Introduction: Control Any Devices Using Raspberry PI and PCF8574, Relay Module

About: Software, electronics, do-it-yourself
This guide shows you how to use PCF8574 with Raspberry PI. The PCF8574 is a 8 bits I/O port expander that uses the I2C bus. To the PCF8574 I will connect the relay module, this will allow control of the electrical device from the Raspberry PI. I will also show an example how to write a program to handle PCF8574 in C++ on Linux.

This article can also see here:

Control any devices using Raspberry PI and PCF8574, relay module

Step 1: Components

Components I used in this example.

Step 2: Schematic

Diagram of connecting Raspberry PI with PCF8574 8bits I/O expander.

Step 3: Enable I2C Interface on the Raspberry Pi

At first we need to enable I2C bus on Raspberry Pi. For this purpose, we use the following command.
	sudo raspi-config
  • Select Interfacing Options
  • Select P5 I2C
  • Select Yes

Step 4: Install Utilities

	sudo apt-get update
	sudo apt-get install -y i2c-tools
We add user pi to group i2c.
	sudo adduser pi i2c
After installation we restart the Raspberry Pi.
	sudo shutdown -r now

Step 5: Checking I2C Bus and PCF8574

First, let's scan the i2c bus. In this step, you must already have a PCF8574 connected,
otherwise the scanner will not find anything.
	i2cdetect -y 1
My PCF8574 has an address 0x38. Now let's test the expander.
0x38 is the address of the PCF8574 expander.
0xf0 is the output state as we set, 4 bits in HIGH and 4 bits in LOW.
	i2cset -y 1 0x38 0xf0
We can also read the state of PCF8574 I/O ports.
	i2cget -y 1 0x38

Step 6: Software

Below simple program to handle PCF8574, written in C++.
#include <stdio.h>
#include <time.h>
#include <string>

#include <wiringPi.h>
#include <pcf8574.h>

using namespace std;

int main (int argc, char *argv[]){
	printf("Raspberry Pi\n");

	pcf8574Setup(100, 0x38);

	for (int i = 0; i < 8; ++i){
    		pinMode(100 + i, OUTPUT);

        int b=0;
        while( 1==1 ){
                printf("LOOP %u\n", b);
                for (int i = 0; i < 8; ++i){
                    digitalWrite(100 + i, i==b ? 0 : 1);
		if( b >= 8 ) b=0;


	digitalWrite(100 + 0, 0);

        digitalWrite(100 + 0, 1);

	return 0;
To compile and launch it, use the following command.
	g++ pcf8574.cpp -o pcf8574 -lwiringPi -std=c++11
Download source code: pcf8574.cpp
