Introduction: DESIGN AND BUILD a WIRELESS LASER ENGRAVER CUM PEN PLOTTER USING FUSION 360 AND 3D PRINTING

About: student at SRM university , Btech mechatronics Loves finding out how things work and trying it myself . Loves anything that's a combination of electronics and mechanical .

A couple of months back while checking out a few laser engravers on aliexpress, I came across some USB powered laser engravers, It was awesome that these could engrave on a variety of materials and also cut out shapes and designs from sticker sheets and paper and doing all this powered by a 5V USB supply. But the downside of these engravers was that they had a small work area, in most cases just 40mm X 40mm which is definitely way too small for my needs.

So I thought why not design and 3D print my own laser engraver from scratch. I started the designing process in FUSION 360 while keeping in mind all the 3D printing tolerances. And finally came up with something really cool. Along the way, I decided to make the laser holder modular so that I can easily replace the laser with a pen or marker for pen plotting. I also added a Bluetooth connectivity feature so that wired connection between your PC and the engraver can be eliminated while transmitting G codes.

So this instructible basically shows how you can make one kind of CNC machine using another kind of CNC machine ;-)

SPECIFICATIONS:-

1. A work area of 200 X 162 mm

2. 1000 mW laser module

3. Runs on a USB power source (5 volts)

4. Auto homing feature.

5. Bluetooth communication between the laser engraver and PC.

6. PWM control of the laser.(helps in producing different shades of black when engraving portraits)

7. 102.4 steps per mm resolution

8. The machine can engrave, cut and draw on different materials.

9. Switchable laser and pen modules.

10. Magnetic module holder for easy switching.

Step 1: DESIGNING THE LASER ENGRAVER IN FUSION 360

FUSION 360 is one of those amazing platforms which allows you to convert those design ideas inside your head into reality. It really helps in expressing your idea about something to others. It's really easy to learn and use. Assembly of the components can be done easily and it helps in the validation of your design by checking for collisions and other problems

I started by designing the base and the Y-axis smooth rod holders. Since the holders consist of two identical components, the mirror feature in fusion 360 got the job done easily. The mirror feature has been used multiple times in designing this laser engraver. Unlike other cad software, one cool thing about fusion 360 is that it allows the designing of multiple components on the same screen with reference to other components, ie the model can be designed in an assembled manner.

The hight of the X-axis guide rails depends on the focal range of the laser you are using. Just make sure that the height of the laser is within that range. The final focusing of the laser beam can be done by adjusting the lens on the laser.

Fusion 360 also allows us to choose the appearance and material of the components so that your final design looks like the real thing. Fusion 360 also lets us convert and save the designed components directly in STL format which makes it easier for the next stage of 3D printing.

I will be sharing the Fusion 360 file of the assembly here,you guys can modify it according to your needs.

Step 2: COMPONENTS, MODULES AND TOOLS REQUIRED:-

    MODULES AND COMPONENTS:

    TOOLS:

    • Sandpaper
    • Small triangular file
    • Screwdrivers
    • soldering iron
    • Hand saw
    • Pliers
    • Lighter
    • Scissors
    • Wire cutters
    • Hand held rotary tool

    Step 3: PARTS TO BE 3D PRINTED :-

    The STL files of all the parts to be 3D printed are uploaded here.

    All the parts are designed such that they can be easily 3D printed without supports.

    I used a TEVO tarantula 3D printer

    • Material : PLA (dark green)
    • Layer height : 0.3mm
    • Infill : 40%
    • wall thickness: 0.8mm
    • Top/bottom thickness : 0.9mm

    Step 4: ASSEMBLING THE Y AXIS

    The first thing I would recommend you guys to do before starting the assembly is to keep the Fusion 360 assembly file open in your PC. This helps in making the assembly process less confusing.

    Fusion 360 lets us hide all the unwanted components for the time being so that we can concentrate better on the area we are assembling.

    Here I have attached screenshots from Fusion 360 as well as the actual assembly pictures.

    Steps of assembly:

    1. Two of the smooth rods are inserted into one of the Y-axis smooth rod holders. I have designed the bores such that the rods will have a tight fit in order to avoid glue. Gently tap the rods with a hammer if necessary.
    2. Four linear bearings are inserted into the slots provided for it beneath the Y-axis carriage. Here again, it's a tight fit, so the glue won't be necessary.
    3. Now slide the open end of the smooth rods in through the linear bearings.
    4. Insert the other smooth rod holder at the open ends of the smooth rods.

    Make sure that the carriage can easily slide from one end to the other in a smooth manner.

