Introduction: Connecting Arduino Uno to Crystalfontz 16x2 OLED With Only 4 Wires!

By Crystalfontz America
About: We manufacturer LCDs, perfect for integrating into consumer products.

These modules are pretty nice. They are the same size as our CFAH1602C series 16x2 Character LCD modules, and thinner as a bonus. The OLED's contrast is fantastic, and they have a crisp look that is hard to beat. Another nice thing is that they have 4 software-selectable character sets, so you won't be stuck wanting for the omega or mu symbol.

Check them out here!

https://www.crystalfontz.com/product/cfal1602c-16x...

Step 1: What You'll Need

Since I had an Arduino Uno handy, I decided to port the SPI version of the AVR code for this OLED to the Arduino. Here are all the parts you will need:

  1. Crystalfontz CFAL1602C OLED in your preferred color.
  2. Connection wires. I used some standard 0.1" headers I had around, and a pack of WRJMPY40 jumper wires.
  3. An Arduino Uno R3

Step 2: Convert OLED to SPI

You will need to order your CFAL1602C pre-confgured for SPI, or follow the instructions in the CFAL1602C datasheet to make the conversion.

Step 3: Connect SPI Lines to OLED

Once that is done, use some of the jumper wires to connect to the pins used for SPI on the CFAL1602C.

Step 4: Connect 5v Power and Ground

Then connect the 5v power and ground pins to the Arduino.

Step 5: Complete the Connections of the OLED's SPI Pins to the Arduino

  • SS: Slave Select
  • MOSI: Master (Arduino) Out, Slave (OLED) In
  • MISO: Master (Arduino) In, Slave (OLED) Out
  • SCK: Spi ClocK

Step 6: Connect Arduino Uno to PC and Open Sketch.

You then just need to connect the Arduino to your PC and open the sketch CFAL1602C_SPI_Arduino.ino. Upload and you will be rewarded with OLED goodness.


//===========================================================================
//
//  Code written for Arduino Uno
//
//  CRYSTALFONTZ CFAL1602C-B CHARACTER OLED IN SPI MODE
//
//  ref: https://www.crystalfontz.com/product/cfal1602c-16x2-character-oled
//
//  2015 - 10 - 22 Brent A. Crosby
//===========================================================================
//This is free and unencumbered software released into the public domain.
//
//Anyone is free to copy, modify, publish, use, compile, sell, or
//distribute this software, either in source code form or as a compiled
//binary, for any purpose, commercial or non-commercial, and by any
//means.
//
//In jurisdictions that recognize copyright laws, the author or authors
//of this software dedicate any and all copyright interest in the
//software to the public domain. We make this dedication for the benefit
//of the public at large and to the detriment of our heirs and
//successors. We intend this dedication to be an overt act of
//relinquishment in perpetuity of all present and future rights to this
//software under copyright law.
//
//THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND,
//EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
//MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
//IN NO EVENT SHALL THE AUTHORS BE LIABLE FOR ANY CLAIM, DAMAGES OR
//OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE,
//ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR
//OTHER DEALINGS IN THE SOFTWARE.
//
//For more information, please refer to
//===========================================================================
//Software SPI (10-bit transfers, difficult to do using the hardware SPI)
#define SPIPORT (PORTB)
#define SPITOGGLE (PINB)
// PB5 (0x20) is SCK  (output) green  OLED pin 12
#define SPI_SCK_PIN (13)
#define SCK_MASK (0x20)
#define CLR_SCK (PORTB &= ~(SCK_MASK))
#define SET_SCK (PORTB |=  (SCK_MASK))
// PB4 (0x10) is MISO (input)  blue   OLED pin 13
//(reference only, it is an input)
#define SPI_MISO_PIN (12)
#define MISO_MASK (0x10)
#define CLR_MISO (PORTB &= ~(MISO_MASK))
#define SET_MISO (PORTB |=  (MISO_MASK))
// PB3 (0x08) is MOSI (output) violet OLED pin 14
#define SPI_MOSI_PIN (11)
#define MOSI_MASK (0x08)
#define CLR_MOSI (PORTB &= ~(MOSI_MASK))
#define SET_MOSI (PORTB |=  (MOSI_MASK))
// DB2 (0x04) is SS   (output) gray   OLED pin 16
#define SPI_SS_PIN (10)
#define SS_MASK (0x04)
#define CLR_SS  (PORTB &= ~(SS_MASK))
#define SET_SS  (PORTB |=  (SS_MASK))
#define DATA (1)
#define COMMAND (0)
//===========================================================================
void write_to_OLED_SPI(uint8_t destination,uint8_t data)
  {
  //Bits sent in this order:
  //  data(1)/command(0) flag
  //  read(1)/write(0) flag
  //  data.7 (msb)
  //  data.6
  //  data.5
  //  data.4
  //  data.3
  //  data.2
  //  data.1
  //  data.0 (lsb)

