Convert 7.2V Cordless Drills to Lithium-Ion Power




Introduction: Convert 7.2V Cordless Drills to Lithium-Ion Power

So...lets say you happen to get you hands on a beautiful old-school BOSCH PBM V-1 cordless drill.

But it came with a couple of drawbacks:
A) The Ni-Cd battery pack is useless (makes sense after all those years).
B) It didn't come with a charger.

So you come to the logical conclusion. The cost of a new battery pack is more that you ar willing to pay,
and its impractical to rebuild the pack with new No-Cd cells as you don't have a charger to begin with!

So what do you do???

Convert to Lithium Power of course! :-)


All you'll need is the following:

1) 2 x 18650 li-ion UNPROTECTED batteries (branded and new is better) (UPGRADED, see last step)
2) One holder for 2 18650 batteries (cheep on eBay or locally) ---SEE LAST STEP FOR AN UPGRADE---
3) A small rotary tool (I used a Dremel with metal cutting discs)
4) Soldering iron (25W should be enough)
5) Hot glue gun (super glue, optional)
6) Tool to open up the old battery pack (I ended up using the Dremel)

(a nice site to read-up on li-po conversions: Lithium-IonBatteries.html)

Its really simple, so...lets begin!

Step 1:

First thing first...

You need to determine the voltage of the pack you have on your drill.
This should be  printed on the pack itself.
My pack was a 7.2Volt one (using six Ni-Cd sub-C cells).
So it makes sense to use two 18650 lithium batteries (at 3.7V nominal voltage each)

So we need to replace the old dead Ni-Cd cells with the new lithium batteries.

First of all we take the old battery pack and pry it open.
Some are easier than others. Some even have screws but others (like mine will require a Dremel)
Try not to do much damage as we will need to put the bottom half back on.

The only thing we will need from in there is the battery pack contacts and a small plastic piece that holds them.
Discard the old cells properly (and be careful of any toxic acid residue on them)

Step 2:

So, you are now ready to put the lithium battery holder inside the pack.

Using the Dremel we cut a hole on the bottom of the pack housing and place the holder inside.
Securing the holder with hot-glue and super-glue is essential.

After that is done we solder the wires to the end contact tabs (OBSERVE THE POLARITY!!!),
and secure the assembly inside the other half with some more hot-glue and super-glue combo.

A this point one should check that the drill works(before putting the two halfs together).
It should work, provided the batteries are chareged and the polarity is correct

Step 3:

All that's left now is to put back together the two halfs of the battery pack.
We do that with some more hot-glue / super-glue combo, and test everything once more.

THAT'S IT... you now have a lithium powered cordless drill !!!

I suggest you get two sets of 18650 batteries, so you can have one set in the drill and one in the charger at all times.

Leave your comments and suggestions at will !

Enjoy and have fun!
Bill Geo

Step 4: 2015: Time for a (power) Upgrade

So after some more use and testing of the drill I found that the current the 18650 batteries can deliver

was enough to drill plastics and soft metals (like brass and aluminum) but the drill struggled with anything more

demanding (even dry-screwing large wood-screws in MDF)...

It was time for a power-source upgrade!

So a 2S 3000mAh Li-Po battery with a 40C discharge rating from my quadcopter project was used instead.

The case was cut to accommodate the larger size of the pack, and the added weight gave the drill a nice balance.

A voltage monitor (again from the R/C world) was added in the back to keep an eye out for over-discharging

(even though the drill is pretty much useless before the voltage drops to any dangerous level).

The difference?


Lots of torque and excellent battery life.

I would suggest to anyone that wants to try a li-po conversion on a drill to go for this type of battery-pack.

Though a mod that uses one or two paralleled 18650 cells will be good enough for a screwdriver or a low-power drill.

NOTE: it goes without saying that the Li-Po pack should be charged with an appropriate charger,

and the voltage level monitored regularly to avoid over-discharge.

Be the First to Share


    • Organization Challenge

      Organization Challenge
    • Block Code Contest

      Block Code Contest
    • Game Design: Student Design Challenge

      Game Design: Student Design Challenge



    7 years ago on Introduction

    Just a note to let you know I have added this to the collection: Cordless-Drill-Battery-Maintenance !


    Take a look at a bunch of different/similar approaches to this project.


    10 years ago on Introduction

    have to say, going with unprotected cells because of under-current issues is DANGEROUS!!!

