Introduction: Flyback Transformer Drivers

About: Just another computer nerd. I'm ready for our AI overlords and wetware implants.

This instructable is the seventh one that I made. This instructable is about how to make a fly back transformer driver. There are two that I will show, one that is mechanical, and one that is solid-state (for the more technologically advanced). My inspiration for this instructable was that I made a mechanical driver, then it died; so I bought another one but decided to make a solid-state one.

Warning: this instructable deals with high voltage, so you could get shocked and potentially killed. I take no responsibility for any damage, injury, or death.

P.S.  The picture you see on this page is copied and pasted from Google, so it's not this good or high power.

Step 1: Parts for Simple Driver

These are the parts that you need for a simple fly back driver. The pros are that it's simple to build and lasts a long time. The cons are that it doesn't make as big sparks as solid-state drivers, and it's very noisy.

Parts:
1- 5 volt relay
?- wires
1- 6 volt power source
1- fly back transformer with pins identified
1- on/off switch (optional)

Tools:
1- soldering iron
1- solder wire
1- helping hands station (optional)

Step 2: Schematic for Simple Driver

This is the schematic for the simple driver. Just wire the relay like the picture has it. The two wires sticking on the bottom is what you connect to the power source and transformer. Just follow schematic #2 to see how to connect it all.

Step 3: Parts for Solid State Flyback Driver

These are the parts that you need for the solid state driver. The pros are that it makes bigger sparks. The cons are that it's harder to make.

Parts:
1- 6 volt power source
1- on/off switch (optional)
1- fly back transformer with pins identified
1-555 timer ic
1-power transistor (see schematic and text file)
1-0.01 uf capacitor
?-resistors (it depends on whether you use the schematic or my info in the text document)
?- wires

Tools:
1- soldering iron
1- solder wire
1- helping hands station (optional)

Hack It! Challenge

Participated in the
Hack It! Challenge

The Mad Science Fair

Participated in the
The Mad Science Fair

Be the First to Share

    Recommendations

    • Plastic Contest

      Plastic Contest
    • The 1000th Contest

      The 1000th Contest
    • Battery Powered Contest

      Battery Powered Contest

    26 Discussions

    1
    nmamirreza
    nmamirreza

    Question 1 year ago

    hi. can i use transistor 13007.13005
    i try it and its not working
    i check transistor out put and it is 12 volt
    why no sparking?
    pls say to me wire awg or mm

    thx

    0
    Count Volta
    Count Volta

    2 years ago

    The first one is very retro but I will try it first.

    0
    TheGreatResistor
    TheGreatResistor

    4 years ago

    Have you tried the simple driver does it work and if it does at what frequency I want to replicate please help

    0
    techno guy
    techno guy

    Reply 4 years ago

    The simple driver runs at a relatively low frequency, probably under 100 Hz.

    It really depends on the size of your relay, bigger relays run slower than smaller relays.

    0
    TheGreatResistor
    TheGreatResistor

    Reply 4 years ago

    Is 100Hz enough to run a flyback?

    0
    techno guy
    techno guy

    Reply 4 years ago

    Technically no because it isn't near the resonant frequency of the flyback, but actually yes (more like kind of) because you'll still be able to draw sparks from it, just they will be smaller and less powerful.

    0
    TheGreatResistor
    TheGreatResistor

    Reply 4 years ago

    How many cm can I expect

    0
    TheGreatResistor
    TheGreatResistor

    Reply 4 years ago

    How many cm or mm sparks can I expect from the relay and the 555 timer

    0
    techno guy
    techno guy

    Reply 4 years ago

    Depends on the input voltage/current/frequency.

    0
    techno guy
    techno guy

    Reply 4 years ago

    Maybe 1 cm?

    Excuse me, I have a question. Will the reverse voltage spikes not damage the 555 chip?

    0
    techno guy
    techno guy

    Reply 4 years ago

    It's possible, you should probably use some kind of diode for protection.

    I have actually burned 555 chips from shorting out the output of the flyback.

    0
    johnl2
    johnl2

    4 years ago

    Sorry, but how on earth do you expect that relay driver to work? What oscillates the relay? As far as I can see, you have both ends of the coil wired in series between the power source and the transformer. I wired it up just for kicks, it turns the relay on and that's about it.

    0
    techno guy
    techno guy

    Reply 4 years ago

    Sometimes that happens, not sure why. In my tests I used a 5 volt relay, those tiny ones that RadioShack used to sell. It works by the relay turning on and swinging the contact which shorts out the coil causing the contact to fall back but opens the circuit and drawing the contact back, over and over.

    0
    -max-
    -max-

    8 years ago on Step 2

    see what happens if you add a film capacitor across the +V and the positive end of the flyback. i did this with a very similar circuit with a ignition coil and it gave me much better output (from <1mm sparks to 20 mm long sparks)

    0
    -max-
    -max-

    Reply 5 years ago on Introduction

    In parallel. That way you make a L1 tank circuit. It has to be well tuned so first without it figure out how many turns gives you the most output, then start adding various film or MKP capacitors to see what works best.

    That wasn't exactly my original idea but it will do exactly the same thing.

    0
    Electrospark
    Electrospark

    Reply 5 years ago on Introduction

    Hmm... Yeah, I saw this configuration on the ZVS circuit.

    I might give it a try but people don't want me to play with high voltage...

    But it's so much fun... :( I guess I'll have to go with second best and watch photonicinduction's videos. :)

    0
    ahime1
    ahime1

    7 years ago on Introduction

    Does the capacitor have to be a 0.01uf or can it be bigger?

    0
    techno guy
    techno guy

    Reply 7 years ago on Introduction

    for the solid state one, it could be different, but the frequency would change.
