hobby! : )