    There's a REASON they put current limits into those protection circuits.
    Draw the power too fast, and you can kill your cells dead.
    You'll need replacement cells every couple months of regular use.
    Just not worth it.
    Remember the big to-do a few years ago with the exploding and burning laptop batteries? The reason today's batteries are so much safer is because they changed the protection circuitry so the cells aren't pushed as hard.

    A MUCH better solution, if you have room, is to use a 2s2p battery setup, with protected cells. That will MORE than double the power, AND make the individual cells last a lot longer. At the least, use a protection circuit with a higher rating. Consider looking at "pack protection" circuits.
    If you DON'T have room for all that, consider BETTER protected cells.
    They are out there. Some Redilast and Tennergy can source over 4 amps!


    Reply 8 years ago on Introduction

    I have to agree with ironsmiter here. His comment rather refers to max current draw under operation that each li-ion cell can handle (which is way lower than NiCd or NiMH batteries); not to be confused with the low voltage cutoff aspect.

    Distributing the current-burden on each cell is achieved; as suggested by ironsmiter; by having two or more in parallell for each planned cell. This distributes the current draw from each cell by I/nC, where I is current and nC refers to the number of cells in parallell. Thus for 7.4v rionsmiter suggests 2p2s (2 in parallell 2 times in series) amounting to a total of 4 cells.

    A look at the spec sheets from major battery manufacturers on 18650-cells gives some valualbe insights on the limitations of these cells . Li-ion cells need much more "babying", than previous batteries. Risk of fire if badly treated highly present. A note worth making for people doing this @ home for the first time.

    Great project! Kudos.


    Reply 10 years ago on Introduction

    Sorry, bad form on my part... SHOULD have started with
    GREAT IDEA! and a lovely write up.
    I love the fact that you're saving that old workhorse from an untimely demise.
    The saying "they don't make them like they used to" is VERY true. Especially for these old, nearly indestructible power tools.

    This is Reduce, Reuse, Recycle at it's best.


    Reply 10 years ago on Introduction

    It's true you started off a little "strong"... :-)

    However my experience with using this drill is that you don't end up
    over-discharging the batteries simple because of the "human factor".
    In other words the drill will have no power and you will pull out the
    batteries to recharge them before you can actually do damage to them.

    But I am planing to do some more measurements and calculations
    in the near future, and then I will be able to get back with more info on that.
    But I still think there are no protection circuits that can provide the current
    the motor needs to run (and also be cost effective).


    Reply 9 years ago on Introduction

    there are Lipo alarms available that monitor the voltage of the cells and start beeping when they hit low voltage without damage to the cells. the alarms don't limit current, just monitor voltage. they plug into the balance lead on the battery


    8 years ago on Step 3

    You have to implement a low-voltage cutoff circuit between your battery and the drill. Otherwise, you will run the risk of discharging the cells beyond a sacred point for Li-ion and your battery will die (or heavily degrade).


    Reply 8 years ago on Step 3

    Yeah, you are right! Thank you for the comment!

    There should be a low voltage cut off there,

    and I am making one using an ATtiny micro, because when there is a lot of current

    draw on the battery the voltage dips a lot momenteraly and thats problematic when using comparators.

    However, I reality I found that the drill becomes useless for lack of power before the LiPo cells reach a point of destructive discharge, so you charge them or replace them anyway...


    Reply 8 years ago on Step 3

    Agreed. ATtiny solution is pro! Thumbs up.


    9 years ago on Introduction

    I just started seeing this idea and it is great! I see many great rechargeable tools in the thrift stores and thought what a pity the cost to get new batteries, but now they can be easily re purposed. It would be nice to have more technical information and sources.


    Reply 9 years ago on Introduction

    I hate to say it like this, but if you are not used to using LiPo batteries, you should not use this idea. Lipo fires are bad! These are predominantly used in R/C race cars, and are required to be charged in a fire-proof container, as they become unstable if they drop below 3.2-3.4 volts per cell, and can spontaneously combust.
    if you do use Lipo, make sure you use a dedicated LiPo charger and a low voltage alarm like I listed above.

    IMO, you are bettter served with a Lithium Ion pack, which are more stable and can also be bought at R/C plane suppliers, and are more stable at low voltage.


    Reply 9 years ago on Introduction

    makya, I think you ment to post rather than reply to my post. Good information.
