Introduction: Connect Your Magicbit to Thingsboard

In this project we are going to send data from sensors connected to magicbit which we can display visually on thingsboard.


  • Magicbit
  • DHT11 Temperature & Humidity Sensor (4 pins)

Step 1: Story


ThingsBoard is an open-source server-side platform that allows you to monitor and control IoT devices. It is free for both personal and commercial usage and you can deploy it anywhere. If this is your first experience with the platform we recommend to review what-is-thingsboard page and getting-started guide.

This sample application will allow you to display humidity/temperature data from DHT11 sensor using your magicbit device and ThingsBoard web UI.

The application that is running on Magicbit device is written using ThingsBoard Arduino SDK which is quite simple and easy to understand.

Once you complete this sample/tutorial, you will see your sensor data on the following dashboard.

Visit the Thingsboard Demo official page and get signed up.

After Signing in On the Left Side Bar you will see Devices. Click devices and add a new device.

On the credentials tab tick Add credentials tab and choose Access Token from the drop down box. Either you can add your own Access Token or leave blank to auto generate token.

Set device to magicbit in alias. Go to the dashboard tab and import dashboard.

Follow the following steps in images to Import the dashboard. Find the demo JSON file called "magicbit_temperature_humidity_demo_dashboard.json" in attachments.

Connect your magic bit with DHT11 module as follows to pin 33.

In the Arduino IDE download the above libraries.

The following is the Arduino code you will be using.

Note You need to edit following constants and variables in the sketch:

  • WIFI_AP - name of your access point
  • WIFI_PASSWORD - access point password
  • TOKEN - the $ACCESS_TOKEN from ThingsBoard configuration step.
  • THINGSBOARD_SERVER - ThingsBoard HOST/IP address that is accessible within your wifi network. Specify if you are using live demo server.

Step 2: Arduino Code

#include <DHT.h>           // DHT for Library library
#include <WiFi.h> // WiFi control for ESP32
#include <ThingsBoard.h> // ThingsBoard SDK

#define DHTPIN 33 // what digital pin we're connected to

#define DHTTYPE DHT11 // DHT 11

// Helper macro to calculate array size
#define COUNT_OF(x) ((sizeof(x)/sizeof(0[x])) / ((size_t)(!(sizeof(x) % sizeof(0[x])))))

// WiFi access point
#define WIFI_AP_NAME "4G"// "WIFI_AP"
// WiFi password
#define WIFI_PASSWORD "nevergiveup"// "WIFI_PASSWORD"

// See
// to understand how to obtain an access token
#define TOKEN "XZjQ26r9XJcsNkWGuASY" // "TOKEN"
// ThingsBoard server instance.

// Baud rate for debug serial
#define SERIAL_DEBUG_BAUD 115200

// Initialize ThingsBoard client
WiFiClient espClient;
// Initialize ThingsBoard instance
ThingsBoard tb(espClient);
// the Wifi radio's status
int status = WL_IDLE_STATUS;

// Period of sending a temperature/humidity data.
int send_delay = 2000;
unsigned long millis_counter;
void InitWiFi()
Serial.println("Connecting to AP ...");
// attempt to connect to WiFi network

while (WiFi.status() != WL_CONNECTED) {
Serial.println("Connected to AP");

void reconnect() {
// Loop until we're reconnected
status = WiFi.status();
if ( status != WL_CONNECTED) {
while (WiFi.status() != WL_CONNECTED) {
Serial.println("Connected to AP");

// Setup an application
void setup() {
// Initialize serial for debugging

// Initialize temperature sensor

// Main application loop
void loop() {

// Reconnect to WiFi, if needed
if (WiFi.status() != WL_CONNECTED) {

// Reconnect to ThingsBoard, if needed
if (!tb.connected()) {
// Connect to the ThingsBoard
Serial.print("Connecting to: ");
Serial.print(" with token ");
if (!tb.connect(THINGSBOARD_SERVER, TOKEN)) {
Serial.println("Failed to connect");

// Check if it is a time to send DHT11 temperature and humidity
if(millis()-millis_counter > send_delay) {
Serial.println("Sending data...");

// Uploads new telemetry to ThingsBoard using MQTT.
// See
// for more details
float h = dht.readHumidity();
// Read temperature as Celsius (the default)
float t = dht.readTemperature();

if (isnan(h) || isnan(t)) {
Serial.println("Failed to read from DHT sensor!");
} else {
Serial.print(" Humidity ");
tb.sendTelemetryFloat("temperature", t);
tb.sendTelemetryFloat("humidity", h);

millis_counter = millis(); //reset millis counter

// Process messages

Step 3: Data Visualization

In live-demo server:

  • login: your live-demo username (email)
  • password: your live-demo password

See live-demo page for more details how to get your account.

Go to “Devices” section and locate “Magicbit”, open device details and switch to “Latest telemetry” tab. If all is configured correctly you should be able to see latest values of “temperature” and “humidity”.

After, open “Dashboards” section then locate and open “magicbit_temperature_humidity_demo_dashboard”. As a result, you will see a time-series chart displaying temperature and humidity level (similar to dashboard image in the introduction).