    Step 5: ATTACHING THE BUILT PLATE:

    1. Drill a hole in the middle of the 22 X 22 cm transparent acrylic sheet.
    2. Bolt the sheet on the Y-axis carriage using a single nut and bolt in the middle.
    3. Adjust the sheet until the edges of the sheet are parallel to the edges of the carriage.
    4. Mark the remaining four hole positions on the acrylic sheet with a marker for drilling reference.
    5. Remove the sheet from the carriage and drill all the holes with a 3mm drill bit.
    6. Using a suitable bigger bit and countersink the 3mm holes so that the bolt head won't stick out.
    7. Finally, attach the build plate (acrylic sheet) to the Y-axis carriage using M3 12mm bolts and nuts.

    Step 6: ASSEMBLING THE X-AXIS

    1. First, fasten the X-axis rod holders and the pillars together using two M3 12mm bolt and nut as shown in the picture.
    2. Now insert both the smooth rods into one of the rod holders just like we did for the Y-axis.
    3. Tight fit the linear bearings onto the X-axis carriage.
    4. Slide-in the carriage through the open ends of the smooth rods and then insert the second holder at the open ends.

    You guys might have noticed that I used 3D printed bearings instead of metals ones. This was because two of the bearings I received were damaged and caused the wobbling of the carriage. The bores of the 3D printed bearings are smoothened using fine sandpaper and oil is applied for smooth motion. They worked just as well as the metal ones.

    Step 7: Converting the Unipolar 28BYJ-48 Motor Into a Bipolar Motor

    There are 2 main reasons why we are converting the unipolar motor into a bipolar motor.

    • Algorithm for controlling a bipolar motor via an A4988 stepper motor driver is simpler than controlling a unipolar motor
    • The CNC shield only supports A4988 stepper motor drivers, thus the shield only supports bipolar stepper motors and hence conversion is a must.

    The conversion can be done in 3 simple steps:-

    1. After opening the blue plastic casing, desolder the red wire from the PCB as seen in the first picture.
    2. Now using a sharp blade, scrape away the common connection between the two coils of the stepper motor as seen in the encircled portion of the second picture.
    3. Now rearrange the wires on the connector based on color as seen in the 3rd picture.

    Watch this video by Make'n'Modify by clicking here for a better understanding of the procedure.

    Step 8: MOUNTING THE MOTOR , PULLEY AND THE BELT OF THE X-AXIS

    1. First, fasten the stepper motor to the X-axis motor mount using two M3 12mm bolts and nuts. Fasten a GT2 16 teeth pulley onto the motor axle by tightening both the grub screws.
    2. Now insert the pulley onto the X-axis pulley holder using an M4 40mm bolt as the axle of the pulley as seen in the picture. Remove both the grub screws from this pulley.
    3. Fasten the Motor mount along with the motor to the right and the pulley holder to the left of the X-axis assembly using three M3 30mm bolts and nuts on each side as shown in the picture.
    4. Tie one end of the timing belt to one of the slots provided for it on the X-axis carriage using cable ties.
    5. Run the other end of the belt through both the pulleys and back to the second slot on the X-axis carriage and tie it using cable ties. Make sure that the belt is not too tight nor too loose. It should be springy to the touch.

    Step 9: BASE BOARD PREPARATION AND X AXIS MOUNTING

    1. First, draw a huge perfect cross in the middle of the baseboard
    2. Align the X-axis assembly along the X-axis of the cross as seen in the picture.
    3. Mark the screw hole positions using a marker.
    4. Do the same for Y-axis as well.
    5. Drill the holes using a 3mm drill bit.
    6. Screw the X-axis assembly to the baseboard.

    Step 10: MOUNTING THE Y-AXIS SETUP

    This is a tricky step, so please refer to the assembly file for better understanding and then follow these steps

    1. Assemble the pulley holder using the Y-axis pulley holder, the pulley, M4 40mm bolt/nut, and metallic washers as seen in the first two pictures.
    2. Now tie one end of the timing belt to one of the slots beneath the Y-axis carriage.
    3. Run the free end of the belt through the pulley assembly which you made earlier and then tie it to the second slot provided beneath the Y-axis carriage.
    4. Once these 3 steps are done we can screw the Y-axis assembly to the plywood base referring the holes for this we drilled earlier after marking the hole positions.
    5. Fasten the stepper motor to the Y-axis motor mount using two M3 12mm bolts and nuts.
    6. Now screw the Y-axis pulley holder and Motor mount to the plywood base. Do this after adjusting both sides to get the correct belt tension. It's okay even if it's not perfect as we will be adding an adjustable belt tensioner later on.

