Floppy Bird

Introduction: Floppy Bird

Today we will be making a game using a TFT LCD. This would look like a game which is really popular and a lot of people still play this game. The game is called Flappy Bird but this game is a bit different because the UI is different as well as the way the game works. I called this game Floppy Bird as this could lead to copyright issues. Nonetheless it's a really fun game and it's easy to make. I have made this instructable which will allow you to make the game completely and make it work like I did. If you have any questions then please comment down below and I will try to answer these questions as fast as possible.


- Arduino Mega 2560 and cable

- Arduino Mega Shield

- Arduino TFT LCD Compatible with the Arduino Mega 2560

- SD Card

Step 1: Assembling the TFT LCD

Now, we can start to assemble the TFT LCD. We'll connect the TFT LCD to the shield, so firstly take the TFT LCD and basically align it with the pins on the shield. Once you have aligned the pins, push the TFT LCD down so it fits in place. When all the pin heads are in the shield and you can't see the pin heads, that's when you know that the TFT LCD is connected properly. Next, we can plug in the shield to the Arduino Mega 2560. Align the pins of the shield on the Arduino Mega and plug it in. When all the pin heads are in the Arduino Mega and you can't see the pin heads, that's when you know that the TFT LCD is connected properly and it's ready to be powered on. Plug in the Arduino to see if you have connected the LCD properly, if the LCD turns on and the screen is white then congrats, you have successfully connected the TFT LCD and now it's ready to be programmed. Lastly, we have one thing to do, which is to connect the SD card in the LCD. On the back of the TFT LCD there is a SD card slot where you can simply plug in the SD card. Therefore, just plug it in and it's done.

Step 2: Programming the TFT LCD

Now, we will program the LCD so it runs the game and we can play it. Below is the code that you have to compile and upload using the Arduino IDE.

Problems you might have:

Change the parameters of the TFT LCD according to the model you have.


#include <UTFT.h>
#include <URTouch.h> #include <EEPROM.h>

//==== Creating Objects UTFT myGLCD(ILI9341_16,38,39,40,41); //Parameters should be adjusted to your Display/Shield model URTouch myTouch( 6, 5, 4, 3, 2);

//==== Defining Fonts extern uint8_t SmallFont[]; extern uint8_t BigFont[]; extern uint8_t SevenSegNumFont[];

extern unsigned int bird01[0x41A]; // Bird Bitmap

int x, y; // Variables for the coordinates where the display has been pressed

// Floppy Bird int xP = 319; int yP = 100; int yB = 50; int movingRate = 3; int fallRateInt = 0; float fallRate = 0; int score = 0; int lastSpeedUpScore = 0; int highestScore; boolean screenPressed = false; boolean gameStarted = false;

void setup() { // Initiate display myGLCD.InitLCD(); myGLCD.clrScr(); myTouch.InitTouch(); myTouch.setPrecision(PREC_MEDIUM); highestScore = EEPROM.read(0); // Read the highest score from the EEPROM initiateGame(); // Initiate the game }

void loop() { xP=xP-movingRate; // xP - x coordinate of the pilars; range: 319 - (-51) drawPilars(xP, yP); // Draws the pillars // yB - y coordinate of the bird which depends on value of the fallingRate variable yB+=fallRateInt; fallRate=fallRate+0.4; // Each inetration the fall rate increase so that we can the effect of acceleration/ gravity fallRateInt= int(fallRate); // Checks for collision if(yB>=180 || yB<=0){ // top and bottom gameOver(); } if((xP<=85) && (xP>=5) && (yB<=yP-2)){ // upper pillar gameOver(); } if((xP<=85) && (xP>=5) && (yB>=yP+60)){ // lower pillar gameOver(); } // Draws the bird drawBird(yB);

// After the pillar has passed through the screen if (xP<=-51){ xP=319; // Resets xP to 319 yP = rand() % 100+20; // Random number for the pillars height score++; // Increase score by one } //==== Controlling the bird if (myTouch.dataAvailable()&& !screenPressed) { fallRate=-6; // Setting the fallRate negative will make the bird jump screenPressed = true; } // Doesn't allow holding the screen / you must tap it else if ( !myTouch.dataAvailable() && screenPressed){ screenPressed = false; } // After each five points, increases the moving rate of the pillars if ((score - lastSpeedUpScore) == 5) { lastSpeedUpScore = score; movingRate++; } } // ===== initiateGame - Custom Function void initiateGame() { myGLCD.clrScr(); // Blue background myGLCD.setColor(114, 198, 206); myGLCD.fillRect(0,0,319,239); // Ground myGLCD.setColor(221,216,148); myGLCD.fillRect(0, 215, 319, 239); myGLCD.setColor(47,175,68); myGLCD.fillRect(0, 205, 319, 214); // Text myGLCD.setColor(0, 0, 0); myGLCD.setBackColor(221, 216, 148); myGLCD.setFont(BigFont); myGLCD.print("Score:",5,220); myGLCD.setFont(SmallFont); myGLCD.print("BY JAWAD", 140, 220); myGLCD.setColor(0, 0, 0); myGLCD.setBackColor(114, 198, 206); myGLCD.print("Highest Score: ",5,5); myGLCD.printNumI(highestScore, 120, 6); myGLCD.print(">RESET<",255,5); myGLCD.drawLine(0,23,319,23); myGLCD.print("TAP TO START",CENTER,100); drawBird(yB); // Draws the bird // Wait until we tap the sreen while (!gameStarted) { if (myTouch.dataAvailable()) { myTouch.read(); x=myTouch.getX(); y=myTouch.getY(); // Reset higest score if ((x>=250) && (x<=319) &&(y>=0) && (y<=28)) { highestScore = 0; myGLCD.setColor(114, 198, 206); myGLCD.fillRect(120, 0, 150, 22); myGLCD.setColor(0, 0, 0); myGLCD.printNumI(highestScore, 120, 5); } if ((x>=0) && (x<=319) &&(y>=30) && (y<=239)) { gameStarted = true; myGLCD.setColor(114, 198, 206); myGLCD.fillRect(0, 0, 319, 32); } } } // Clears the text "TAP TO START" before the game start myGLCD.setColor(114, 198, 206); myGLCD.fillRect(85, 100, 235, 116); } // ===== drawPlillars - Custom Function void drawPilars(int x, int y) { if (x>=270){ myGLCD.setColor(0, 200, 20); myGLCD.fillRect(318, 0, x, y-1); myGLCD.setColor(0, 0, 0); myGLCD.drawRect(319, 0, x-1, y);

