FPV Goggles With Local to Remote View Switch, With Local Infrared Camera

By in CircuitsGadgets

2,110

47

2

Introduction: FPV Goggles With Local to Remote View Switch, With Local Infrared Camera

By

If you don't want to take off the FPV mask when you take off and landing with yout RC model, then use this home made mask that has a switch to change back and forth from the FPV view to your eyes view. This is all home made and has an infrared front camera you can switch to normal light or IR.

This is fully home built using a cell phone 3D viewing support (mask), with a Tx receiver, some switches and cables.

Have a safe flight !