    Step 11: MAGNETIC MOUNT AND THE LASER MODULE

    1. Once both the mount halves are 3D printed, insert the magnets into the slots with a little bit of superglue in between. Make sure that the same poles are facing outside in one half and the opposite poles are facing outside in the second half of the mount.
    2. Fasten the half with a long slot in the middle to the X-axis carriage using two M3 12mm bolts and nuts. The long slot is provided to adjust the height of the laser later on if required.
    3. The remaining half is fastened to the laser module using two M3 12mm bolts.
    4. The MOSFET module is glued on using hot glue
    5. A three-wire connector is made. Insulation from the free end is removed and the wires are fastened to the screw terminals of the MOSFET module. The +ve and -ve of the laser are connected to V+and V- respectively of the MOSFET module. The power is connected to the VCC and GND respectively. The signal wire is connected to sig pin of the MOSFET module.

    Step 12: PEN LIFTING MODULE

    1. Once both the pieces are 3D printed, the faces which come in contact with each other ae smoothened using a file and sandpaper until both the pieces slide one inside the other with very little friction.
    2. Now three M3 40mm bolts are screwed in. These bolts are used to hold the pen rigidly inside the setup. A spring is inserted before screwing the middle bolt.
    3. An M3 12 mm bolt is also screwed into one of the holes for the servo motor to push on.
    4. A screw is used to hold the free end of the spring in tension so that writing pressure can be applied.
    5. A servo motor is glued on as seen in the picture.
    6. Wire screw terminals are also glued on using superglue.
    7. An Arduino nano is used here to convert the laser control signals received from the CNC shield into PWM signals which can control the micro servo motor.

    WIRING :

    • +5 Volt - Vin
    • -5 Volt - GND
    • Signal - D10
    • Servo power +ve - 5V
    • Servo power -ve - GND
    • Servo signal - D3

    Once the wiring is done upload the code file "pen_module_code" attached in this step into your Arduino nano.

    Step 13: CIRCUIT DIAGRAM

    The connection is straight forward

    The X and Y motors are plugged into ports marked as X-axis and Y-axis respectively.

    The PWM laser signal is taken from the "Z+" pin on the CNC shield.

    Step 14: WIRING THE SYSTEM

    1. The boost converter is set to 12 volts by turning the pot on it clockwise.
    2. The CNC shield is inserted into the Arduino
    3. The cooling fan is glued at the opening provided for it using hot glue. The Arduino along with the CNC shield and the boost module is fixed in the casing
    4. The LED strip is added for looks as well as for power indication.
    5. The 3D printed casing is screwed to the plywood.
    6. An 87 X 75 mm sheet of transparent acrylic with a thickness of 2 mm is used as the casing cover. It can be slide in through a slot provided for it on one of the sides of the casing.
    7. The limit switches are attached in such a way that the button clicks 3mm before the bearings of each carriage collide with the rod holders.
    8. The wires for the motors and limit switches are extended using ribbon wires and the connections are insulated using heat shrink insulation.close to the X-axis pulley as shown in the picture. This is the pin to which the laser module or the pin module will be plugged in. Solder +5 volts, GND and Sig from the CNC shield to these pins. When you are plugging in the modules, make sure its plugged in the right way.
    9. Add a set of male jumper pins
    10. The ribbon wires glued neatly to the plywood base using superglue.

    We are using the boost converter here just to power the ICs in the A4988 motor driver on the CNC shield.

    Each motor draws just 150 mA of current, Therefore you guys won't face any kind of heating of the boost converter.

    Step 15: ADDING BLUETOOTH CONNECTIVITY

    In order to send and receive data or in our case G-codes via the HC05 Bluetooth module, first, we should configure the module using AT commands.

      1. Connect the HC05 module to an Arduino Uno as seen in the first picture.
      2. Upload the code attached to this step into that Arduino.
      3. Now go to the serial monitor and type in the AT codes given in the 2nd picture.
      4. Once the configuration is done, disconnect the HC05 module from the Arduino you used to program it and connect to the Arduino CNC Shield according to the circuit diagram in the 3rd picture.

      Since electronic components are used, I used a tiny piece of PCB to make things easier.

      I attached ends of female jumper wires to the Bluetooth module so that it can be easily plugged into the CNC shield.

      Step 16: CODING THE LASER ENGRAVER

      This is a code from Github which I slightly modified

      1. In order to upload it First pair and connect your computer to the laser engraver via Bluetooth. Use the default password "1234" if asked for.
      2. Now open the attached code in Arduino IDE and select your Bluetooth port number from the ports in tools.
      3. Now hit the compile and upload button.