#if(1)
  //Pretty fast software SPI 10-bit transfer code
  //Several ideas taken from the fastest non-assembly implementation at:
  //http://nerdralph.blogspot.com/2015/03/fastest-avr-software-spi-in-west.html
  //
  // The SS pin is low for ~3.8uS, the clock frequency is ~ 2.6MHz
  // 47x faster than above
  //Pre-calculate the value that will drive clk and data low in one cycle.
  //(Note that this is not interrupt safe if an ISR is writing to the same port)
  register uint8_t
    force_clk_and_data_low;
  //Select the chip
  CLR_SS;
  //Pre-calculate the value that will drive clk and data low in one
  //operation.
  force_clk_and_data_low = (SPIPORT & ~(MOSI_MASK | SCK_MASK) );
  //Set clock and data low
  SPIPORT = force_clk_and_data_low;
  //Set the data(1)/command(0) flag
  if(DATA==destination)
    {
    SPITOGGLE = MOSI_MASK;
    }
  //Use a toggle to bring the clock up
  SPITOGGLE = SCK_MASK;
  //Set clock and data low
  SPIPORT = force_clk_and_data_low;
  //MOSI is already 0, for read(1)/write(0) flag as write
  //Use a toggle to bring the clock up
  SPITOGGLE = SCK_MASK;
  //Now clock the 8 bits of data out
  SPIPORT = force_clk_and_data_low;
  if(data & 0x80)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x40)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x20)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x10)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x08)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x04)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x02)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x01)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  //Release the chip
  SET_SS;
#else
  //Straight-forward software SPI 10-bit transfer code, perhaps
  //easier to understand, possibly more portable. Certainly slower.
  //
  // The SS pin is low for ~180uS, the clock frequency is ~57KHz
  // 47x slower than above
  //Select the chip, starting a 10-bit SPI transfer
  digitalWrite(SPI_SS_PIN, LOW);
  //(bit 0) Set the data(1)/command(0) flag
  if(DATA==destination)
    digitalWrite(SPI_MOSI_PIN, HIGH);
  else
    digitalWrite(SPI_MOSI_PIN, LOW);
  //Clock it in.
  digitalWrite(SPI_SCK_PIN, LOW);
  digitalWrite(SPI_SCK_PIN, HIGH);
  //(bit 1) Clear the read(1)/write(0) flag to write, clock it in.
  digitalWrite(SPI_MOSI_PIN, LOW);
  //Clock it in.
  digitalWrite(SPI_SCK_PIN, LOW);
  digitalWrite(SPI_SCK_PIN, HIGH);
  //(bits 2-9) Push each of the 8 data bits out.
  for(uint8_t mask=0x80;mask;mask>>=1)
    {
    //Set the MOSI pin high or low depending on if our mask
    //corresponds to a 1 or 0 in the data.
    if(mask&data)
      {
      digitalWrite(SPI_MOSI_PIN, HIGH);
      }
    else
      {
      digitalWrite(SPI_MOSI_PIN, LOW);
      }
    //Clock it in.
    digitalWrite(SPI_SCK_PIN, LOW);
    digitalWrite(SPI_SCK_PIN, HIGH);
    }
  //Release the chip, ending the 10-bit SPI transfer
  digitalWrite(SPI_SS_PIN, HIGH);
#endif
  }
//===========================================================================
void position_cursor(uint8_t column, uint8_t line)
  {
  //Set CGRAM Address, RS=0,R/W=0
  // 7654 3210
  // 1AAA AAAA
  //  0x00 to 0x27 => Line 1
  //  0x40 to 0x67 => Line 2
  write_to_OLED_SPI(COMMAND,0x80 | (line?0x40:0x00) | (column & 0x3F));
  }
//===========================================================================
// According to the WS0010 data sheet, only the clear display time has
// an appreciable execution time of 6mS. All others are listed at 0.
void clear_display(void)
  {
  //Display Clear RS=0,R/W=0
  // 7654 3210
  // 0000 0001
  write_to_OLED_SPI(COMMAND,0x01);
  _delay_ms(6);
  }
//===========================================================================
void initialize_display()
  {
  //Refer to WS0010 data sheet, page 21
  // https://www.crystalfontz.com/products/document/3176/WS0010.pdf
  //The display controller requests:
  //  "Wait for power stabilization 500ms:
  _delay_ms(500);
  //Function set, RS=0,R/W=0
