Introduction: Controlling Servo Motor Using IR Remote Control

About: Mechatronics engineer. I'm a Fab Lab Egypt team member.

If you are looking for comfort and controlling your electronic devices remotely, you will find your need in this instructable.

In this instructable we will learn how to control a servo motor with remote control, this will give you a general concept on how to control remotely. You should know that the remote control sends Infrared(IR) signals, so we will learn how to receive and read these signals using Arduino.

Step 1: Required Components

  • Arduino UNO
  • Servo motor
  • Remote control
  • IR receiver
  • Breadboard
  • Jumper wires

Step 2: Wiring

We use arduino UNO to control the servo motor to make the functionality we want.

We use IR receiver to read IR signals from remote control.

Wiring IR receiver and servo motor is shown in pictures.

Follow the steps of wiring in the pictures.

Step 3: The Programming

First, download IRremote library for arduino from this link.

Copy the library to Local Disk(C:) > Program Files(x86) > Arduino > libraries

Open IRremote demo example from Arduino IDE as picture 1 then upload to arduino board.

Then open serial monitor and try to click on any button of remote control to send a signal to IR receiver, the HEX code of each button must appear in serial monitor as picture 2

Then detect the HEX code of the buttons using to control the servo motor, assume you will use two buttons of your choice, one for clockwise rotation and another for counter clockwise rotation.

for example, use (+) for clockwise and (-) for counterclockwise, so you have to get their HEX codes.

(+) ---> A3C8EDDB

(-) ---> F076C13B

In the final code, the functionality is when clicking at any of two buttons the motor is toggling between the rotation in main direction and stop so when first click at any of two buttons the motor will rotate in button's direction, and when second click at same button the motor will stop as shown in the video.

The code is:

// Written by: Mohamed Soliman
// This code is for controlling servo motor with IR remote control // When clicking at any of two buttons the motor is toggling between the rotation and stop

#include <IRremote.h> //must copy IRremote library to arduino libraries #include <Servo.h> #define plus 0xA3C8EDDB //clockwise rotation button #define minus 0xF076C13B //counter clockwise rotation button

int RECV_PIN = 2; //IR receiver pin Servo servo; int val; //rotation angle bool cwRotation, ccwRotation; //the states of rotation

IRrecv irrecv(RECV_PIN);

decode_results results;

void setup() { Serial.begin(9600); irrecv.enableIRIn(); // Start the receiver servo.attach(9); //servo pin }

void loop() { if (irrecv.decode(&results)) { Serial.println(results.value, HEX); irrecv.resume(); // Receive the next value

if (results.value == plus) { cwRotation = !cwRotation; //toggle the rotation value ccwRotation = false; //no rotation in this direction }

if (results.value == minus) { ccwRotation = !ccwRotation; //toggle the rotation value cwRotation = false; //no rotation in this direction } } if (cwRotation && (val != 175)) { val++; //for colockwise button } if (ccwRotation && (val != 0)) { val--; //for counter colockwise button } servo.write(val); delay(20); //General speed }

Step 4: Let Your Circuit Working

Have fun with your remotely controlled servo motor.

With the same concept you can remotely control everything you need from a single LED to any device in your room.

2 People Made This Project!

Recommendations

  • Hide It Challenge

    Hide It Challenge
  • 3D Printed Student Design Challenge

    3D Printed Student Design Challenge
  • Soapmaking and Candlemaking Speed Challenge

    Soapmaking and Candlemaking Speed Challenge

55 Comments

0
akshay.d21
akshay.d21

6 years ago on Introduction

Very nice instructable mohamed ! :)
One doubt i have is, the servo runs continuously for as long as the button is pressed or what ?

0
mohamed soliman
mohamed soliman

Reply 6 years ago on Introduction

No, it runs continuously for first click and stops for second click.

that's because the remote doesn't send continuous signal for one click.

0
giantpair
giantpair

Reply 5 years ago

Can I make it run continuously while pushing the button?

0
elhadi30
elhadi30

6 years ago on Introduction

nice .work ....but Is it possible to increase the speed of rotation

0
mohamed soliman
mohamed soliman

Reply 6 years ago on Introduction

yes it's possible, by decreasing the delay time, it's the time of rotation of 1 degree.

0
nilesh2690
nilesh2690

6 years ago on Introduction

Hello I want to control Servo motor using count from webpage?

How can i do that?

0
mohamed soliman
mohamed soliman

Reply 6 years ago on Introduction

check that you copied IRremote library to arduino libraries, and try to remove RobotIRremote library which is mainly existed in arduino libraries so that the code work correctly.

0
Srisai2022
Srisai2022

3 months ago on Step 4

how can i control multiple servo motors using single ir sensor and ir remote?

0
schmidleo16
schmidleo16

8 months ago

When I pushed a button on my remote all that showed up was
Protocol=NEC Address=0x4 Command=0x3 Repeat gap=28800us.
Does anyone know why?

0
TheAntman22O
TheAntman22O

10 months ago

my servo wont turn ive tried multiple ones and i can confirm im recieving a signal

0
SNJJNS
SNJJNS

Tip 2 years ago on Step 4

Remote HEX codes


ESP8266Basic variables


IR_CHminus
= "e318261b:UNKNOWN:32"

IR_CH = "511dbb:UNKNOWN:32"

IR_CHplus = "ee886d7f:UNKNOWN:32"

IR_PREV = "52a3d41f:UNKNOWN:32"

IR_NEXT = "d7e84b1b:UNKNOWN:32"

IR_PLAY = "20fe4dbb:UNKNOWN:32"

IR_VOLminus= "f076c13b:UNKNOWN:32"

IR_VOLplus = "a3c8eddb:UNKNOWN:32"

IR_EQ = "e5cfbd7f:UNKNOWN:32"

IR_0 = "c101e57b:UNKNOWN:32"

IR_100plus = "97483bfb:UNKNOWN:32"

IR_200plus = "f0c41643:UNKNOWN:32"

IR_1 = "9716be3f:UNKNOWN:32"

IR_2 = "3d9ae3f7:UNKNOWN:32"

IR_3 = "6182021b:UNKNOWN:32"

IR_4 = "8c22657b:UNKNOWN:32"

IR_5 = "488f3cbb:UNKNOWN:32"

IR_6 = "449e79f:UNKNOWN:32"

IR_7 = "32c6fdf7:UNKNOWN:32"

IR_8 = "1bc0157b:UNKNOWN:32"

IR_9 = "3ec3fc1b:UNKNOWN:32"

For the Remote in the image (Cheap Chinese model with "Car MP3" logo along bottom edge