myGLCD.setColor(0, 200, 20); myGLCD.fillRect(318, y+81, x, 203); myGLCD.setColor(0, 0, 0); myGLCD.drawRect(319, y+80, x-1, 204); } else if( x<=268) { // Draws blue rectangle right of the pillar myGLCD.setColor(114, 198, 206); myGLCD.fillRect(x+51, 0, x+60, y); // Draws the pillar myGLCD.setColor(0, 200, 20); myGLCD.fillRect(x+49, 1, x+1, y-1); // Draws the black frame of the pillar myGLCD.setColor(0, 0, 0); myGLCD.drawRect(x+50, 0, x, y); // Draws the blue rectangle left of the pillar myGLCD.setColor(114, 198, 206); myGLCD.fillRect(x-1, 0, x-3, y);

// The bottom pillar myGLCD.setColor(114, 198, 206); myGLCD.fillRect(x+51, y+80, x+60, 204); myGLCD.setColor(0, 200, 20); myGLCD.fillRect(x+49, y+81, x+1, 203); myGLCD.setColor(0, 0, 0); myGLCD.drawRect(x+50, y+80, x, 204); myGLCD.setColor(114, 198, 206); myGLCD.fillRect(x-1, y+80, x-3, 204); } // Draws the score myGLCD.setColor(0, 0, 0); myGLCD.setBackColor(221, 216, 148); myGLCD.setFont(BigFont); myGLCD.printNumI(score, 100, 220); }

//====== drawBird() - Custom Function void drawBird(int y) { // Draws the bird - bitmap myGLCD.drawBitmap (50, y, 35, 30, bird01); // Draws blue rectangles above and below the bird in order to clear its previus state myGLCD.setColor(114, 198, 206); myGLCD.fillRoundRect(50,y,85,y-6); myGLCD.fillRoundRect(50,y+30,85,y+36); } //======== gameOver() - Custom Function void gameOver() { delay(3000); // 1 second // Clears the screen and prints the text myGLCD.clrScr(); myGLCD.setColor(255, 255, 255); myGLCD.setBackColor(0, 0, 0); myGLCD.setFont(BigFont); myGLCD.print("GAME OVER", CENTER, 40); myGLCD.print("Score:", 100, 80); myGLCD.printNumI(score,200, 80); myGLCD.print("Restarting...", CENTER, 120); myGLCD.setFont(SevenSegNumFont); myGLCD.printNumI(2,CENTER, 150); delay(1000); myGLCD.printNumI(1,CENTER, 150); delay(1000); // Writes the highest score in the EEPROM if (score > highestScore) { highestScore = score; EEPROM.write(0,highestScore); } // Resets the variables to start position values xP=319; yB=50; fallRate=0; score = 0; lastSpeedUpScore = 0; movingRate = 3; gameStarted = false; // Restart game initiateGame(); }

Step 3: Done!

We have made the circuit and compiled the code. Now, we just have to plug in the Arduino mega and play the game.

Here, I have a link to a video that shows how this game works and what to do in order to set it up :


Let me know if you have any problems down below.

Be the First to Share


    • Cold Challenge

      Cold Challenge
    • Clocks Contest

      Clocks Contest
    • Make it Glow Contest

      Make it Glow Contest



    2 years ago

    Arduino: 1.8.13 (Windows 10), Placa:"Arduino Mega or Mega 2560, ATmega2560 (Mega 2560)"
    C:\...\AppData\Local\Temp\ccRNUyDM.ltrans0.ltrans.o: In function `drawBitmap':
    C:\...\UTFT/UTFT.cpp:1154: undefined reference to `bird01'
    C:\...\Arduino\libraries\UTFT/UTFT.cpp:1154: undefined reference to `bird01'
    C:\...\Arduino\libraries\UTFT/UTFT.cpp:1154: undefined reference to `bird01'
    C:\...\Arduino\libraries\UTFT/UTFT.cpp:1154: undefined reference to `bird01'
    C:\...\Arduino\libraries\UTFT/UTFT.cpp:1170: undefined reference to `bird01'
    C:\...AppData\Local\Temp\ccRNUyDM.ltrans0.ltrans.o:C:\...\Arduino\libraries\UTFT/UTFT.cpp:1170: more undefined references to `bird01' follow
    collect2.exe: error: ld returned 1 exit status
    exit status 1

    im using Mega 2560 with Megashield V2.2 and the TFT-320-QVT-9341 screen
    hello, thanks for your project.
    it shows me this error while sending code to the arduino. can you help please
    thank you very much.


    Question 2 years ago on Step 3

    Loaded and compiled the sketch. Then I get the error message: Error compiling for board Arduino Mega or Mega 2560. I have the Mega 2560 with Megashield V2.2 and the TFT-320-QVT-9341 display. What else can I do? Greatings