  // 7654 3210
  // 0011 NFFT
  //  N = lines: N=1 is 2 lines
  //  F = Font: 0 = 5x8, 1 = 5x10
  //  FT = Font Table:
  //     FT=00 is English/Japanese ~"standard" for character LCDs
  //     FT=01 is Western European I fractions, circle-c some arrows
  //     FT=10 is English/Russian
  //     FT=11 is Western European II my favorite, arrows, Greek letters
  write_to_OLED_SPI(COMMAND,0x3B);
  //Graphic vs character mode setting, RS=0,R/W=0
  // 7654 3210
  // 0001 GP11
  //  G = Mode: 1=graphic, 0=character
  //  C = Power: 1=0n, 0=off
  write_to_OLED_SPI(COMMAND,0x17);
  //Display On/Off Control RS=0,R/W=0
  // 7654 3210
  // 0000 1DCB
  //  D = Display On
  //  C = Cursor On
  //  B = Cursor Blink
  write_to_OLED_SPI(COMMAND,0x0E);
  //Display Clear RS=0,R/W=0
  // 7654 3210
  // 0000 0001
  clear_display();
  //Display home
  write_to_OLED_SPI(COMMAND,0x02);
  //Entry Mode Set RS=0,R/W=0
  // 7654 3210
  // 0000 01IS
  //  I = Increment/or decrement
  //  S = Shift(scroll) data on line
  write_to_OLED_SPI(COMMAND,0x06);
  //Display Clear RS=0,R/W=0
  // 7654 3210
  // 0000 0001
  clear_display();
  }
//===========================================================================
void setup()
  {
  //General setup, port directions.
  // PB5 (0x20) is SCK  (output) green  OLED pin 12
  pinMode(SPI_SCK_PIN, OUTPUT);
  // PB4 (0x10) is MISO (input)  blue   OLED pin 13
  //(reference only, it is an input)
  pinMode(SPI_MISO_PIN, INPUT);
  // PB3 (0x08) is MOSI (output) violet OLED pin 14
  pinMode(SPI_MOSI_PIN, OUTPUT);
  // DB2 (0x04) is SS   (output) gray   OLED pin 16
  pinMode(SPI_SS_PIN, OUTPUT);
  }
//===========================================================================
void loop()
  {
  //Simple demo loop, shows a screen of text, including high order characters
  //( see page 10 of https://www.crystalfontz.com/controllers/WinstarDisplay/WS0010/378 )
  //
  //Then there is a screen with solid characters on the left, and 50%
  //checkerboard characters on the right.
  // Initialize the display
  initialize_display();
  //Display text screen
  //              0123456789012345
  char line1[17]=">}CRYSTALFONTZ{<";
  line1[ 0]=0xF6; // right triange;
  line1[ 1]=0xC7; // right triange;
  line1[14]=0xC8; // left triange;
  line1[15]=0xF7; // left triange;
  //              0123456789012345
  char line2[17]="OLED:aaaaaaaaaaS";
  line2[ 5]=0xE0; //beta
  line2[ 6]=0xA8; //function
  line2[ 7]=0xB8; //divide
  line2[ 8]=0xDA; //sigma
  line2[ 9]=0xEA; //mu (micro)
  line2[10]=0xDF; //alpha
  line2[11]=0xDE; //omega
  line2[12]=0xCF; //circle C
  line2[13]=0x1A; //about equal
  line2[14]=0xED; //pi
  // write to the first line
  position_cursor(0,0);
  for(int col=0;col<16;col++)
    {
    write_to_OLED_SPI(DATA,line1[col]);
    }
  // write to the second line
  position_cursor(0,1);
  for(int col=0;col<16;col++)
    {
    write_to_OLED_SPI(DATA,line2[col]);
    }
  //Show the text message for a bit
  _delay_ms(1000);
  //Use the custom characters (CGRAM) to make the
  //left half solid, the right half checkerboard
  //Set CGRAM [0], to solid
  write_to_OLED_SPI(COMMAND,0x40 | (0 <<3));
  for(int i=1;i<=8;i++)
  write_to_OLED_SPI(DATA,0xFF);
  //Set CGRAM [1], checkerboard
  write_to_OLED_SPI(COMMAND,0x40 | (1 <<3));
  for(int i=1;i<=4;i++)
    {
    write_to_OLED_SPI(DATA,0xAA);
    write_to_OLED_SPI(DATA,0x55);
    }
  // write to the first line
  position_cursor(0,0);
  for(int col=0;col<8;col++)
    {
    write_to_OLED_SPI(DATA,0);  // CGRAM[0]
    }
  for(int col=8;col<16;col++)
    {
    write_to_OLED_SPI(DATA,1);  // CGRAM[1]
    }
  // write to the second line
  position_cursor(0,1);
  for(int col=0;col<8;col++)
    {
    write_to_OLED_SPI(DATA,0);  // CGRAM[0]
    }
  for(int col=8;col<16;col++)
    {
    write_to_OLED_SPI(DATA,1);  // CGRAM[1]
    }
  //Show the pattern for a bit
  _delay_ms(1000);
  }
//===========================================================================