      Attachments

      Step 17: LASER GRBL SOFTWARE CONFIGURATION

      Laser GRBL is one of the best free G-code streamer software for DIY laser engravers. It can directly stream G codes to an Arduino via a com port. It has an inbuilt conversion tool to convert a picture into G codes.

      Click here to download the software.

      After installation of the software, follow the following steps for its configuration.

      1. Set the com port to which your laser engraver is connected.
      2. Set the baud rate at 115200
      3. Go to "Grbl" then Grbl Configuration" and set the values in the window that opens as seen in the pictures.

      The configuration values can be modified according to what suits your machine best.

      Once the configuration is done your laser engraver cum pen plotter is ready for action,

      Go to the "files" button on the toolbar and open the design you would like to engrave or cut out.

      There are options to select what type of engraving you would like to do, the power of the laser, etc which you can adjust according to the laser module you are using. Here I have attached pictures showing the settings I used.

      Plugin the laser module and its time for some testing.

      Step 18: TESTING

      Once the laser is plugged in, its time to test the accuracy and precision of your machine.

      There are a few things we should test:-

      • If the X and Y-axis are moving in the correct direction.
      • If the homing is working or not.
      • If the motor is missing steps due to high friction or belts which are too tight.Adjust belt tension to fix this problem.
      • If the dimension of the designs being printed matches the dimensions which you gave in the software.Recalculate the steps per mm according to the stepper motor you are using.

      The belt tension can be adjusted using a 3D printed belt tensioner. Turn the M3 bolt on it until the right tension is attained. I have attached the STL file of the belt tensioner along with the other files to be 3D printed.

      To test if the motor is missing steps and if the dimensions are right, print a simple continuous geometric figure like a square, triangle or a circle. If the laser starts from one point and perfectly stops at the same point it means that your laser is not missing a single step and is working perfectly. Once the triangle or square is printed, manually measure its dimensions using a ruler and see if it matches with the dimensions you gave.

      Here I have attached videos of the laser starting and perfectly stopping at the same point.

      Step 19: RESULTS

      The machine came out amazing.

      I was able to engrave on a variety of materials like wood, cardboard, leather, plastic, etc.

      Since the motor had about 102 steps per mm, I was able to do tiny engravings with high details like the dragon I cut out from black stickers.

      The engraver was running smoothly on a USB power supply without any problems.

      I hope this instructable will help people looking forward to making their own laser engravers or pen plotters.

      If anyone has any doubts or suggestions, please do let me know through the comments.

      CNC Contest

      Fourth Prize in the
      CNC Contest

      Be the First to Share

        Recommendations

        • Pi Day Speed Challenge

          Pi Day Speed Challenge
        • Trash to Treasure Contest

          Trash to Treasure Contest
        • Sculpt & Carve Challenge

          Sculpt & Carve Challenge

        16 Comments

        0
        alireza.mosi1
        alireza.mosi1

        7 weeks ago

        Hi, thank you patrick panikulam for your design. I just wondering can I increase the length of the shafts in order to expand the working area?

        0
        patrick panikulam
        patrick panikulam

        Reply 1 day ago

        yes you can. Also get longer belts and a bigger build plate .
        you have to set the new axis lengths in the laser grbl software.

        0
        nunoit57
        nunoit57

        19 days ago

        can't download stl's please fix thank you






        0
        DokterChaos
        DokterChaos

        6 months ago

        I built this project as pen plotter. some feedback and tips to add to the guide:

        The pulley width is 10mm. your aliexpress links has 2 different sizes available
        The pulley axle width is 5mm.
        It takes some time to figure out how many pieces to print of every STL, and in what direction. The names of the STL's and the ones used in fusion360 are different, which makes for quite a bit of puzzling.
        I printed the parts on a Prusa MK3S, and it's well-tuned, and all parts came out with a very loose fitment. Axle rods didn't press-fit and the pen module rattled around a lot. It seems the extrusion ratio of your 3D printer is too high. I mounted the rods with some tape around it, and re-printed the inner piece of the pen module. I discarded the magnetic mount of the pen module, and mount the pen module with 2 screws. You could see the pen module wobble around too much during plotting.

        You need more screw sizes than the ones listed. I ordered more countersunk M3 screws in 14 and 16mm. otherwise you get very long screws sticking out everywhere. Adding how many screws of every type would be handy.
        Setting up GRBL, I had to enable $21 for hard limits.
        I thought the spindle speed would determine how far the pen goes, which is wrong. you can only run at max spindle speed (1000). To adjust the travel of the pen, open pen_module_code.ino and adjust values 20 and 60. the shorter the travel of the pen, the better. Later I'll add a few buttons and code to the Arduino Nano, to tweak the distance easily. You also need a 1K pulldown on the PWM signal to the arduino nano.
        You also need a tension spring, and piece to mount on the servo which actuates the arm. I 3D printed something in PETG, then heated up the part around the mounting hole (soldering iron or hot air gun), then pressed the piece onto the servo. This gives the arm a good fit and prevents slippage.
        Adding a hole to mount the screw and spring of the pen module would be nice.
        You need to install the Servo library for Arduino, to upload the code.
        I used the standard GRBL software, so I could use the latest version.

