Introduction: Control EL Wire With an Arduino
In this instructable I will show you how to control EL Wire with an Arduino.
What you will need:
EL Wire and Inverter - I recommend http://ez-el.com/ez-el-wire/10ft-ez-el-wire-3v-inverter-kit/
Arduino or any micro controller that can control a relay
SPDT Micromini Relay 5V - I recommend Radio Shack 275-0240
Wire
Heat Shrink Tubing or Electrical Tape
General Purpose PC Board
Tools:
Soldering Iron and Solder
Wire Cutters and Strippers
Step 1: Schematic
This is how to hook the circuit up:
Step 2: Wire Up the EL Wire
First you need to disconnect the power wires from the inverter leading to the EL Wire like shown in the picture.
Next solder the ground wires together.
Now connect the voltage wires to the relay as shown in the schematic.
You might want to solder the wires and the relay together on a small PCB.
Step 3: Connect the Relay to the Microcontroller
Lastly, connect the coil wires to the Arduino, just like you would connect an LED. Refer to the schematic for help connecting.
Before you use this be sure to power on the EL Wire inverter. Make sure is is in a non blinking mode.
Any code that works with an LED will work with this hack.

Participated in the
Microcontroller Contest
8 Comments
4 years ago
You needed to add a diode across the relay coil to prevent reverse voltage damage. Other than that, looks good!
6 years ago
I'm trying to keep my power consumption and real estate down to a bare minimum. Could I use a 1.5Vrelay with a 3V teensy arduino and a 1.5V EL transformer? I need a small backlight in a battery powered electronic device.
7 years ago on Introduction
I did this in a similar fashion but an led chaser board was used to sequentially switch the relays (instead of blinking leds). still working out the intermittent bugs though.
7 years ago on Introduction
Thanks. That was cool but I never saw any pictures of the strippers!
8 years ago
Thanks for your suggestions. As far asi know you can't dim the EL Wire or do PWM.
Reply 8 years ago on Introduction
Actually you can do both, see this incomplete and abandoned ( pretty much ) page for the pic 877. Code is C so should be understandable. Electronically the relay is replaced by a triac.
8 years ago
I think you need a reverse current protection diode in there as the relay is inductive.
8 years ago on Introduction
How does this handle dimming of the EL wire?