Step 7: Optimizing the Code.

This code transfers at a clock frequency of about ~57KHz, and it takes about ~180uS, to complete one 10-bit write, you won't die from old age waiting for it.

But the old assembly-coding EE in me wanted to see if it could go a little faster . Starting with some optimized Arduino Software SPI examples, I was able to do a bit better:

//Pretty fast software SPI 10-bit transfer code
  //Several ideas taken from the fastest non-assembly implementation at:
  //http://nerdralph.blogspot.com/2015/03/fastest-avr-software-spi-in-west.html
  //
  // The SS pin is low for ~3.8uS, the clock frequency is ~ 2.6MHz
  // 47x faster than above
  //Pre-calculate the value that will drive clk and data low in one cycle.
  //(Note that this is not interrupt safe if an ISR is writing to the same port)
  register uint8_t
    force_clk_and_data_low;
  //Select the chip
  CLR_SS;
  //Pre-calculate the value that will drive clk and data low in one
  //operation.
  force_clk_and_data_low = (SPIPORT & ~(MOSI_MASK | SCK_MASK) );
  //Set clock and data low
  SPIPORT = force_clk_and_data_low;
  //Set the data(1)/command(0) flag
  if(DATA==destination)
    {
    SPITOGGLE = MOSI_MASK;
    }
  //Use a toggle to bring the clock up
  SPITOGGLE = SCK_MASK;
  //Set clock and data low
  SPIPORT = force_clk_and_data_low;
  //MOSI is already 0, for read(1)/write(0) flag as write
  //Use a toggle to bring the clock up
  SPITOGGLE = SCK_MASK;
  //Now clock the 8 bits of data out
  SPIPORT = force_clk_and_data_low;
  if(data & 0x80)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x40)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x20)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x10)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x08)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x04)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x02)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  SPIPORT = force_clk_and_data_low;
  if(data & 0x01)
    SPITOGGLE = MOSI_MASK;
  SPITOGGLE = SCK_MASK;
  //Release the chip
  SET_SS;

That speeds up things by a factor of 47 times, bringing a transfer from 180uS to 3.8us. The equivalent clock frequency from 247KHz to 2.6MHz. Very nice!

Of course either routine will work . . . the "proper Arduino" should be more portable. Have fun connecting an OLED to your Arduino, feel free post your comments or questions.

Step 8: Have Questions? Need More Info?

Have questions or problems? Post questions to our forum: https://forum.crystalfontz.com/showthread.php/7388-Connect-Arduino-Uno-to-a-CFAL1602C-SPI-16x2-Character-OLED-(only-4-wires-needed)
