Introduction: H-BRIDGE RECTIFIER CIRCUIT TO CONTROL THE DIRECTION OF DC MOTOR USING PROTEUS STIMULATION

By

Description:

H Bridge is a simple electronic circuit which enables us to apply voltage to load in either direction. It is commonly used in robotics application to control DC Motors. By using H Bridge we can run DC Motor in clockwise or anticlockwise directions. In order to change the direction of the voltage supplied, the H-Bridge controls the switches that deliver power to the load.

SOFTWARE REQUIRED:

Proteus 8 Professional

Step 1: Selecting Components in Proteus From Its Library.

The first five components are found in component mode

The last two are found in Terminal mode

COMPONENETS USED:

Transistor(2N2219) - 4

Switch – 2

Diode – 4

Resistor – 4

DC Motor – 1

Ground

Power Source - 2

For detailed explanation Refer Video @0:57 seconds

Step 2: Connect the Components Carefully As Given in the Below Image to Form a Complete Circuit.

Use the help of the reference picture

Ensure all components are properly connected

Refer video if needed Click Here

Step 3: Stimulating the Circuit

This is the final step.

Its time to stimulate the circuit.

Click on the run, pause, stop buttons to stimulate, pausing the stimulation and ending the stimulation, respectively which is found at the left bottom corner.

DON’T FORGET TO SAVE THE PROJECT!

HOPE YOU LIKED THE INSTRUCTIONS THANK YOU KEEP EXPLORING!
