Introduction: Get the Serial Number of a DS18B20 With an Arduino
This is a quick guide on how to get the individual serial numbers of your DS18B20 1-wire temperature sensors.
This is handy for projects that require multiple sensors.
Things you need:
- Arduino 5v (UNO, Mega, Pro Mini etc) - Arduino UNO R3 - AliExpress - eBay
Temp Sensor DS18B20 - AliExpress - eBay
4.7k - 1/4w Resistor THT - AliExpress - eBay
Breadboard - AliExpress - eBay
- Jumper Wires - Male to Male - AliExpress - eBay
- A computer with Arduino IDE installed
Step 1: Add the Required Library to Arduino IDE
- Open Arduino IDE (I am using 1.8.1)
- Click "Sketch" -> "Include Library" -> "Manage Libraries..."
- Select the search bar and type "dallas"
- Click "DallasTemperature" and click "Install"
Alternatively you can download the Library from here: https://github.com/milesburton/Arduino-Temperature...
This Library includes the OnWire Library.
Step 2: Wire Up the DS18B20
Using a bread board connect +5V, GND and Digital Pin 2 (Pin 2 is already set in the example sketch) from the Arduino using Male to Male breadboard jumpers.
Connect the DS18B20 parallel to the 3x terminal strips on the breadboard.
- Pin 1 (GND) -> GND (Ground 0V)
- Pin 2 (DATA) -> Digital Pin 2
- Pin 3 (Vdd) -> +5V
For Normal Power Mode connect a 4.7K Resistor from +5V to Digital Pin 2 wire on the breadboard.
The following link is a great resource for the DS18B20 1-wire temperature sensor.
Step 3: Load the Example Sketch "Single"
Open Arduino IDE (I am using 1.8.1)
Click "File" -> "Examples" -> "Dallas Temperature" -> "Single"
I added in delay(5000); on line 103 to give me time to copy the serial number
Select your appropriate board form "Tools" -> "Board"
Select your appropriate port "Tools" -> "Port"
Now "Upload" the Sketch "Sketch" -> "Upload"
Click "Tools" -> "Serial Monitor" make sure the baud rates match mine is 9600
If you sketch did not upload check your Board, Port, USB drivers etc.
Step 4: Copy the Serial Number
From the "Serial Monitor" you will see the 4th line is "Device 0 Address: xxxxxxxxxxxxxxxx"
This is the Serial Number of the DS18B20
If it is "0000000000000000" then there is an issue reading your DS18B20.
Highlight it with your mouse and press CTRL+C on you keyboard then past it in Notepad
For my other projects my code uses an array of these numbers. I reformatted the HEX string to the following format.
DeviceAddress tempSensorSerial[9]= {
{0x28, 0xFF, 0x07, 0xA6, 0x70, 0x17, 0x04, 0xB5}, {0x28, 0xFF, 0xB2, 0xA6, 0x70, 0x17, 0x04, 0x28}, {0x28, 0xFF, 0x42, 0x98, 0x70, 0x17, 0x04, 0xD3}, {0x28, 0xFF, 0x86, 0xA8, 0x70, 0x17, 0x04, 0xA6}, {0x28, 0xFF, 0x2B, 0x65, 0x71, 0x17, 0x04, 0x76}, {0x28, 0xFF, 0x66, 0x62, 0x71, 0x17, 0x04, 0xF5}, {0x28, 0xFF, 0xD9, 0x9B, 0x70, 0x17, 0x04, 0x9C}, {0x28, 0xFF, 0x98, 0x6A, 0x71, 0x17, 0x04, 0xED}, {0x28, 0xFF, 0x99, 0x42, 0x71, 0x17, 0x04, 0x4C} };
Step 5: Finished
Now you can identify each individual DS18B20 1-wire temperature sensor in your code and use a function like this:
float getTemperature(byte j)
{
sensors.requestTemperaturesByAddress(tempSensorSerial[j]);
float tempC = sensors.getTempC(tempSensorSerial[j]);
return tempC;
}
Check out my simple example sketch