        So, now I got it ready and it worked... quite poorly. The belt yanks the pulleys sideways, causing a very slack belt and the pulley to grind into the plastic. After some plotting, the motors would have an offset of 1cm from the original position. The heat of the motors melted the mounting brackets in both PLA and PETG, so I reprinted them in ABS.
        Reducing the current on the stepper drivers quickly led to lost steps on the motor. T
        I printed an extra brace for the pulleys, to keep them straight. This drastically improved the accuracy of the pen plotter, but quickly killed the stepper motor. I had a spare motor, which also broke after an hour or so. It makes clicking sounds but doesn't move. I ordered two Nema steppers on Aliexpress, so I hope that makes the machine faster, more accurate and more reliable.

        2020-08-20 00.43.31.jpgIMG_20200821_190554.jpg2020-08-14 22.16.16.jpg
        0
        DokterChaos
        DokterChaos

        Reply 6 months ago

        With cheap Nema steppers, the improvement was massive. I was still losing some steps, so I filed away a part of the frame where the belt was rubbing and changed power supplies. This is with a 0.40mm gel pen. Not bad.

        0
        DokterChaos
        DokterChaos

        9 months ago

        I'm building the plotter right now. The 7mm pulleys don't seem to fit. Are you using the 10mm wide pulleys with a 6mm belt?

        0
        patrick panikulam
        patrick panikulam

        Reply 9 months ago

        If you are talking about the bore of the pulley I am using , I am using a pulley with 5mm bore . The shaft if the motor I am using is 5mm so ot was a perfect fit .

        0
        DokterChaos
        DokterChaos

        Reply 9 months ago

        ah, no, I mean the belt width. pulleys for a 10mm belt look like they fit, while the ones for a 6mm belt seem too short

        0
        luivraos
        luivraos

        Tip 11 months ago

        I finished my amounto of "Whoa, really!" today, excellent job!!
        If you change the pen for a nail polisher they sell for 2Dll that works with a pair of "AA" battery to make it a CNC engraver, wire it to activate when it is down and reduce speed and youll have the whole package!
        something like this:
        https://www.wish.com/product/5a30a03d518c1c443af5a855?hide_login_modal=true&from_ad=goog_shopping&_display_country_code=MX&_force_currency_code=MXN&pid=googleadwords_int&c=%7BcampaignId%7D&ad_cid=5a30a03d518c1c443af5a855&ad_cc=MX&ad_lang=ES&ad_curr=MXN&ad_price=72.00&campaign_id=9436859950&gclid=Cj0KCQjw1Iv0BRDaARIsAGTWD1uZlN7XP38_mCo2WZGoOxd-xY3vzJ9wkcqf0pONLGxPigF01xMXusQaAjVgEALw_wcB&share=web

        0
        charls4
        charls4

        Question 1 year ago on Step 19

        when uploading the pen-module-code.ino I get the error message "#include expects" Filename or Filename. Please help because everything else works.
        0
        patrick panikulam
        patrick panikulam

        Answer 1 year ago

        Instead of directly running the code which I have uploaded , copy the contents of the code I uploaded, paste it in a new sketch in Arduino ide and try compiling it . Make sure the servo library already exists in your Arduino libraries.
        Make sure the board selected is Arduino nano .
        The code for the penmodule is very simple . Incase nothing works you can make the code your self, it's that simple . Just make a code to turn a sevo connected to the pin D3 to a certain angle when the pin D10 is high and return the servo to its initial position when pin D10 is low

        0
        vishnu_
        vishnu_

        1 year ago

        hlo there;
        i am unable to upload code via bluetooth
        plz help me .
        mine bluetooth module is hc 05 with 3.0 firmware

        0
        patrick panikulam
        patrick panikulam

        Reply 1 year ago

        If you are talking about just uploading GRBL code, you can also do using the traditional USB cable.
        Here is a videos which clearly explains how to code an Arduino via Bluetooth

        https://youtu.be/doxaobqMr7g

        0
        solarborg
        solarborg

        1 year ago

        Great job now all you need is a drag knife. There are some designs in thingiverse. Don't try a router as it's not strong enough 10/10
